Medium Power Film Capacitors
FFVE/FFVI (FFWE/FFWI RoHS Compliant)
GENERAL DESCRIPTION
The FFV capacitor is specifically designed for DC filtering, low reactive power.
The series uses a non-impregnated metallized polypropylene or polyester dielectric, which
features a controlled self-healing process, specially treated to have a very high dielectric
strength in operating conditions up to 105°C.
The FFV special design gives this series a very low level of stray inductance (18 nH to 40 nH).
Furthermore, the performance levels of the FFVE capacitor makes them a very interesting
alternative to electrolytic technology, because they can withstand much higher levels of
surge voltage, very high rms current ratings, and longer lifetimes.
K
DC FILTERING
Not RoHS Compliant
Please select correct termination style.
PACKAGING MATERIAL
Self-extinguishing plastic case (V0 = in
accordance with UL 94) filled thermosetting
resin.
Self-extinguishing thermosetting resin (V0
= in accordance with UL 94; I3F1 = in
accordance with NF F 16-101).
FFVE capacitors meet the Level 2 requirement of the fire behavior standard NF F 16-102.
DIMENSIONS
Also available with
threaded female
connections -
M5 x 7.5mm max
Torque 2.5Nm
20
(0.787)
– – Male Threaded
Terminal Code
M8
1.0
(0.039)
JE or 7X
Female Threaded
Tightening Torque
3 N.m max
*Mounting with Thermal Interface Grease
Dimensions: millimeters (inches)
General Tolerance:
±0.5
(0.020)
5 (0.197)
45±1
(1.772±0.039)
Ø20 (0.787)
±1
(0.039)
Ø16 (0.63)min
5 (0.197)
M5x7.5
Plastic Case
22
(0.866)
Tinned Output
LABEL
H±1
(0.039)
LABEL
H±1
(0.039)
Ø5.5 (0.217)
(3 10
.9 1
76
)
71.7 (2.822)
84.5 (3.327) max
0.6
Ø84
(0.024) (3.307) max
5 (0.197)
71.7 (2.822)
84.5 (3.327) max
5 (0.197)
Max Torque 8.5 N.m for M8
Max Torque 2.5 N.m for M5
Resin
HOW TO ORDER
FFVE
4
H
Voltage Code
H = 300V L = 1000V
I = 400V
(FFVE/FFWE)
J = 500V L = 1100V
K = 600V
(FFVI/FFWI)
A = 700V U = 1200V
B = 800V N = 1900V
C = 900V
0187
Capacitance
Code
0 + pF code
0187 = 180μF
0356 = 35μF
etc.
K
––
Series
Dielectric
FFVE = Standard
4 = Polyester
FFVI = Standard
6 = Polypropylene
FFWE = RoHS Compliant
FFWI = RoHS Compliant
Capacitance
Terminal Code
Tolerances
– – or J7 = Male Threaded
K = ±10%
JE or 7X = Female Threaded
See Ratings and Part
Reference Tables for details
HOT SPOT CALCULATION
See Hot Spot Temperature, page 3.
θ
hot spot
=
θ
case
+ (P
d
+ P
t
) x R
th
with P
d
(Dielectric losses) = Q x tgδ
0
Q x tgδ
0
⇒
[
1
⁄
2
x C
n
x (V
peak
to
peak
)
2
x f ] x tgδ
0
tgδ
0
(tan delta)
For polypropylene, tgδ
0
= 2 x 10
-4
for frequencies up to
1MHz and is independent of temperatures. For polyester,
tgδ
0
values are shown in graph 4 on page 3.
