SSP1A110M7T

Description
Solid State Relays - Industrial Mount SSR 1P 10A@300VAC ZC 90-280VDC IN W
CategoryTopical application    Mechanical and electrical/engineering/automation
File Size81KB,4 Pages
ManufacturerSCHNEIDER ELECTRIC
Download Datasheet Parametric View All

SSP1A110M7T Online Shopping

Suppliers Part Number Price MOQ In stock
SSP1A110M7T - - View Buy Now

SSP1A110M7T Overview

Solid State Relays - Industrial Mount SSR 1P 10A@300VAC ZC 90-280VDC IN W

SSP1A110M7T Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerSCHNEIDER ELECTRIC
Product CategorySolid State Relays - Industrial Mount
ProductSSR - Solid State Relays
Factory Pack Quantity1
Product data sheet
Characteristics
SSP1A110M7T
solid state relay-panel mount-thermal pad-input
90-280VAC,output 24-300V AC,10 A
Main
Range of product
Product or component type
Provided equipment
Device short name
Mounting support
Network number of phases
Contacts type and composition
[In] rated current
Solid state output type
Zelio Relay
Solid state relay
Thermal pad
SSP1
Panel
1 phase
1 NO
10 A
Zero voltage switching
SCR output
Complementary
[Uc] control circuit voltage
Minimum switching voltage
Maximum switching voltage
Response time
Input current limits
Output voltage
Load current
Absolute maximum voltage
Surge current
Maximum I²t for fusing
Protection device type
Leakage current
Voltage drop
Feb 17, 2018
90...280 V AC
90 V AC turn-on
10 V AC turn-off
30 ms turn-off
25 ms turn-on
5...10 mA
24...300 V AC
0.15...10 A
600 V
<= 120 A for 16.6 ms
60 A².s for 8.33 ms at 60 Hz half cycle
66 A².s for 10 ms at 50 Hz half cycle
Type 1 - 13 A miniature circuit breaker (MCB) - curve B
Type 2 - 10 A miniature circuit breaker (MCB) - curve B
<= 1 mA off-state
1.15 V on-state
1
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
