194D
www.vishay.com
Vishay Sprague
Solid Tantalum Chip Capacitors,
T
ANTAMOUNT
™, Conformal Coated
FEATURES
• 8 mm, 12 mm, 16 mm tape and reel packaging
available per EIA-481 and reeling per
IEC 60286-3, 7" [178 mm] standard
• Mounting: surface mount
Available
Available
PERFORMANCE CHARACTERISTICS
www.vishay.com/doc?40194
Operating Temperature:
-55 °C to +125 °C
(above 85 °C, voltage derating is required)
Capacitance Range:
0.10 μF to 330 μF
Capacitance Tolerance:
± 10 %, ± 20 % standard
Voltage Rating:
4 V
DC
to 50 V
DC
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
Note
*
This datasheet provides information about parts that are
RoHS-compliant and / or parts that are non RoHS-compliant. For
example, parts with lead (Pb) terminations are not RoHS-compliant.
Please see the information / tables in this datasheet for details
ORDERING INFORMATION
194D
TYPE
225
CAPACITANCE
X0
CAPACITANCE
TOLERANCE
X0 = ± 20 %
X9 = ± 10 %
X5 = ± 5 %
Special order
004
DC VOLTAGE RATING
AT +85 °C
This is expressed in volts.
To complete the
three-digit block, zeros
precede the voltage rating
A
CASE CODE
2
TERMINATION
T
PACKAGING
This is expressed
in picofarads. The
first two digits are
the significant
figures. The third
is the number of
zeros to follow.
See Ratings
and Case
Codes table
2 = gold plated
(50 μ inch minimum)
standard
(RoHS compliant)
8 = 60/40 solder plated
6 = 60/40 solder plated,
fused
7 = hot solder dipped
T = T/R (full reel)
7" [178 mm] reel
standard
H = T/R (half reel)
7" [178 mm]
U = T/R (partial reel)
7" [178 mm]
B = bulk
Note
• Preferred tolerance and reel sizes are in bold.
We reserve the right to supply higher voltage ratings and tighter capacitance tolerance capacitors in the same case size
DIMENSIONS
in inches [millimeters]
Weld and
dimple
projection
identifies
anode (+)
terminal
W
T
1
-
H
L
P
P
T
2
max.
CASE CODE
A
B
C
D
E
F
G
H
W
0.050 ± 0.015
[1.27 ± 0.38]
0.050 ± 0.015
[1.27 ± 0.38]
0.050 ± 0.015
[1.27 ± 0.38]
0.100 ± 0.015
[2.54 ± 0.38]
0.100 ± 0.015
[2.54 ± 0.38]
0.135 ± 0.015
[3.43 ± 0.38]
0.110 ± 0.015
[2.79 ± 0.38]
0.150 ± 0.015
[3.81 ± 0.38]
L
0.100 ± 0.015
[2.54 ± 0.38]
0.150 ± 0.015
[3.81 ± 0.38]
0.200 ± 0.015
[5.08 ± 0.38]
0.150 ± 0.015
[3.81 ± 0.38]
0.200 ± 0.015
[5.08 ± 0.38]
0.220 ± 0.015
[5.59 ± 0.38]
0.265 ± 0.015
[6.73 ± 0.38]
0.285 ± 0.015
[7.24 ± 0.38]
H
0.050 ± 0.015
[1.27 ± 0.38]
0.050 ± 0.015
[1.27 ± 0.38]
0.050 ± 0.015
[1.27 ± 0.38]
0.050 ± 0.015
[1.27 ± 0.38]
0.050 ± 0.015
[1.27 ± 0.38]
0.070 ± 0.015
[1.78 ± 0.38]
0.110 ± 0.015
[2.79 ± 0.38]
0.110 ± 0.015
[2.79 ± 0.38]
P
0.030 ± 0.005
[0.76 ± 0.13]
0.030 ± 0.005
[0.76 ± 0.13]
0.030 ± 0.005
[0.76 ± 0.13]
0.030 ± 0.005
[0.76 ± 0.13]
0.030 ± 0.005
[0.76 ± 0.13]
0.030 ± 0.005
[0.76 ± 0.13]
0.050 ± 0.005
[1.27 ± 0.13]
0.050 ± 0.005
[1.27 ± 0.13]
T
1
0.005
[0.13]
0.005
[0.13]
0.005
[0.13]
0.005
[0.13]
0.005
[0.13]
0.005
[0.13]
0.005
[0.13]
0.005
[0.13]
T
2
MAX.