P
t
(Thermal losses) = R
s
x (I
rms
)
2
where
C
n
in Farad
I
rms
in Ampere
f in Hertz
θ
in °C
V in Volt
R
s
in Ohm
R
th
in °C/W
θ
case
= bottom center of case
Rs(f) vs FREQUENCY
For frequency higher than 1 kHz
use following curve
3.5
Rs(f) = (Rs-a) + k a
H=34: a 0.20
H=40: a 0.21
H=51: a 0.23
H=64: a 0.24
3.0
2.5
2.0
1.5
1.0
1
100
10
Frequency (kHz)
1000
24
■
JUNE 2015
Medium Power Film Capacitors
FFVE/FFVI (FFWE/FFWI RoHS Compliant)
Working temperature
Capacitance range
Capacitance tolerance
Rated DC voltage
Test voltage between terminals @ 25°C
Insulation voltage between
shorted terminals and earth
Dielectric
-40°C to +105°C (according to the power to be dissipated)
100μF to 400μF
±10%
300 to 400 V
1.5 x V
n
dc 10s
7 kVrms/60sec/50Hz
Polyester
RATINGS AND PART NUMBER REFERENCE – POLYESTER DIELECTRIC
Part Number*
FFVE4H0187K--
FFVE4H1956K--
FFVE4H0257K--
FFVE4H0357K--
FFVE4H0407K--
FFVE4I0107K--
FFVE4I0127K--
FFVE4I0157K--
FFVE4I0187K--
FFVE4I0227K--
Capacitance
(μF)
180
195
250
350
400
100
120
150
180
220
Height
34
34
40
51
51
34
34
40
51
51
(1.339)
(1.339)
(1.575)
(2.008)
(2.008)
(1.339)
(1.339)
(1.575)
(2.008)
(2.008)
Irms max.
(A)
Ls max.
(nH)
Rs
(m )
0.8
0.8
0.6
0.8
0.8
0.7
0.6
0.7
1.0
0.9
Rth
(°C/W)
4.7
4.4
5.2
7.2
7.1
4.7
4.1
5.0
8.5
7.2
Typical
Weight (g)
300
300
350
420
420
300
300
350
420
420
Vndc 300 volts (Voltage Code H)
100
18
100
18
100
25
100
32
110
32
Vndc 400 volts (Voltage Code I)
80
18
100
18
100
25
80
32
100
32
*Change “--” to “JE” for female connectors M5 x 7.5mm
Dimensions millimeters (inches)
LIFETIME EXPECTANCY
FFVE POLYESTER
1.5
1.4
1.3
1.2
1.1
1.0
0.9
0.8
0.7
0.6
0.5
0.4
100
50°C
60°C
70°C
85°C
95°C
105°C
1000
10000
100000
1000000
V
w
/V
n
dc
Lifetime Expectancy (hours)
V
w
: permanent working or operating DC voltage.
JUNE 2015
■
25
DC FILTERING
ELECTRICAL CHARACTERISTICS – FFVE/FFWE POLYESTER DIELECTRIC
Medium Power Film Capacitors
FFVE/FFVI (FFWE/FFWI RoHS Compliant)
ELECTRICAL CHARACTERISTICS – FFVE/FFWE POLYPROPYLENE DIELECTRIC
Working temperature
Capacitance range
Capacitance tolerance
Rated DC voltage
Test voltage between terminals @ 25°C
Insulation voltage between
shorted terminals and earth
Dielectric
-40°C to +105°C (according to the power to be dissipated)
12μF to 220μF
±10%
600 to 1900 V
1.5 x V
n
dc 10s
7 kVrms/60sec/50Hz
Polypropylene
V
w
/V
n
dc
V
w
/V
n
dc
DC FILTERING
RATINGS AND PART NUMBER REFERENCE – POLYPROPYLENE DIELECTRIC
Part Number*
FFVE6K0256K--
FFVE6K0107K--
FFVE6K0157K--
FFVE6K0227K--
FFVE6B0666K--
FFVE6B0107K--
FFVE6B0147K--
FFVE6C0126K--
FFVE6C0386K--
FFVE6C0476K--
FFVE6C0706K--
FFVE6C0107K--
FFVE6L0666KJ7
FFVE6L0107KJ7
FFVE6L0147KJ7
FFVE6U0476KJ7
FFVE6U0706KJ7
FFVE6U0107KJ7
FFVE6N0156KJ7
FFVE6N0246KJ7
FFVE6N0356KJ7
Capacitance
(μF)
25
100
150
220
66
100
140
12
38
47
70
100
66
100
140
47
70
100
15
24
35
Height
34 (1.339)
40 (1.575)
51 (2.008)
64 (2.520)
40 (1.575)
51 (2.008)
64 (2.520)
34 (1.339)
34 (1.339)
40 (1.575)
51 (2.008)
64 (2.520)
40 (1.575)
51 (2.008)
64 (2.520)
40 (1.575)
51 (2.008)
64 (2.520)
40 (1.575)
51 (2.008)
64 (2.520)
Irms max.
(A)
Ls max.
