NTCLE201E3...SB, NTCLE300E3...SB
www.vishay.com
Vishay BCcomponents
NTC Thermistors, 2-Point Mini Chip Sensor, Flexible Leads
FEATURES
•
•
•
•
Accuracy of 0.5 °C between 0 °C and 50 °C
Small 2.4 mm diameter
High stability over a long life
Long and flexible leads for special mounting or
assembly requirements
• AEC-Q200 qualified
• Material categorization: for definitions of
compliance please see
www.vishay.com/doc?99912
VALUE
3K to 10K
± 2.18
3977
± 0.75
-40 to +125
± 0.5
100
UNIT
Ω
%
K
%
°C
°C
mW
QUICK REFERENCE DATA
PARAMETER
Resistance value at 25 °C
Tolerance on
R
25
-value
B
25/85
-value
Tolerance on B
25/85
-value
Operating temperature
range at zero dissipation
Accuracy for T measured
between 0 °C and 50 °C
Maximum power
dissipation at 55 °C
Min. dielectric withstanding
voltage between terminals
and coated body
Weight
APPLICATIONS
• Temperature measurement, sensing and control in
automotive, industrial and consumer electronic
equipment
DESCRIPTION
These negative temperature coefficient thermistors consist
of a mini-chip soldered between two AWG#30 ETFE
insulated (LE300) or non-insulated (LE201) 0.3 mm nickel
leads and coated with a solid ocher color epoxy lacquer.
PACKAGING
The thermistors are packed in cardboard boxes; the
smallest packing quantity is 1000 units.
500
≈
0.2
V
AC
g
MARKING
The coated body has no markings.
MOUNTING
By soldering in any position.
DESIGN-IN SUPPORT
For complete curve computation, please visit:
www.vishay.com/thermistors/ntc-curve-list/.
ELECTRICAL DATA AND ORDERING INFORMATION
R
25
(Ω)
3000
5000
10 000
3000
5000
10 000
R
25
-TOL.
(± %)
2.18
2.18
2.18
2.18
2.18
2.18
B
25/85
(K)
3977
3977
3977
3977
3977
3977
B
25/85
-TOL.
(± %)
0.75
0.75
0.75
0.75
0.75
0.75
SAP MATERIAL AND
ORDERING NUMBER
NTCLE201E3302SB
NTCLE201E3502SB
NTCLE201E3103SB
NTCLE300E3302SB
NTCLE300E3502SB
NTCLE300E3103SB
DIMENSIONS
in millimeters
Component outline for NTCLE201E3...
2.4
max.
Component outline for NTCLE300E3...
2.4
max.
0.25 ± 0.025
0.3 ± 0.03
2.4
max.
0.58 max.
2.4
max.
6±1
8 max.
38 ± 2
8 max.
38 ± 2
Revision: 14-Jun-17
Document Number: 29051
1
For technical questions, contact:
nlr@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
NTCLE201E3...SB, NTCLE300E3...SB
www.vishay.com
DERATING
P
(%)
100
Vishay BCcomponents
0
-40
-25
0
55
85
T
amb
(°C)
125
Power derating curve
Note
• Zero power is considered as measuring power max. 1 % of max. power.
RESISTANCE VALUES AT INTERMEDIATE TEMPERATURES
T
OPER
(°C)
-40
-35
-30
-25
-20
-15
-10
-5
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
105
110
115
120
125
R
T
/R
25
33.21
23.99
17.52
12.93
9.636
7.250
5.505
4.216
3.255
2.534
1.987
1.570
1.249
1.000
0.8059
0.6535
0.5330
0.4372
0.3605
0.2989
0.2490
0.2084
0.1753
0.1481
0.1256
0.1070
0.09154
0.07860
0.06773
0.05858
0.05083
0.04426
0.03866
0.03387
T-TOL.
(± K)
0.68
0.66
0.64
0.62
0.59
0.57
0.55
0.52
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.55
0.61
0.66
0.72
0.77
0.83
0.89
0.95
1.02
1.08
1.14
1.21
1.27
1.34
1.41
TCR
(%/K)
-6.57
-6.36
-6.15
-5.95
-5.76
-5.58
-5.40
-5.24
-5.08
-4.92
-4.78
-4.64
-4.50
-4.37
-4.25
-4.13
-4.02
-3.91
-3.80
-3.70
-3.60
-3.51
-3.42
-3.33
-3.25
-3.16
-3.09
-3.01
-2.94
-2.87
-2.80
-2.73
-2.67
-2.61
R
T
-VALUE (kΩ)
NTCLE201E3...SB OR NTCLE300E3...SB
302
99.63
71.97
52.56
38.79
28.91
21.75
16.51
12.65
9.766
7.602
5.962
4.710
3.746
3.000
2.418
1.960
1.599
1.312
1.082
0.8966
0.7470
0.6253
0.5259
0.4443
0.3769
0.3211
0.2746
0.2358
0.2032
0.1757
0.1525
0.1328
0.1160
0.1016
502
166.1
120.0
87.60
64.65
48.18
36.25
27.52
21.08
16.28
12.67
9.936
7.849
6.244
5.000
4.030
3.267
2.665
2.186
1.803
1.494
1.245
1.042
0.8765
0.7405
0.6282
0.5352
0.4577
0.3930
0.3387
0.2929
0.2542
0.2213
0.1933
0.1694
103
332.1
239.9
175.2
129.3
96.36
72.50
55.05
42.16
32.56
25.34
19.87
15.70
12.49
10.00
8.059
6.535
5.330
4.372
3.606
2.989
2.490
2.084
1.753
1.481
1.256
1.070
0.9154
0.7860
0.6773
0.5858
0.5083
0.4426
0.3866
0.3387
Revision: 14-Jun-17
Document Number: 29051
2
For technical questions, contact:
nlr@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
