S
NAP
A
CTION
S
WITCHES
S
UB
-M
INIATURE
8
AMP
D
OUBLE
P
OLE
S
NAP
A
CTION
S
WITCHES
This unique design has a DPDT-DB (Form ZZ)
contact arrangement, or can be wired externally
to provide two commons to form standard DPDT
(Form CC) circuitry. This switch can control up to
4 isolated circuits.
A
PPLICATIONS
•
•
•
•
•
Aircraft rotary actuator
Aircraft valve actuator
Circuit breakers
Aircraft contractors
Industrial machinery
K
EY
F
EATURES
:
•
Gold or silver contacts
•
Meets MIL-PRF-8805/77
•
End or side terminals available
•
UL recognized and CSA certified:
8 amps @ 125/250 VAC
•
Roller lever, lever, short roller lever
and bushing mount actuator are
available
A
CTUAL
S
IZE
A
CTUAL
S
IZE
O
RDERING
I
NFORMATION
:
Switches
Part Number
26-804
26-888051
26-904
26-988051
Simultaneity
Simultaneous*
Ref. M8805/77-001
Simultaneous*
Ref. M8805/77-002
Contacts
Silver**
Gold Plated
Silver**
Gold Plated
Terminals
End Solder
End Solder
Side Solder
Side Solder
RoHS Compliant
—
—
* Within .004" of plunger travel.
** For electrical loads under 250 mA, consult factory.
Actuator
(see page 72 for additional specifications)
Part Number
76-1200
Roller Lever
76-1210
Lever
76-1220
Short Roller Lever
76-22604
Bushing Mount
Switch Series
26
26
26
16
Oper. Force
8 oz max
7 oz max
16 oz max
5 oz
Release Force
l 1/2 oz min
2 oz min
5 oz min
—
Pretravel
.130 max
.155 max
.050 max
.050 max
Overtravel
.026 min
.025 min
.012 min
.156 min
Movement Diff.
.054 ± .022
.065 max
.020 ± .010 - .005
—
S
TANDARDS
/ A
GENCY
/ R
ATINGS
:
®
RoHS
COMPLIANT
2002 / 95 / EC
V
D E
IEC
IP67
COMPLIANT
www.itwswitches.com
60
Contact an Authorized Distributor or Factory for Pricing
S
ERIES
26: S
UB
-M
INIATURE
8
AMP
D
OUBLE
P
OLE
E
ND
S
OLDER
S
NAP
A
CTION
S
WITCHES
M
ECHANICAL
/ E
LECTRICAL
C
HARACTERISTICS
:
Pretravel:
0.050 inches (Max)
Overtravel:
0.012 inches (Min)
Operating Force:
12 ± 4 oz
Release Force:
5 oz (Min)
Movement Differential:
0.020 inches ± .010 / .005
Operating Point:
0.396 inches ± .015
(from mounting hole centers)
Circuit:
DPDT-DB (Form ZZ)
Temperature Index:
To 275°F Ambient
MIL-PRF-8805/7 QPL listed:
26-888051 M8805/77-001
26-988051 M8805/77-002
S
IDE
S
OLDER
Electrical Ratings:
Circuitry Current Voltage
DPDT-DB 8 Amps 125/250 VAC 75-80% PF
(Form ZZ) 5 Amps 28 VDC
Copyright © 2011 ITW Switches 2011
Designs and specifications are subject to change
without notice due to product improvement.
61
800.544.3354
A
CTUATORS
S
EE
P
AGE
60 & 62
FOR
S
WITCHES
K
EY
F
EATURES
:
•
Roller Lever
•
Lever
•
Short Roller Lever
•
Bushing Mount
M
ECHANICAL
C
HARACTERISTICS
:
Part Number
76-1200
Roller Lever
76-1210
Lever
76-1220
Short Roller Lever
76-22604
Bushing Mount
Switch Series
26
26
26
16
Oper. Force
8 oz max
7 oz max
16 oz max
5 oz
Release Force
1.5 oz min
2 oz min
5 oz min
—
Pretravel
.130 max
.155 max
.050 max
.050 max
Overtravel
.026 min
.025 min
.012 min
.156 min
Movement Diff.
.054 ± .022
.065 max
.010 ± .005
—
Notes: (1) Characteristics may vary depending on type of basic switch used in assembly.
(2) All actuators supplied with mounting hardware.
76-1200
76-1220
76-1210
76-22604
Copyright © 2011 ITW Switches 2011
www.itwswitches.com
72
Designs and specifications are subject to
change without notice due to product improvement.
