Border Cap
®
Single Layer Capacitor
Description
SLC with recessed metallization, available with
borders on one or both sides.
Recessed metallization have been designed
to minimize the potential of shorting during
attachment (epoxy or solder).
l
Available from 0.03pF to 2400pF
l
Operating frequency up to 100GHz
l
Wire Bondable:
100µ” Au with a Ni Barrier Layer
l
25, 50 and 100 Volt options
l
Customized designs are available, please
contact sales office
Applications
l
DC Blocking
l
RF Bypassing
l
Filtering
l
Tuning
Test Level Codes
Commercial Level
Y
X
1% AQL 2-Side Visual
100% 4-Side Visual
1% AQL Electrical (CAP/DF/IR & DWV)
l
Coupling
Benefits
l
Eliminates rollback and burrs
l
Improved vision recognition
l
Tighter control on dimensions
l
Facilitates pick and place – thus reducing
High Reliability
MIL-PRF-49464 Group A
A
• 100% Thermal Shock
• 100% Voltage Conditioning
• 100% Electrical (CAP/DF/IR & DWV)
• 100% 6-Side Visual
• Bond Strength
• Die Shear
• Temperature Coefficient
B
MIL-PRF-49464 Group B
• MIL-PRF-49464 Group A
• Immersion
• Low Voltage Humidity
• Life
• Customer Defined
• 6-Side Visual
handling damage
Border Cap
®
D
E
Configuration B
Tolerance
Code
Description
± 0.05pF
± 0.1pF
± 0.25pF
± 0.50pF
± 10%
± 15%
± 20%
GMV (Guarantee Minimum Value)
+80%, -20%
Voltage
Code
Voltage
25 Volts
50 Volts
100 Volts
Double
Border Cap
®
A
B
C
D
K
L
M
X
Z
2
5
1
Configuration E
Configuration
Code
Description
Single-Sided
Double-Sided
B
E
Border Caps need to have a tolerance that is effectively 10%.
Part Number Identification
D
Product
D = Border
Cap
®
www.dilabs.com
K
Tolerance
A = ± 0.05pF
B = ± 0.10pF
C = ± 0.25pF
D = ± 0.5pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
L = ± 15%
M = ± 20%
Z = +80% -20%
10
Case
Size
10
12
15
20
25
30
35
40
50
BN
See material
tables.
100
Capacitance
(pF)
R02 = 0.02pF
0R5 = 0.5pF
1R0 = 1.0pF
5R1 = 5.1pF
100 = 10pF
101 = 100pF
152 = 1500pF
Refer to
Capacitance
range tables for
available values.
Consult an inside
sales rep. for
custom solutions.
1
Voltage
2 = 25V*
1 = 100V
*For
capacitors
with UX
material only
E
Termination
P = Ni / Au
B = Single
X
Test Level
Y, X, A, B,
D and E.
See test level
definitions.
Material
Border
E = Double
Border
M = Au
*For
capacitors
with UX
material only
Packaging
D = Black Dotted
E = Repopulated
T = Tape and
Reel
Leave blank for
generic waffle
pack.
North America
Knowles (Cazenovia)
Phone: +1 315 655 8710
KCCSales@knowles.com
Europe
Knowles (UK) Ltd
Phone: +44 1603 723300
SyferSales@knowles.com
Far East
Knowles Capacitors
Phone: +86 512 62588258-6243
KCAsiaSales@knowles.com
10334-3/17
Dimensions
Style
Length / Width
0.010” ±0.001” (0.254mm ±0.025)
0.012” ±0.001” (0.305mm ±0.025)
0.015” ±0.001” (0.381mm ±0.025)
0.020” ±0.001” (0.508mm ±0.025)
0.025” ±0.001” (0.635mm ±0.025)
0.030” ±0.001” (0.762mm ±0.025)
0.035” ±0.001” (0.889mm ±0.025)
0.040” ±0.001” (1.016mm ±0.025)
0.012” ±0.001” (1.27mm ±0.025)
Pad Size
0.008” (0.203mm)
0.010” (0.254mm)
0.011” (0.279mm)
0.016” (0.406mm)
0.021” (0.533mm)
0.026” (0.660mm)
0.031” (0.787mm)
0.036” (0.914mm)
0.046” (1.168mm)
Border
0.001” (0.025mm)
0.001” (0.025mm)
0.002” (0.051mm)
0.002” (0.051mm)
0.002” (0.051mm)
0.002” (0.051mm)
0.002” (0.051mm)
0.002” (0.051mm)
0.002” (0.051mm)
Thickness
0.006” ±0.0025” (0.152mm ± 0.064mm)
0.006” ±0.0025” (0.152mm ± 0.064mm)
0.006” ±0.0025” (0.152mm ± 0.064mm)
0.006” ±0.0025” (0.152mm ± 0.064mm)
0.006” ±0.0025” (0.152mm ± 0.064mm)
0.006” ±0.0025” (0.152mm ± 0.064mm)
0.006” ±0.0025” (0.152mm ± 0.064mm)
0.006” ±0.0025” (0.152mm ± 0.064mm)
0.006” ±0.0025” (0.152mm ± 0.064mm)
D10
D12
D15
D20
D25
D30
D35
D40
D50
W
T
L
P
B
B
*UX material available in 25V (0.006” Thick) and 50V (0.010” Thick)
Capacitance values - Single-Sided
Style
MATERIAL
MIN.
