SHEET 1 OF 1
5.08
[.200 in]
12.70
[.500 in]
3.81
[.150 in]
n
1.85
[.073 in]
TYP.
5.08
[.200 in]
1.22
[.048 in]
12.70
[.500 in]
6.86
[.270 in]
ISOMETRIC
2.69
[.106 in]
3.17
[.125 in]
6.10
[.240 in]
POS. 1
n
6.35
[.250 in]
KEYWAY
2.54
[.100 in]
5.08
[.200 in]
RECOMENDED PC MOUNTING
.52
[.020 in]
.85
[.033 in]
POS. 2
n
6.35
[.250 in]
Without Locking
Ring
n
2.38
[.094 in]
With Standard
Locking Ring
12.30
[.484 in]
1/4-40 UNS
THREADS
.50
[.020 in]
7.55
[.297 in]
PANEL
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
2
1.44
[.057 in]
ON
2-3
OFF
OPEN
ON
2-1
1
3
12.70
[.500 in]
E-SWITCH
LOGO ON
OPPOSITE SIDE
1
2
3.81
[.150 in]
3
3.18
[.125 in]
.76
[.030 in]
1.27
[.050 in]
EPOXY
SEAL
3
.51
[.020 in]
RATING
8.84
[.348 in]
CIRCUIT: SPDT
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=±0.4
X.XX=±0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. PLATING MATERIAL: GOLD
5. RATING: 0.4 (VA) @20V (AC or DC)
6. CONTACT RESISTANCE: 10 Milli-OHMS MAX.
7. ELECTRIC LIFE: 40,000 make-and-break cycles
at full load.
8. INSULATION RESISTANCE: 1,000 Mega-ohm min.
9. DIELECTRIC STRENGTH: 1,000 V RMS @sea level.
10. OPERATING TEMP.: -30°C to 85°C
11.
DENOTES CRITICAL PARAMETER.
12. 2002/95/EC (ROHS) COMPLIANT
13. HARDWARE TO BE SHIPPED BULK
T100000 - HEXNUT - QTY 2
T100011 - LOCKWASHER - QTY 1
T100015 - LOCKRING - QTY 1
A
REV
18975
PCR NO
Released For Production
DESCRIPTION
3/30/10
DATE
BLR
BY
TITLE
100SP3T6B11M7REH
DATE
DR
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
SCALE
2:1
DWG
REV
3/30/2010
BLR
ST113074
A