0.015
[0.38]
0.015
[0.38]
0.015
[0.38]
0.015
[0.38]
0.015
[0.38]
0.015
[0.38]
0.015
[0.38]
0.015
[0.38]
Note
• When solder coated terminations are required, add 0.015" [0.381 mm] to termination dimension tolerances
Revision: 21-Jun-17
Document Number: 40000
1
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
194D
www.vishay.com
Vishay Sprague
RATINGS AND CASE CODES
μF
0.10
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
120
150
220
330
H
H
A
A/B
B
B/C
C/D
D/E
E/F
F
F/G
F/G
H
H
H
A
A/B
A/B
A/B/C
C/D
B/D/E
E/F
F
F/G
F/G
G/H/F
G/H
H
H
A
A/B
A/B
A/B/C
B/C/D
D/E
B/C/E/F
E/F
F/G
F/G
F/G/H
H
G/H
H
H
H
A
A/B
A/B
A/B/C
B/C/D
B/D/E
E/F
E/F
F/G
F/G
F/G/H
G/H
H
H
A
A/B
A/B
B/C
C/D
D/E
E/F
E/F
E/F/G
F/G
G/H
H
A
A/B
B
A/B/C
D
E
E/F
F
F/G
F/G
G/H
G/H
H
4V
6V
10 V
15 V
20 V
25 V
A
35 V
A
A
A
A/B
B
C
D
E
F
F
F/G
G/H
G/H
H
50 V
A
A
B
B
C
D
E
F
F
G
H
H
MARKING AND POLARITY
Conformal coated capacitors have no marking on capacitor body.
Rating and date code information is provided on the reel label.
Negative end cap or termination is identified by black epoxy.
Positive end cap or termination is sealed with pink epoxy, in addition
to the weld projection.
Cathode
termination
Black epoxy
Pink epoxy
Anode
termination
Revision: 21-Jun-17
Document Number: 40000
2
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
194D
www.vishay.com
Vishay Sprague
MAX. DCL
AT +25 °C
(μA)
MAX. DF
AT +25 °C
120 Hz (%)
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
8
8
8
10
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
10
6
6
10
8
8
8
10
STANDARD RATINGS
CAPACITANCE
(μF)
CASE CODE
PART NUMBER
2.2
3.3
3.3
4.7
6.8
6.8
10
10
15
15
22
22
33
47
47
68
68
100
120
150
330
1.5
2.2
2.2
3.3
3.3
4.7
4.7
4.7
6.8
6.8
10
10
10
15
15
22
33
33
47
47
68
68
68
100
100
120
150
330
4 V
DC
AT +85 °C, SURGE = 5 V; 2.7 V
DC
AT +125 °C, SURGE = 3.4 V
A
194D225(1)004A(2)(3)
0.5
A
194D335(1)004A(2)(3)
0.5
B
194D335(1)004B(2)(3)
0.5
B
194D475(1)004B(2)(3)
0.5
B
194D685(1)004B(2)(3)
0.5
C
194D685(1)004C(2)(3)
0.5
C
194D106(1)004C(2)(3)
0.5
D
194D106(1)004D(2)(3)
0.5
D
194D156(1)004D(2)(3)
0.6
E
194D156(1)004E(2)(3)
0.6
E
194D226(1)004E(2)(3)
0.9
F
194D226(1)004F(2)(3)
0.9
F
194D336(1)004F(2)(3)
1.3
F
194D476(1)004F(2)(3)
1.9
G
194D476(1)004G(2)(3)
1.9
F
194D686(1)004F(2)(3)
2.7
G
194D686(1)004G(2)(3)
2.7
H
194D107(1)004H(2)(3)
4.0
H
194D127(1)004H(2)(3)
4.8
H
194D157(1)004H(2)(3)
6.0
H
194D337(1)004H(2)(3)
13.2
6 V
DC
AT +85 °C, SURGE = 8 V; 4 V
DC
AT +125 °C, SURGE = 5 V
A
194D155(1)006A(2)(3)
0.5
A
194D225(1)006A(2)(3)
0.5
B
194D225(1)006B(2)(3)
0.5
A
194D335(1)006A(2)(3)
0.5
B
194D335(1)006B(2)(3)
0.5
A
194D475(1)006A(2)(3)
0.5
B
194D475(1)006B(2)(3)
0.5
C
194D475(1)006C(2)(3)
0.5
C
194D685(1)006C(2)(3)
0.5
D
194D685(1)006D(2)(3)
0.5
B
194D106(1)006B(2)(3)
0.6
D
194D106(1)006D(2)(3)
0.6
E
194D106(1)006E(2)(3)
0.6
E
194D156(1)006E(2)(3)
1.0
F
