DC COMPONENTS CO., LTD.
R
KBPC
MB
35005
3505
THRU
KBPC
3510
MB
3510
RECTIFIER SPECIALISTS
TECHNICAL SPECIFICATIONS OF SINGLE-PHASE SILICON BRIDGE RECTIFIER
VOLTAGE RANGE - 50 to 1000 Volts
CURRENT - 35 Amperes
FEATURES
* Metal case for Maximum Heat Dissipation
* Surge overload ratings-400 Amperes
* Low forward voltage drop
MB-25
TYP
MECHANICAL DATA
* Case: Metal, electrically isolated
* Epoxy: UL 94V-0 rate flame retardant
* Terminals: Plated .25"(6.35mm) Faston lugs, solderable per
MIL-STD-202E, Method 208 guaranteed
* Polarity: As marked
* Mounting position: Any
* Weight: 30 grams
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Dimensions in inches and (millimeters)
o
KBPC
35005
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Bridge Input Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Output Current at Tc = 55
o
C
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC Method)
Maximum Forward Voltage Drop per element at 17.5A DC
Maximum DC Reverse Current at Rated
DC Blocking Voltage per element
I
2
t Rating for Fusing (t<8.3ms)
Typical Junction Capacitance ( Note1)
Typical Thermal Resistance (Note 2)
Operating and Storage Temperature Range
NOTES : 1.Measured at 1 MH
Z
and applied reverse voltage of 4.0 volts
2. Thermal Resistance from Junction to Case per leg.
@T
A
= 25
o
C
@T
A
= 100
o
C
SYMBOL
V
RRM
V
RMS
V
DC
I
O
I
FSM
V
F
I
R
I
2
t
C
J
RθJ C
T
J,
T
STG
MB3505
50
35
50
KBPC
3501
MB351
100
70
100
KBPC
3502
MB352
200
140
200
KBPC
3504
MB354
400
280
400
35
400
1.1
10
500
664
300
2.2
-55 to + 150
KBPC
3506
MB356
600
420
600
KBPC
3508
MB358
800
560
800
KBPC
3510
MB3510 UNITS
1000
700
1000
Volts
Volts
Volts
Amps
Amps
Volts
uAmps
A
2
Sec
pF
0
C/W
C
0
268
