PIN
RECEPTACLES
FOR .015” - .025” DIAMETER PINS
1707
.072 DIA.
.064 DIA.
.054 DIA.
1707-0-19-XX-30-XX-10-0
0240
Press-fit in .061 mounting hole
Wire Crimp Termination. Accepts wire
sizes 22 AWG Max. / 24 AWG Min.
.031
.028 .086
.150
0240-0-15-XX-30-XX-04-0
Press-fit in .059 mounting hole
0307
0307-0-15-XX-30-XX-04-0
Press-fit in .059 mounting hole
1753
1753-0-15-XX-30-XX-04-0
Press-fit in .057 mounting hole
.600
.040 DIA.
HOLE
.200
1705/1706/1762
17XX-0-15-XX-3X-XX-04-0
Press-fit in .057 mounting hole
0672
Basic Part
Number
Height
A
0672-X-15-XX-30-XX-10-0
Swage mount in .049 hole
Basic Part
Number
.053 DIA.
.070 DIA.
.045 DIA.
.086
.105
.135
Board
Thickness
Length
V
1705-0
1706-0
1762-0
.165
.218
.300
V
.035 DIA.
HOLE
0672-1
0672-2
0672-3
0672-4
.031
.062
.094
.125
.052
.084
.115
.146
1024/1104
1XX4-0-18-XX-30-XX-10-0
Press-fit in .059 mounting hole
Accepts wire sizes up to .028” dia.
0498
Basic Part
Number
Length
L
0498-0-15-XX-35-XX-04-0
Press-fit in .057 mounting hole
8131
8131-0-15-XX-30-XX-10-0
Press-fit in .057 mounting hole
1024-0
1104-0
.290
.450
PAGE 168 | PIN RECEPTACLES
SPECIFICATIONS:
Shell Material:
Brass Alloy 360, 1/2 Hard
Contact Material:
Beryllium Copper Alloy 172, HT
Dimensions: Inches
Tolerances On:
Lengths:
± .005
2011/65/EU
ORDER CODE: XXXX - X - 1X - XX -
XX
- XX - XX - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
200
μ”
TIN/LEAD OVER NICKEL
80
200
μ”
TIN OVER NICKEL (RoHS)
15
10
μ”
GOLD OVER NICKEL (RoHS)
SPECIFY CONTACT FINISH:
02
100
μ”
TIN/LEAD OVER NICKEL
84
100
μ”
TIN OVER NICKEL (RoHS)
27
30
μ”
GOLD OVER NICKEL (RoHS)
Diameters: ± .002
Angles:
±2°
RoHS - 2
SELECT CONTACT:
#30 or #35
CONTACT (DATA ON PAGE 253 & 254)
(For alternate contact choices, see groups B and C on page 248)
