AXIAL LEADED INDUCTORS（CAL Type）、
RADIAL LEADED INDUCTORS（LH Type）、
LEADED FERRITE BEAD INDUCTORS（ FB Series A Type／R Type）
■RELIABILITY
DATA
1. Operating temperature Range
CAL45 Type
Specified Value
LHL□□□
FBA/FBR
CAL45 Type
Test Methods and
Remarks
LHL□□□
FBA/FBR
2. Storage temperature Range
Including self-generated heat
－25½＋ 105℃
CAL45 Type
Specified Value
LHL□□□
FBA/FBR
3. Rated current
CAL45 Type
Specified Value
LHL□□□
FBA/FBR
CAL45 Type :
The maximum DC value having inductance within 10% and temperature increase within 40℃ by the application of DC bias.
LHL□□□ :
The maximum DC value having inductance decrease within 10% (LHLC08, LHLC10：within 30%) and temperature increase within the
following specified temperature by the application of DC bias.
Reference temperature
: 25℃（LHL08, LHL10）
: 40℃（LHLC08, LHLC10）
FBA/FBR :
No disconnection or appearance abnormality by continuous current application for 30 min. Change after the application shall be
within ±20% of the initial value.
This is not guaranteed for electrical characteristics during current application.
Within the specified tolerance
－40½＋ 85℃（Except for taping condition）
Test Methods and
Remarks
4. Impedance
CAL45 Type
Specified Value
LHL□□□
FBA/FBR
Test Methods and
Remarks
FBA/FBR :
Measuring equipment
Measuring frequency
Within the specified tolerance
: Impedance analyzer (HP4191A) or its equivalent
: Specified frequency
5. Inductance
CAL45 Type
Specified Value
LHL□□□
FBA/FBR
CAL45 Type :
Measuring equipment
Measuring frequency
LHL□□□ :
Measuring equipment
Measuring frequency
: LCR meter (HP4285A + HP42851A or its equivalent)
: Specified frequency
: LCR meter (HP4285A＋HP42851A or its equivalent)
: LCR meter (HP4263A) or its equivalent (at 1kHz)
: Specified frequency
Within the specified tolerance
Test Methods and
Remarks
▶
This catalog contains the typical specification only due to the limitation of space. When you consider the purchase of our products, please check our specification.
For details of each product (characteristics graph, reliability information, precautions for use, and so on), see our Web site (http://www.ty-top.com/) .