(nH)
Rs
(m )
0.7
0.6
0.9
1.0
0.7
1.0
1.3
0.9
1.6
0.8
1.2
1.1
1.5
2.0
2.5
1.7
2.4
2.9
1.1
1.3
1.6
Rth
(°C/W)
4.3
4.8
6.9
8.4
4.7
6.7
8.4
4.4
3.9
4.6
6.7
8.2
5.1
7.3
9.2
4.9
7.2
8.9
5.2
6.5
8.4
Typical
Weight (g)
300
350
420
500
350
420
500
300
300
350
420
500
350
420
500
350
420
500
350
420
500
Vndc 600 volts (Voltage Code K)
90
18
100
25
110
32
100
40
Vndc 800 volts (Voltage Code B)
100
25
90
32
100
40
Vndc 900 volts (Voltage Code C)
70
18
100
18
100
25
100
32
90
40
Vndc 1000 volts (Voltage Code L)
70
25
64
32
51
40
Vndc 1200 volts (Voltage Code U)
66
25
59
32
49
40
Vndc 1900 volts (Voltage Code N)
73
25
73
32
67
40
*Change “--” to “JE” for female connectors M5 x 7.5mm
*Change “J7” to “7X” for female connectors M5 x 7.5mm
Dimensions millimeters (inches)
LIFETIME EXPECTANCY FOR FFVE POLYPROPYLENE
-- and JE
1.8
1.6
1.4
1.2
1.0
0.8
0.6
100
95°C
105°C
1000
10000
70°C
85°C
100000
1000000
50°C
1.6
1.5
1.4
1.3
1.2
1.1
1.0
0.9
100°C
0.8
0.7
0.6
100
J7 and 7X
50°C
85°C
70°C
95°C
105°C
1000
10000
100000
1000000
Lifetime Expectancy (hours)
Lifetime Expectancy (hours)
V
w
: permanent working or operating DC-voltage.
V
w
: permanent working or operating DC-voltage.
26
■
JUNE 2015
Medium Power Film Capacitors
FFVE/FFVI (FFWE/FFWI RoHS Compliant)
Working temperature
Capacitance range
Capacitance tolerance
Rated DC voltage
Test voltage between terminals @ 25°C
Insulation voltage between
shorted terminals and earth
Dielectric
-40°C to +105°C (according to the power to be dissipated)
47μF to 275μF
±10%
500 to 1100V
1.25 x V
n
dc 10s
7 kVrms/60sec/50Hz
Polypropylene
RATINGS AND PART NUMBER REFERENCE – POLYPROPYLENE DIELECTRIC
Part Number*
FFVI6J1256K--
FFVI6J0207K--
FFVI6J2756K--
FFVI6A0107K--
FFVI6A0157K--
FFVI6A0227K--
FFVI6C0666K--
FFVI6C0107K--
FFVI6C0147K--
FFVI6L0476K--
FFVI6L0706K--
FFVI6L0107K--
Capacitance
(μF)
125
200
275
100
150
220
66
100
140
47
70
100
Height
40 (1.575)
51 (2.008)
64 (2.520)
40 (1.575)
51 (2.008)
64 (2.520)
40 (1.575)
51 (2.008)
64 (2.520)
40 (1.575)
51 (2.008)
64 (2.520)
Irms max.
(A)
Ls max.
(nH)
Rs
(m )
0.6
0.8
0.9
0.6
0.9
1.0
0.7
1.0
1.3
0.8
1.2
1.1
Rth
(°C/W)
5.0
6.7
8.7
4.8
6.9
8.4
4.7
6.7
8.4
4.6
6.7
8.2
Typical
Weight (g)
350
420
500
350
420
500
350
420
500
350
420
500
Vndc 500 volts (Voltage Code J)
90
25
90
32
90
40
Vndc 700 volts (Voltage Code A)
100
25
100
32
100
40
Vndc 900 volts (Voltage Code C)
100
25
90
32
100
40
Vndc 1100 volts (Voltage Code L)
100
25
100
32
90
40
Dimensions millimeters (inches)
LIFETIME EXPECTANCY FOR FFVI
1.2
1.1
1.0
V
w
/V
n
dc
70°C
0.9
85°C
0.8
95°C
0.7
0.6
0.5
100
1000
105°C
50°C
10000
100000
Lifetime Expectancy (hours)
V
w
: permanent working or operating DC-voltage.
JUNE 2015
■
27
DC FILTERING
ELECTRICAL CHARACTERISTICS – FFVI/FFWI POLYPROPYLENE DIELECTRIC
