1N6103AUS – 1N6137AUS
Voidless Hermetically Sealed Surface Mount
Bidirectional Transient Voltage Suppressors
Qualified to MIL-PRF-19500/516
Qualified Levels:
JAN, JANTX, JANTXV
and JANS*
Available on
commercial
versions
DESCRIPTION
This surface mount series of industry recognized voidless, hermetically sealed, bidirectional
Transient Voltage Suppressors (TVS) designs is military qualified to MIL-PRF-19500/516 and is
ideal for high-reliability applications where a failure cannot be tolerated. They provide a Working
Peak “Standoff” Voltage selection from 5.7 to 152 Volts with a 500 W rating for a 10/1000
µs
pulse.
They are very robust in hard-glass construction and internal “Category
1”
metallurgical bonds.
These are also available as both a non-suffix part and an “A” version providing different voltage
tolerances as described in the nomenclature section. These devices are also available in axial-
leaded packages for thru-hole mounting.
“B” or SQ-MELF
Package
Also available in:
“B” Package
(axial-leaded)
1N6103 – 1N6137
Important:
For the latest information, visit our website
http://www.microsemi.com.
FEATURES
•
•
•
•
•
•
High surge current and peak pulse power provides transient voltage protection for sensitive circuits.
Triple-layer passivation.
Internal “Category
1”
metallurgical bonds.
Voidless hermetically sealed glass package.
JAN, JANTX, and JANTXV qualified versions are available per MIL-PRF-19500/516.
*JANS available for 1N6103(A)US thru 1N6118(A)US per MIL-PRF-19500/516 as well as further
options for screening in reference to MIL-PRF-19500 for all others in this series.
(See
part nomenclature
for all available options.)
RoHS compliant versions available (commercial grade only).
•
APPLICATIONS / BENEFITS
•
•
•
•
•
•
•
•
•
Military and other high-reliability applications.
Extremely robust construction.
Extensive range in working peak “standoff” voltage (V
WM
) from 5.7 to 152 volts.
500 watt peak pulse power (P
PP
) for a 10/1000
µs
pulse.
ESD and EFT protection per IEC6100-4-2 and IEC61000-4-4 respectively.
Protection from the secondary effects of lightning per select levels in IEC61000-4-5.
Square-end-cap terminals for easy placement.
Non-sensitive to ESD per MIL-STD-750 method 1020.
Inherently radiation hard as described in Microsemi “MicroNote
050”.
MAXIMUM RATINGS
@
T
A
= 25 C unless otherwise noted
Parameters/Test Conditions
Junction and Storage Temperature
Thermal Resistance Junction-to-End Cap
Peak Pulse Power @ 25 ºC (10/1000
µs)
o (1)
Steady-State Power up to T
EC
= 150 C
o (2)
Steady-State Power @ T
A
= 25 C
Impulse Repetition Rate
Solder Temperature @ 10 s
Notes:
1.
2.
o
Symbol
T
J
and T
STG
R
ӨJEC
P
PP
P
D
P
D
df
T
SP
Value
-55 to +175
8.3
500
3.0
2.0
0.01
260
Unit
o
C
C/W
W
W
W
%
o
C
o
MSC – Lawrence
6 Lake Street,
Lawrence, MA 01841
Tel: 1-800-446-1158 or
(978) 620-2600
Fax: (978) 689-0803
MSC – Ireland
Gort Road Business Park,
Ennis, Co. Clare, Ireland
Tel: +353 (0) 65 6840044
Fax: +353 (0) 65 6822298
Website:
www.microsemi.com
Linearly derate above T
EC
=150
o
C to zero at T
EC
=175
o
C.
Steady-state power ratings with reference to ambient are for PC boards where thermal resistance from
mounting point to ambient is sufficiently controlled where maximum rated T
J
is not exceeded (also see
figure 4).
T4-LDS-0277-1, Rev. 1 (121354)
©2013 Microsemi Corporation
Page 1 of 6
1N6103AUS – 1N6137AUS
MECHANICAL and PACKAGING
•
•
•
•
•
•
•
CASE: Hermetically sealed voidless hard glass with tungsten slugs.
TERMINALS: Tin/lead plate over copper. RoHS compliant matte-tin is available on commercial grade only.
MARKING: None.
POLARITY: No polarity marking for these bidirectional TVSs.
