SHANGHAI SUNRISE ELECTRONICS CO., LTD.
KBPC15005 THRU KBPC1510
SINGLE PHASE SILICON
BRIDGE RECTIFIER
VOLTAGE: 50 TO 1000V CURRENT: 15A
FEATURES
• Surge overload rating: 300A peak
• High case dielectric strength
• 1/4" universal fasten terminal
• and
φ.04"
lead - wire available
• High temperature soldering guaranteed:
250
o
C/10sec/0.375"(9.5mm) lead length
at 5 lbs tension
TECHNICAL
SPECIFICATION
KBPC15
KBPC15W
MECHANICAL DATA
• Polarity: Polarity symbol marked on body
• Mounting position: Hole thru for #8 screw
• Case: metal or plastic
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(Single-phase, half-wave, 60Hz, resistive or inductive load rating at 25
o
C, unless otherwise stated, for capacitive load,
derate current by 20%)
RATINGS
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
(T
c
=55
o
C)
Peak Forward Surge Current (8.3ms single
half sine-wave superimposed on rated load)
Maximum Instantaneous Forward Voltage
(at forward current 7.5A DC)
Maximum DC Reverse Current
T
a
=25
o
C
(at rated DC blocking voltage)
T
a
=100
o
C
Storage and Operating Junction Temperature
Note:
Suffix "W" for wire type
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
T
STG
,T
J
KBPC KBPC KBPC KBPC KBPC KBPC KBPC
15005 1501 1502 1504 1506 1508 1510
50
100
200
400
600
800
1000
35
70
140
280
420
560
700
50
100
200
400
600
800
1000
15
300
1.1
10.0
500
-55 to +150
UNITS
V
V
V
A
A
V
µA
µA
o
C
http://www.sse-diode.com
