NT
Features
■
RoHS compliant*
■
2/4 isolated resistors in an 0404/0804 size
■
■
■
■
■
Paper tape on reel for automatic placement
*R
oH
S
CO
M
PL
IA
package
E24 series from 10 ohms to 1 megohm
Convex termination style
Resistance tolerance ±5 %
Suitable for all types of soldering processes
Model CAY10 - Chip Resistor Array
Specifications
Requirement
Short Time Overload
Soldering Heat
Temperature Cycling (5)
Moisture Load Life
Load Life
Characteristics
Characteristics
Number of Elements (Isolated)
Power Rating @ 70 °C per Resistor
Package Power Rating @ 70 °C
Resistance Tolerance
Resistance Range (E24)
plus Zero-ohm Jumper
T.C.R.
Max. Overload Voltage
Max. Working Voltage
Operating Temp. Range
Rating Temperature
Packaging
CAY10-xxxJ2
2
0.0625 W
0.125 W
±5 %
10 ohms - 1 megohm
±250 ppm/°C
50 V
25 V
-55 °C to +125 °C
+70 °C
10,000 pieces per reel
CAY10-xxxJ4
4
0.0625 W
0.250 W
Characteristics
±2 %
±1 %
±1 %
±3 %
±3 %
Test Method
Rated Voltage X 2.5, 5 seconds
260 °C ±5 °C, 10 seconds ±1 second
125 °C (30 minutes) - normal (15 minutes)
-30 °C (30 minutes) - normal (15 minutes)
1000 hours
1000 hours
How To Order
CA Y 10 - 103 J 4 LF
Chip Arrays
Type
• Y = Convex
Model
• 10 = 04 Package Width
Resistance Code
• <10 ohms: “R” represents decimal
point (example: 4R7 = 4.7 ohms).
• ≥10 ohms: First two digits are signifi-
cant, third digit represents number of
zeros to follow (example: 474 = 470k
ohms
• 000 = Zero-ohm Jumper
Resistance Tolerance
• J = ±5 %
Resistors
• 2 = 2 Resistors
• 4 = 4 Resistors
Terminations
• LF = Tin-plated (RoHS compliant)
For Standard Values Used in Capacitors,
Inductors, and Resistors,
click here.
Characteristics
Protective
Glass Overcoat
Derating Curve
100
Rated Load (%)
70
°C
125
°C
Isolated Circuit
CAY10-xxxJ2
4
3
Thick Film
Resistive Element
80
60
40
20
0
-55
40 60 80
Ambient Temp. (˚C)
100 120 140 160
R
R
1
2
CAY10-xxxJ4
Typical Part Marking
Termination
High Purity
Alumina
Substrate
8
7
6
5
None on part. Label on reel will include
part number.
1
R
R
R
R
2
3
4
*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
Model CAY10 - Chip Resistor Array
Soldering Profile for RoHS Compliant Chip Resistors and Arrays
275
<1>
Maximum of 20 seconds between
260 °C peak
<1>
255 °C
+255 °C and +260 °C
225
220 °C
Temperature (°C)
190 °C
175
150 °C
60 - 90
seconds
Ramp Down
6 °C/second
125
60 - 120 seconds
10 seconds minimum
75
Ramp Up
3 °C/second maximum
25
0
50
100
150
Time (seconds)
200
250
300
Product Dimensions
CAY10-xxxJ4
0.40
±
0.15
(.016
±
.006)
CAY10-xxxJ2
0.33
±
0.10
(.013
±
.004)
0.15
±
0.10
(.006
±
.004)
1.0
±
0.10
(.040
±.004)
0.25
±
0.10
(.010
±
.004)
0.15
±
0.10
(.006
±
.004)
1.0
±
0.10
(.040
±.004)
0.25
±
0.10
(.010
±
.004)
0.5
±
0.05
(.020
±
.002)
2.0
±
0.10
(.079
±
.004)
0.30
±
0.15
(.012
±
.006)
0.35
±
0.10
(.014
±
.004)
0.67
±
0.10
(.026
±
.004)
0.35
±
0.10
(.014
±
.004)
1.0
±
0.10
(.040
±
.004)
Land Pattern
CAY10-xxxJ4
0.50
(.020)
0.50
(.020)
1.50
(.059)
0.50
(.020)
CAY10-xxxJ2
0.65
(.026)
0.50
(.020)
1.50
(.059)
0.40
(.016)
0.30
(.012)
DIMENSIONS:
MM
(INCHES)
0.35
(.014)
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
Model CAY10 - Chip Resistor Array
Packaging Dimensions
0.45
±
.010
MAX.
(.018
±
.004)
DIA.
1.50
±
.010
(.059 + .004)
4.00
±
0.10
(.157
±
.004)
1.75
±
0.10
(.069
±
.004)
2.0
±
0.5
(.079
±
.020)
13.0
±
0.2
(.511
±
.008)
CAY10-xxxJ2: 1.20
±
0.10
(.047
±
.004)
3.50
±
0.05
(.138
±
.002)
8.00
±
0.20
(.315
±
.008)
2.00
±
0.10
(.079
±
.004)
21.0
±
0.8
(.827
±
.031)
60
(2.362)
CAY10-xxxJ4: 2.20
±
0.10
(.087
±
.004)
1.0
1.20
±
0.10
MAX.
(.040)
(.047
±
.004)
9.0
±
0.3
(.354
±
.012)
11.4
±
1.0
(.449
±
.040)
180
(7.087)
DIMENSIONS:
MM
(INCHES)
REV. 01/15
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
