www.murata-ps.com
SELECTION GUIDE
Order Code
30800AC
30101AC
30151AC
30201AC
3000A Series
Surface Mount Power Inductor
Inductance (1MHz, 0.1V)
Typ. @ I
DC
±20%
nH
nH
80
97
145
191
82
105
120
162
I
DC3
Typ.
A
37
36
29
22
I
SAT
(Typ.)
4
25ÚC
100ÚC
A
A
57
48
33
24
47
41
29
22
DC Resistance
Typ.
Max.
mΩ
mΩ
0.19
0.20
0.19
0.21
0.35
0.35
0.35
0.35
FEATURES
Low-profile surface-mount design
Inductance Range from 80nH to 200nH
Rated current up to 57A
pk
Materials meet UL94V-0
Custom inductance values available
RoHS compliant
J-STD-020 D.1 reflow
ABSOLUTE MAXIMUM RATINGS
Operating temperature range
Storage temperature range
SOLDERING INFORMATION
1
Peak reflow solder temperature
Pin finish
Moisture sensitivity level
2
-40°C to +130°C
-40°C to +155°C
250°C
SAC305
1
Mechanical Dimensions
Mechanical Dimensions
7.10 (0.280) Max.
PRODUCT OVERVIEW
The 3000A series are a range of high-current,
surface-mount bead inductors, suited to a variety
of applications. The products are designed for
noise suppression in high-frequency, high-current
switching power supplies, DC-DC converters,
DC-AC inverters and VRMs.
Weight Typ. = 0.94g
7.00 (0.276) Max.
1.52 (0.060)
4.96 (0.195) Max.
2.48 (0.098)
Recommended Pad Layout
2.03
(0.080)
2.03
(0.080)
3.05 (0.120)
3.3 (0.130)
Unless otherwise stated, all dimensions in mm (inches) ± 0.25 (0.010).
Specifications typical at T
A
= 25°C
1 For further information, please visit www.murata-ps.com/rohs
2 Representative samples of the product were subjected to the conditioning described in IPC/JEDEC J-STD-020D and passed electrical
testing, package coplanarity and visual inspection which revealed no external cracks or changes in package body flatness.
3 I
DC
is the value at which the inductance falls to 80% of its nominal value or when its temperature reaches 40ÚC, which ever is sooner.
4 I
SAT
is the value at which the inductance falls to 80% of its nominal value.
For full details go to
www.murata-ps.com/rohs
www.murata-ps.com/support
3000A_A02
Page 1 of 3
3000A Series
Surface Mount Power Inductor
INDUCTANCE Vs CURRENT
3000A Series Inductance Vs Current
1000
200nH
100
150nH
Inductance, L (nH)
100nH
80nH
10
1
1
10
Current, IDC (A)
TEMPERATURE Vs CURRENT
3000A Temperature Vs Current
50
Temperature rise above ambient, t (ºC)
40
30
20
10
0
0
5
10
15
20
25
30
80
15
nH
0n
H
20
0n
H
35
40
Current, I DC (A)
INDUCTANCE Vs FREQUENCY
3000A Series Inductance Vs Frequency
1000
100
Inductance, L (nH)
100nH
10
10
0n
H
150nH
80nH
1
200nH
0.1
10
100
1000
Frequency, (MHz)
www.murata-ps.com/support
3000A_A02
Page 2 of 3
3000A Series
Surface Mount Power Inductor
PACKAGE SPECIFICATIONS
Reel Dimensions
(
0.63
+0.02
)
-0
Ø300 (11.81) Max.
Ø100
49.75 (1.96) Min.
13.50 0.531
Ø
12.50 0.492
16±
(???-?
16
+0.5
-0
Ø
Leader Section
400 (15.748) Min.
100 (3.937)
Min.
2.3±0.5 (0.09±0.02) Min.
22.4
(0.882)
Max.
†
22.4
(0.882)
Max.
†
Goods
Enclosure
Section
16.4-16.6
(0.646-0.654)
†
Trailer Section
160 (6.299) Min.
Ø21.1 (Ø0.83) Min.
Reel Dimensions
1.75
(0.069)
12.00
(0.472)
4.00
(0.157)
Ø1.50
(0.059)
0.40
(0.016)
24.00
(0.945)
11.50
(0.453)
A
A
Direction of unreeling
5.20
(0.205)
Murata Power Solutions, Inc.
11 Cabot Boulevard, Mansfield, MA 02048-1151 U.S.A.
ISO 9001 and 14001 REGISTERED
Murata Power Solutions, Inc. makes no representation that the use of its products in the circuits described herein, or the use of other
technical information contained herein, will not infringe upon existing or future patent rights. The descriptions contained herein do not imply
the granting of licenses to make, use, or sell equipment constructed in accordance therewith. Specifications are subject to change without
notice.
© 2013 Murata Power Solutions, Inc.
www.murata-ps.com/support
3000A_A02
Page 3 of 3