D10
MAX.
TOL.
MIN.
D12
MAX.
TOL.
MIN.
D15
MAX.
TOL.
MIN.
D20
MAX.
TOL.
MIN.
D25
CAPACITANCE (pF)
MAX.
TOL.
MIN.
D30
MAX.
TOL.
MIN.
D35
MAX.
TOL.
MIN.
D40
MAX.
TOL.
MIN.
D50
MAX.
TOL.
PI
PG
AH
CF
NA
CD
CG
DB
NP
NR
NS
NU
NV
BD
BC
BE
BL
BJ
BN
BU
BV
UX
0.03
0.04
0.06
0.07
0.07
0.15
0.25
0.25
0.25
0.5
0.9
1.8
2.7
2.2
3.9
3.6
6.2
10
13
27
39
82
0.05
0.06
0.1
0.1
0.1
0.15
0.35
0.35
0.4
0.8
1.5
3
4.3
3.3
6.2
6.2
10
16
22
43
68
100
P,K
P,K
P,K
P,K
P,K
A,K
A,K
A,K
A,K
B,K
C,K
D,K
D,K
K
K
K
K,M
K
K,M
M
M
M
0.05
0.06
0.09
0.1
0.15
0.2
0.3
0.35
0.4
0.7
1.3
2.7
3.9
3
5.6
5.6
9.1
15
20
36
62
120
0.07
0.09
0.1
0.15
0.15
0.25
0.5
0.5
0.6
1.1
2.2
4.3
6.2
5.1
9.1
9.1
13
24
33
62
100
140
P,K
P,K
P,K
P,K
A,K
A,K
A,K
A,K
B,K
B,K
C,K
D,K
K
K
K
K
K,M
K
K,M
M
M
M
0.06
0.08
0.15
0.15
0.15
0.25
0.45
0.45
0.55
1
1.9
3.9
5.6
4.3
8.2
8.2
13
20
30
56
82
100
0.09
0.1
0.2
0.2
0.2
0.35
0.7
0.7
0.85
1.6
3
5.6
8.2
6.8
13
12
20
33
43
82
130
200
P,K
P,K
A,K
A,K
A,K
A,K
B,K
B,K
B,K
C,K
D,K
K
K
K
K
K
K,M
K
K,M
M
M
M
0.15
0.15
0.25
0.25
0.25
0.45
0.8
0.8
0.95
1.8
3.6
6.8
10
8.2
15
15
24
39
51
100
150
200
0.15
0.2
0.35
0.45
0.45
0.7
1.3
1.3
1.6
3
5.6
11
16
13
24
22
36
62
82
160
240
370
A,K
A,K
A,K
A,K
A,K
B,K
C,K
C,K
C,K
D,K
D,K
K
K
K
K
K
K,M
K
K,M
M
M
M
0.2
0.25
0.4
0.45
0.45
0.7
1.3
1.3
1.5
3
5.6
11
16
13
24
24
36
62
82
150
240
300
0.3
0.4
0.6
0.7
0.7
1.1
2
2.2
2.4
4.7
9.1
18
27
20
39
36
56
100
130
240
390
590
A,K
A,K
A,K
B,K
B,K
B,K
C,K
C,K
C,K
D,K
K
K
K
K
K
K
K,M
K
K,M
M
M
M
0.3
0.35
0.55
0.65
0.65
0.95
1.8
1.9
2.2
4.3
8.2
16
24
18
36
33
56
91
120
220
360
450
0.45
0.55
0.9
1
1
1.6
3
3
3.6
6.8
13
27
39
30
56
56
91
150
200
360
560
860
A,K
A,K
B,K
B,K
B,K
C,K
D,K
D,K
D,K
K
K
K
K
K
K
K
K,M
K
K,M
M
M
M
0.35
0.5
0.75
0.8
0.85
1.4
2.7
2.7
3
6.2
11
22
33
27
47
47
75
120
160
300
510
600
0.6
0.8
1.2
1.3
1.5
2.2
4.3
4.3
5.1
10
18
36
56
43
75
75
120
200
270
510
820
1200
A,B,K
B,K
B,K
B,K
C,K
D,K
D,K
D,K
K
K
K
K
K
K
K
K,M
K
K,M
M
M
M
0.5
1
1.1
1.2
1.8
3.3
3.6
4.3
7.5
15
30
43
33
62
62
100
160
220
430
680
800
0.7
0.95
1.4
1.6
1.7
2.7
5.1
5.1
6.2
11
22
43
62
51
91
91
130
240
330
620
1000
1600
A,B,K
B,K
B,K
K
K
K
K
K
K
K
K
K
K
K
K
K
K,M
K
K,M
M
M
M
0.8
1
1.5
1.7
1.8
2.7
5.1
5.6
6.2
12
22
47
68
51
100
91
150
270
330
620
1.1
1.5
2.2
2.4
2.7
4.3
8.2
8.2
10
18
33
68
100
82
150
130
220
390
510
1000
B,K
B,K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K,M
K
K,M
M
M
M
A,B,K 0.65
1000 1500
1200 2400