194D156(1)006F(2)(3)
1.0
F
194D226(1)006F(2)(3)
1.4
F
194D336(1)006F(2)(3)
2.1
G
194D336(1)006G(2)(3)
2.1
F
194D476(1)006F(2)(3)
3.0
G
194D476(1)006G(2)(3)
3.0
F
194D686(1)006F(2)(3)
4.3
G
194D686(1)006G(2)(3)
4.3
H
194D686(1)006H(2)(3)
4.3
G
194D107(1)006G(2)(3)
6.0
H
194D107(1)006H(2)(3)
6.0
H
194D127(1)006H(2)(3)
7.2
H
194D157(1)006H(2)(3)
9.0
H
194D337(1)006H(2)(3)
20.0
Notes
• Part number definitions:
(1) Tolerance: for 10 % tolerance, specify “X9”; for 20 % tolerance, change to “X0”, for 5 % tolerance specify “X5” (special order)
(2) Termination: for gold plated specify “2”, for solder plated 60/40 specify “8”, for solder plated 60/40, fused specify “6”, for hot solder
dipped specify “7”
(3) Packaging code: for 7" reels specify “T”, for half of 7" reels specify “H”, for partial of 7" reels specify “U”, for bulk specify “B”
(1)
5 % tolerance is not available for the 0.33 μF / 50 V design and the 10 μF / 10 V design
Revision: 21-Jun-17
Document Number: 40000
3
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
194D
www.vishay.com
STANDARD RATINGS
CAPACITANCE
(μF)
CASE CODE
PART NUMBER
MAX. DCL
AT +25 °C
(μA)
MAX. DF
AT +25 °C
120 Hz (%)
4
6
6
6
6
6
6
6
6
6
6
6
6
8
6
6
6
6
6
6
6
6
6
10
6
6
6
10
8
8
10
10
4
4
4
6
6
6
6
6
6
6
6
6
6
6
Vishay Sprague
1.0
1.5
1.5
2.2
2.2
3.3
3.3
3.3
4.7
4.7
4.7
6.8
6.8
10
(1)
10
10
10
15
15
22
22
33
33
47
47
47
68
100
100
120
150
220
0.68
1.0
1.0
1.5
1.5
2.2
2.2
2.2
3.3
3.3
3.3
4.7
4.7
4.7
10 V
DC
AT +85 °C, SURGE = 13 V; 7 V
DC
AT +125 °C, SURGE = 9 V
A
194D105(1)010A(2)(3)
0.5
A
194D155(1)010A(2)(3)
0.5
B
194D155(1)010B(2)(3)
0.5
A
194D225(1)010A(2)(3)
0.5
B
194D225(1)010B(2)(3)
0.5
A
194D335(1)010A(2)(3)
0.5
B
194D335(1)010B(2)(3)
0.5
C
194D335(1)010C(2)(3)
0.5
B
194D475(1)010B(2)(3)
0.5
C
194D475(1)010C(2)(3)
0.5
D
194D475(1)010D(2)(3)
0.5
D
194D685(1)010D(2)(3)
0.7
E
194D685(1)010E(2)(3)
0.7
B
194D106(1)010B(2)(3)
1.0
C
194D106(1)010C(2)(3)
1.0
E
194D106(1)010E(2)(3)
1.0
F
194D106(1)010F(2)(3)
1.0
E
194D156(1)010E(2)(3)
1.5
F
194D156(1)010F(2)(3)
1.5
F
194D226(1)010F(2)(3)
2.2
G
194D226(1)010G(2)(3)
2.2
F
194D336(1)010F(2)(3)
3.3
G
194D336(1)010G(2)(3)
3.3
F
194D476(1)010F(2)(3)
4.7
G
194D476(1)010G(2)(3)
4.7
H
194D476(1)010H(2)(3)
4.7
H
194D686(1)010H(2)(3)
6.8
G
194D107(1)010G(2)(3)
10.0
H
194D107(1)010H(2)(3)
10.0
H
194D127(1)010H(2)(3)
12.0
H
194D157(1)010H(2)(3)
15.0
H
194D227(1)010H(2)(3)
22.0
15 V
DC
AT +85 °C, SURGE = 20 V; 10 V
DC
AT +125 °C, SURGE = 12 V
A
194D684(1)015A(2)(3)
0.5
A
194D105(1)015A(2)(3)
0.5
B
194D105(1)015B(2)(3)
0.5
A
194D155(1)015A(2)(3)
0.5
B
194D155(1)015B(2)(3)
0.5
A
194D225(1)015A(2)(3)
0.5
B
194D225(1)015B(2)(3)
0.5
C
194D225(1)015C(2)(3)
0.5
B
194D335(1)015B(2)(3)
0.5
C
194D335(1)015C(2)(3)
0.5
D
194D335(1)015D(2)(3)
0.5
B
194D475(1)015B(2)(3)
0.7
D
194D475(1)015D(2)(3)
0.7
E
194D475(1)015E(2)(3)
0.7
Notes
• Part number definitions:
