LARGE CAPACITANCE ALUMINUM ELECTROLYTIC CAPACITORS
Long life snap-ins, 105℃
TXH
Items
Category
Temperature Range
Rated Voltage Range
Capacitance Tolerance
Leakage Current
Dissipation Factor
(tanδ)
Low Temperature
Characteristics
(Max. Impedance Ratio)
Endurance
Series
TXH
Longer life
LXM P6-47
・Endurance
with ripple current : 10,000 hours at 105℃
・Non
solvent resistant type
・RoHS2
Compliant
◆SPECIFICATIONS
Characteristics
-25 to +105℃
200 to 450V
dc
±20%
(M)
I≦3 CV
Where, I : Max. leakage current (µA), C : Nominal capacitance (µF), V : Rated voltage (V)
Rated voltage (V
dc
)
200 to 400V
450V
tanδ (Max.)
0.15
0.20
Rated voltage (V
dc
)
200 to 400V
450V
Z (-25℃)/Z (+20℃)
4
8
(at 20℃, 120Hz)
(at 20℃ after 5 minutes)
(at 20℃, 120Hz)
Shelf Life
(at 120Hz)
The following specifications shall be satisfied when the capacitors are restored to 20℃ after subjected to DC voltage with the rated
ripple current is applied (the peak voltage shall not exceed the rated voltage) for 10,000 hours at 105℃.
Capacitance change
≦±20%
of the initial value
D.F. (tanδ)
≦200%
of the initial specified value
Leakage current
≦The
initial specified value
The following specifications shall be satisfied when the capacitors are restored to 20℃ after exposing them for 1,000 hours at 105℃ without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Capacitance change
≦±15%
of the initial value
D.F. (tanδ)
≦150%
of the initial specified value
Leakage current
≦The
initial specified value
◆DIMENSIONS
[mm]
●
Terminal
Code : VS (
φ
30 to
φ
40) : Standard
Negative mark
PC board pin-out
(View from Solder side)
●
Terminal
Code : LI (
φ
35,
φ
40)
Negative mark
PC board pin-out
(View from Solder side)
4.2±0.5
5±0.5
14.2±1
2-1.2×6
Sleeve (PET : Brown)
φ
D+1max.
Sleeve (PET : Brown)
φ
D+1max.
Vent
L±2
*
4.0±0.5
2-φ2
10
Vent
L±2
**
4.5±1
*
φ
D=40mm : 3.5
±
0.5mm
**
φ
D=40mm : 4.0
±
1
The standard design has no plastic disc.
◆PART
NUMBERING SYSTEM
E T XH
1
2
3
4
5
6
7
VS N
8
9
10
11
12
13
M
14
15
16
17
S
18
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 470µF:471, 1,000µF:102)
Dummy terminal code
Terminal code (VS, LI)
Voltage code (ex. 200V:201 , 450V:451)
Series code
Category
Please refer to "Product code guide (snap-in type)"
Product specifications in this catalog are subject to change without notice.Request our product specifications before purchase and/or use. Please use our products based on the information contained in this catalog and product specifications.
6-45
CAT. No. E1001R
LARGE CAPACITANCE ALUMINUM ELECTROLYTIC CAPACITORS
Long life snap-ins, 105℃
TXH
Series
◆STANDARD
RATINGS
WV
(V
dc
)
Cap
(µF)
560
680
820
820
1,000
1,000
1,000
1,200
1,200
1,500
1,500
1,800
390
470
560
680
680
820
820
820
1,000
1,000
1,200
1,200
1,500
1,800
Rated ripple
current
Case size
tanδ
(Arms/
φD×L(mm)
105℃, 120Hz)
30
×30
30
×35
30
×40
35
×30
30
×45
35
×35
40
×30
35
×40
40
×35
35
×50
40
×40
40
×50
30
×30
30
×35
35
×30
30
×45
35
×35
30
×50
35
×40
40
×30
35
×45
40
×35
35
×50
40
×40
40
×50
40
×60
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
1.50
1.70
2.00
2.00
2.20
2.20
2.17
2.40
2.45
2.81
2.79
3.24
1.30
1.42
1.58
1.80
1.76
2.03
2.01
1.96
2.30
2.27
2.55
2.53
2.96
3.39
Part No.
ETXH201VSN561MR30S
ETXH201VSN681MR35S
ETXH201VSN821MR40S
ETXH201VSN821MA30S
ETXH201VSN102MR45S
ETXH201VSN102MA35S
ETXH201VSN102MB30S
ETXH201VSN122MA40S
ETXH201VSN122MB35S
ETXH201VSN152MA50S
ETXH201VSN152MB40S
ETXH201VSN182MB50S
ETXH251VSN391MR30S
ETXH251VSN471MR35S
ETXH251VSN561MA30S
ETXH251VSN681MR45S
ETXH251VSN681MA35S
ETXH251VSN821MR50S
ETXH251VSN821MA40S
ETXH251VSN821MB30S
ETXH251VSN102MA45S
ETXH251VSN102MB35S
ETXH251VSN122MA50S
ETXH251VSN122MB40S
ETXH251VSN152MB50S
ETXH251VSN182MB60S
WV
(V
dc
)
Cap
(µF)
220
270
270
330
330
330
390
390
470
470
560
560
680
820
220
220
270
270
330
330
390
470
560
Rated ripple
current
Case size
tanδ
(Arms/
φD×L(mm)
105℃, 120Hz)
30
×35
30
×40
35
×30
30
×45
35
×35
40
×30
30
×50
35
×40
35
×45
40
×35
35
×50
40
×40
40
×50
40
×60
30
×40
35
×30
30
×45
35
×35
30
×50
35
×40
35
×45
35
×50
40
×60
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
0.20
1.00
1.15
1.13
1.29
1.26
1.28
1.44
1.43
1.60
1.58
1.79
1.78
2.05
2.36
1.04
1.02
1.19
1.16
1.33
1.32
1.48
1.64
1.98
Part No.
ETXH401VSN221MR35S
ETXH401VSN271MR40S
ETXH401VSN271MA30S
ETXH401VSN331MR45S
ETXH401VSN331MA35S
ETXH401VSN331MB30S
ETXH401VSN391MR50S
ETXH401VSN391MA40S
ETXH401VSN471MA45S
ETXH401VSN471MB35S
ETXH401VSN561MA50S
ETXH401VSN561MB40S
ETXH401VSN681MB50S
ETXH401VSN821MB60S
ETXH451VSN221MR40S
ETXH451VSN221MA30S
ETXH451VSN271MR45S
ETXH451VSN271MA35S
ETXH451VSN331MR50S
ETXH451VSN331MA40S
ETXH451VSN391MA45S
ETXH451VSN471MA50S
ETXH451VSN561MB60S
200
400
250
450
◆RATED
RIPPLE CURRENT MULTIPLIERS
・Frequency
Multipliers
Frequency(Hz)
200, 250V
dc
400, 450V
dc
50
0.81
0.77
120
1.00
1.00
300
1.17
1.16
1k
1.32
1.30
10k
1.45
1.41
50k
1.50
1.43
The endurance of capacitors is reduced with internal heating produced by ripple current at the rate of halving the lifetime with every 5℃ rise.
When long life performance is required in actual use, the rms ripple current has to be reduced.
Product specifications in this catalog are subject to change without notice.Request our product specifications before purchase and/or use. Please use our products based on the information contained in this catalog and product specifications.
6-46
CAT. No. E1001R
