ALUMINUM ELECTROLYTIC CAPACITORS
UES
Bi-Polarized, For Audio Equipment
Bi-polarized “nichicon MUSE” acoustic series.
Suited for audio signal circuits.
Compliant to the RoHS directive (2011/65/EU).
UES
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle (tan
δ)
Bi-polarized
UFW
Performance Characteristics
– 40 to +85°C
6.3 to 50V
1 to 1000µF
± 20% at 120Hz, 20°C
After 1 minute's application of rated voltage at 20°C, leakage current is not more than 0.03CV or 3 (µA), whichever is greater.
Measurement frequency : 120Hz at 20°C
Rated voltage (V)
tan
δ
(MAX.)
6.3
0.24
10
0.20
6.3
4
8
16
0.16
10
3
6
16
2
4
25
0.16
25
2
4
35
0.14
35
2
4
50
0.12
50
2
4
Measurement frequency : 120Hz
Stability at Low Temperature
Rated voltage (V)
Impedance ratio
ZT / Z20 (MAX.)
Z– 25°C / Z+20°C
Z– 40°C / Z+20°C
Endurance
The specifications listed at right shall be met when the
capacitors are restored to 20
°C
after the rated voltage
is applied for 1000 hours at 85
°C
with the polarity
inverted every 250 hours.
Capacitance change
tan
δ
Leakage current
Within ±20% of the initial capacitance value
150% or less than the initial specified value
Less than or equal to the initial specified value
Shelf Life
Marking
After storing the capacitors under no load at 85°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4 clause
4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.
Printed with black color letter on clear green sleeve.
Radial Lead Type
Sleeve (P.E.T.)
φ
d
Type numbering system (Example : 10V 47
µ
F)
1
2
3
4
5
6
7
8
9 10
11
UE S 1 A 4 7 0 MEM
φD
+
0.5 MAX.
P ±
0.5
Configuration
Capacitance tolerance (±20%)
φD
5
6.3
8 · 10
Code
DM
EM
Pressure
relief vent
(φ6.3up)
L+
MAX.
(mm)
Rated capacitance (47µF)
Rated voltage (10V)
Series name
Type
φD
15
MIN
4
MIN
5
6.3
8
10 12.5 16
P
φd
2.0 2.5 3.5 5.0 5.0 7.5
0.6 0.6 0.6 0.6 0.8 0.8
(φD < 10) 1.0
(φD 10) 1.5
PM
12.5 · 16 HM
•
Please refer to page 20 about the end seal
configuration.
Dimensions
V
Cap.(µF)
Code
φ
D
×
L (mm)
6.3
0J
10
1A
16
1C
25
1E
35
1V
50
1H
5
×
11
5
×
11
5
×
11
6.3
×
11
8
×
11.5
10
×
12.5
10
×
16
10
×
20
12.5
×
25
16
×
25
16
×
31.5
1
2.2
3.3
4.7
10
22
33
47
100
220
330
470
1000
010
2R2
3R3
4R7
100
220
330
470
101
221
331
471
102
5
×
11
6.3
×
11
8
×
11.5
10
×
12.5
10
×
16
10
×
20
12.5
×
25
5
×
11
6.3
×
11
6.3
×
11
10
×
12.5
10
×
16
10
×
20
12.5
×
20
16
×
25
5
×
11
6.3
×
11
6.3
×
11
8
×
11.5
10
×
12.5
10
×
20
12.5
×
20
12.5
×
25
16
×
25
5
×
11
5
×
11
6.3
×
11
8
×
11.5
10
×
12.5
10
×
16
12.5
×
25
12.5
×
25
16
×
25
16
×
31.5
5
×
11
6.3
×
11
8
×
11.5
10
×
12.5
10
×
12.5
10
×
20
12.5
×
25
16
×
25
16
×
25
Please refer to page 20, 21, 22 about the formed or taped product spec.
Please refer to page 4 for the minimum order quantity.
283