(1) Tolerance: for 10 % tolerance, specify “X9”; for 20 % tolerance, change to “X0”, for 5 % tolerance specify “X5” (special order)
(2) Termination: for gold plated specify “2”, for solder plated 60/40 specify “8”, for solder plated 60/40, fused specify “6”, for hot solder
dipped specify “7”
(3) Packaging code: for 7" reels specify “T”, for half of 7" reels specify “H”, for partial of 7" reels specify “U”, for bulk specify “B”
(1)
5 % tolerance is not available for the 0.33 μF / 50 V design and the 10 μF / 10 V design
Revision: 21-Jun-17
Document Number: 40000
4
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
194D
www.vishay.com
STANDARD RATINGS
CAPACITANCE
(μF)
CASE CODE
PART NUMBER
MAX. DCL
AT +25 °C
(μA)
1.1
1.1
1.6
1.6
2.4
2.4
3.5
3.5
5.3
5.3
5.3
10.0
7.0
10.0
15.0
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.7
0.7
0.9
0.9
1.4
1.4
2.0
2.0
2.0
3.0
3.0
4.0
4.4
6.6
MAX. DF
AT +25 °C
120 Hz (%)
6
6
6
6
6
6
6
6
6
6
6
8
6
6
10
4
4
4
4
4
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
8
6
6
Vishay Sprague
15 V
DC
AT +85 °C, SURGE = 20 V; 10 V
DC
AT +125 °C, SURGE = 12 V
6.8
6.8
10
10
15
15
22
22
33
33
33
47
47
68
100
0.47
0.68
0.68
1.0
1.0
1.5
1.5
2.2
2.2
3.3
3.3
4.7
4.7
6.8
6.8
10
10
10
15
15
22
22
33
E
F
E
F
F
G
F
G
F
G
H
G
H
H
H
A
A
B
A
B
B
C
C
D
D
E
E
F
E
F
E
F
G
F
G
G
H
H
194D685(1)015E(2)(3)
194D685(1)015F(2)(3)
194D106(1)015E(2)(3)
194D106(1)015F(2)(3)
194D156(1)015F(2)(3)
194D156(1)015G(2)(3)
194D226(1)015F(2)(3)
194D226(1)015G(2)(3)
194D336(1)015F(2)(3)
194D336(1)015G(2)(3)
194D336(1)015H(2)(3)
194D476(1)015G(2)(3)
194D476(1)015H(2)(3)
194D686(1)015H(2)(3)
194D107(1)015H(2)(3)
194D474(1)020A(2)(3)
194D684(1)020A(2)(3)
194D684(1)020B(2)(3)
194D105(1)020A(2)(3)
194D105(1)020B(2)(3)
194D155(1)020B(2)(3)
194D155(1)020C(2)(3)
194D225(1)020C(2)(3)
194D225(1)020D(2)(3)
194D335(1)020D(2)(3)
194D335(1)020E(2)(3)
194D475(1)020E(2)(3)
194D475(1)020F(2)(3)
194D685(1)020E(2)(3)
194D685(1)020F(2)(3)
194D106(1)020E(2)(3)
194D106(1)020F(2)(3)
194D106(1)020G(2)(3)
194D156(1)020F(2)(3)
194D156(1)020G(2)(3)
194D226(1)020G(2)(3)
194D226(1)020H(2)(3)
194D336(1)020H(2)(3)
20 V
DC
AT +85 °C, SURGE = 26 V; 13 V
DC
AT +125 °C, SURGE = 16 V
Notes
• Part number definitions:
(1) Tolerance: for 10 % tolerance, specify “X9”; for 20 % tolerance, change to “X0”, for 5 % tolerance specify “X5” (special order)
(2) Termination: for gold plated specify “2”, for solder plated 60/40 specify “8”, for solder plated 60/40, fused specify “6”, for hot solder
dipped specify “7”
(3) Packaging code: for 7" reels specify “T”, for half of 7" reels specify “H”, for partial of 7" reels specify “U”, for bulk specify “B”
(1)
5 % tolerance is not available for the 0.33 μF / 50 V design and the 10 μF / 10 V design
Revision: 21-Jun-17
Document Number: 40000
5
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
京公网安备 11010802033920号
EEWORLD
