Wind CUBEFuse
™
For Wind Power Generation Applications
Features and Product Benefits
• Maximize uptime and reliability using fuses designed and
recognized to UL 248 for low voltage fuses
• Fast-acting protection specifically designed for low-fault
current conditions that occur in wind power generation
systems
• Minimize chances of equipment failure and personnel injury
when using full range fuses having fast response time to
low-magnitude faults
• Simplify compatibility with readily available industry
standard Class CF holders while minimizing panel space by
up to 80%
• Meets all UL specified overload opening requirements
• Minimizes incident energy and reduces arc flash hazards
utilizing Class J electrical characteristics
• Finger-safe feature minimizes exposure to live parts,
reducing hazard to personnel
Catalog Symbol:
WCF_RN
Description:
Finger-safe, fast-acting CUBEFuse for wind
power generation.
Electrical Characteristics:
Maximum clearing time at 200%
rated current:
• 4 Minutes for 1 to 30A fuses
• 6 Minutes for 35 to 60A fuses
• 8 Minutes for 70 to 100A fuses
Ratings:
Volts —
Amps —
IR —
IR —
690Vac
1-100A
50kA AC (1-60A)
30kA AC (70-100A)
Catalog Numbers (amp rating)
Non-Indicating Wind
WCF1RN
WCF15RN
WCF3RN
WCF20RN
WCF6RN
WCF25RN
WCF10RN WCF30RN
CUBEFuse
WCF35RN
WCF40RN
WCF45RN
WCF50RN
WCF60RN
WCF70RN
WCF80RN
WCF90RN
WCF100RN
—
—
—
Agency Information:
• UL Recognized Fuse: Guide JFHR, File E56412
• cURus component certified C22.2
Wind CUBEFuse Holders
Catalog Numbers
(amps)
Fits 690V Wind CUBEFuse Holder
Non-Indicating
TCFH30NW TCFH60NW TCFH100NW
WCF1RN
X
X
X
WCF3RN
X
X
X
WCF6RN
X
X
X
WCF10RN
X
X
X
WCF15RN
X
X
X
WCF20RN
X
X
X
WCF25RN
X
X
X
WCF30RN
X
X
X
WCF35RN
X
X
WCF40RN
X
X
WCF50RN
X
X
WCF60RN
X
X
WCF70RN
X
WCF80RN
X
WCF90RN
X
WCF100RN
X
Other Ratings/Specifications:
Watts Loss at Rated Current:
WCF15RN: 3.48W
WCF30RN: 5.45W
WCF60RN: 7.27W
WCF100RN: 11.50W
Operating and Storage Temperature Range:
-40 to 90°C
Material Specifications:
• Case: Glass filled PES (Polyethersulfone)
• Terminals: Copper alloy
• Terminal plating: Electroless tin
Installation:
Fits 690V WCF holders as listed in the table
Application:
• Wind Systems:
- Transformer protection
- Pitch and speed control
- Turbine HVAC and lighting
Carton Quantity and Weight
Amp
Carton Weight Per Carton
Rating
Qty.
lbs
kg
WCF1-30A
12
1.39
0.63
WCF35-60A
12
1.42
0.65
WCF70-100A 6
1.74
0.79
0712
BU-SB12615
Page 1 of 2
Data Sheet 9009
WCF_RN Dimensions – in (mm)
Fuse
Amps
1-15
20
25-30
35-40
45-50
60
70
80-90
100
A
1.88
(47.75)
1.88
(47.75)
1.88
(47.75)
2.13
(54.10)
2.13
(54.10)
2.13
(54.10)
3.01
(76.45)
3.01
(76.45)
3.01
(76.45)
B
0.75
(19.05)
0.75)
(19.05)
0.75
(19.05)
1.00
(25.40)
1.00
(25.40)
1.00
(25.40)
1.00
(25.40)
1.00
(25.40)
1.00
(25.40)
Dimensions - in (mm)
C
D
E
1.00
0.23
0.04
(25.40)
(5.84)
(1.02)
1.00
0.31
0.04
(25.40)
(7.87)
(1.02)
1.00
0.31
0.04
(25.40)
(7.87)
(1.02)
1.13
0.36
0.04
(28.58)
(9.10)
(1.02)
1.13
0.44
0.04
(28.58) (11.13)
(1.02)
1.13
0.44
0.04
(28.58) (11.13)
(1.02)
1.26
0.49
0.06
(32.00) (12.45)
(1.60)
1.26
0.49
0.06
(32.00) (12.45)
(1.60)
1.26
0.57
0.06
(32.00) (14.48)
(1.60)
F
0.63
(15.93)
0.63
(15.93)
0.63
(15.93)
0.63
(15.93)
0.63
(15.93)
0.63
(15.93)
0.58
(14.78)
0.58
(14.78)
0.58
(14.78)
G
0.28
(7.11)
0.28
(7.11)
0.28
(7.11)
0.38
(9.65)
0.38
(9.65)
0.38
(9.65)
0.38
(9.65)
0.38
(9.65)
0.38
(9.65)
Current Limitation Curves
Time-Current Characteristic Curves–Average Melt
1000
15A
40A
50A
60A
100,000
B
100A
10A
20A
1A
3A
30A
6A
INSTANTANEOUS PEAK LET THRU CURRENT IN AMPSPS
100A
10,000
60A
50A
40A
30A
15A
1,000
100
A
100
1,000
10,000
100,000
PROSPECTIVE SHORT-CIRCUIT CURRENT SYMMETRICAL RMS AMPS
TIME IN SECONDS
10
Wind CUBEFuse Holders
1
0.1
All 690V 100, 60 and 30A Wind CUBEFuse holders can be
dovetail together for the required number of poles.
690V Fuse Holder Catalog Numbers
Catalog
Numbers
TCFH30NW
TCFH60NW
TCFH100NW
Amp
Range
1-30
1-60
1-100
CURRENT IN AMPS
The only controlled copy of this Data Sheet is the electronic read-only version located on the Cooper Bussmann Network Drive. All other copies of
this document are by definition uncontrolled. This bulletin is intended to clearly present comprehensive product data and provide technical informa-
tion that will help the end user with design applications. Cooper Bussmann reserves the right, without notice, to change design or construction of
any products and to discontinue or limit distribution of any products. Cooper Bussmann also reserves the right to change or update, without notice,
any technical information contained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.
0712
BU-SB12615
10,000
100
10
1,000
1
0.01
Page 2 of 2
Data Sheet 9009
300,000
