ADSP-3221TG/883B datasheet, PDF

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> ADSP-3221TG/883B

ADSP-3221TG/883B: Description32-BIT, DSP-FLOATING POINT PROCESSOR, CPGA144, CERAMIC, PGA-144; CategoryThe embedded processor and controller Microcontrollers and processors; File Size3MB，47 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

ADSP-3221TG/883B Overview

32-BIT, DSP-FLOATING POINT PROCESSOR, CPGA144, CERAMIC, PGA-144

ADSP-3221TG/883B Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Parts packaging code	PGA
package instruction	PGA,
Contacts	144
Reach Compliance Code	unknow
boundary scan	NO
maximum clock frequency	8 MHz
External data bus width	32
JESD-30 code	S-CPGA-P144
JESD-609 code	e0
length	40 mm
low power mode	NO
Humidity sensitivity level	NOT SPECIFIED
Number of terminals	144
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Output data bus width	32
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	PGA
Package shape	SQUARE
Package form	GRID ARRAY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	MILITARY
Maximum seat height	4.19 mm
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	NO
technology	CMOS
Temperature level	MILITARY
Terminal surface	TIN LEAD
Terminal form	PIN/PEG
Terminal pitch	2.54 mm
Terminal location	PERPENDICULAR
Maximum time at peak reflow temperature	NOT SPECIFIED
width	40 mm
uPs/uCs/peripheral integrated circuit type	DSP PERIPHERAL, FLOATING POINT PROCESSOR
Base Number Matches	1