TAPE & REEL option: Standard per EIA-481-B. Consult factory for quantities.
WEIGHT: Approximately 539 milligrams.
See
Package Dimensions
on last page.
PART NOMENCLATURE
Applicable to entire series:
JAN
Reliability Level
JAN = JAN Level
JANTX = JANTX Level
JANTXV = JANTXV Level
Blank = commercial
JEDEC type number
See
Electrical Characteristics
table
1N6103 A US (e3)
RoHS Compliance
e3 = RoHS compliant (available
on commercial grade only)
Blank = non-RoHS compliant
Surface Mount Package
Voltage Tolerance
A = Standard
Blank =5% higher V
C
, 5% lower
min. V
(BR)
and 5% lower I
PP
Applicable to 1N6103(A)US – 1N6118(A)US only:
JANS
Reliability Level
JANS = JANS Level
JEDEC type number
See
Electrical Characteristics
table
1N6103 A
US
Surface Mount Package
Voltage Tolerance
A = Standard
Blank =5% higher V
C
, 5% lower
min. V
(BR)
and 5% lower I
PP
Applicable to 1N6119(A)US – 1N6137(A)US only:
MSP 1N6119 A
Reliability Level
MSP (reference JANS)
JEDEC type number
See
Electrical Characteristics
table
US (e3)
RoHS Compliance
e3 = RoHS compliant
Blank = non-RoHS compliant
Surface Mount Package
Voltage Tolerance
A = Standard
Blank =5% higher V
C
, 5% lower
min. V
(BR)
and 5% lower I
PP
T4-LDS-0277-1, Rev. 1 (121354)
©2013 Microsemi Corporation
Page 2 of 6
1N6103AUS – 1N6137AUS
SYMBOLS & DEFINITIONS
Definition
Minimum Breakdown Voltage: The minimum voltage the device will exhibit at a specified current.
Working Peak Voltage: The maximum peak voltage that can be applied over the operating temperature range. This is
also referred to as Standoff Voltage.
Maximum Standoff Current: The maximum current that will flow at the specified voltage and temperature.
Maximum clamping voltage at specified I
PP
(Peak Pulse Current) at the specified pulse conditions.
Peak Pulse Power: The peak power dissipation resulting from the peak impulse current I
PP
.
Symbol
V
(
BR)
V
WM
I
D
V
C
P
PP
ELECTRICAL CHARACTERISTICS
MINIMUM
BREAKDOWN
VOLTAGE
(Note 1)
V
(BR)
@ I
(BR)
Volts
7.13
7.79
8.65
9.50
10.45
11.40
12.35
14.25
15.20
17.10
19.0
20.9
22.8
25.7
28.5
31.4
34.2
37.1
40.9
44.7
48.5
53.2
58.9
64.6
71.3
77.9
86.5
95.0
104.5
114.0
123.5
142.5
152.0
171.0
190.0
mA
175
150
150
125
125
100
100
75
75
65
65
50
50
50
40
40
30
30
30
25
25
20
20
20
20
15
15
12
12
10
10
8
8
5
5
RATED
STANDOFF
VOLTAGE
V
WM
V
5.7
6.2
6.9
7.6
8.4
9.1
9.9
11.4
12.2
13.7
15.2
16.7
18.2
20.6
22.8
25.1
27.4
29.7
32.7
35.8
38.8
42.6
47.1
51.7
56.0
62.2
69.2
76.0
86.6
91.2
98.8
114.0
121.6
136.8
152.0
MAXIMUM
STANDBY
CURRENT
I
D
@ V
WM
µA
50
20
20
20
20
20
20
20
20
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
MAXIMUM
CLAMPING
VOLTAGE
(Note 1)
V
C
@ I
PP
Volts
11.2
12.1
13.4
14.5
15.6
16.9
18.2
21.0
22.3
25.1
27.7
30.5
33.3
37.4
41.6
45.7
49.9
53.6
59.1
64.6
70.1
77.0
85.3
97.1
103.1
112.8
125.1
137.6
151.3
165.1
178.8
206.3
218.4
245.7
273.0
MAXIMUM
PEAK PULSE
CURRENT
(Note 1)
I
PP
Amps
44.6
41.3
37.3
34.5
32.0
29.6
27.5
23.8
22.4
19.9
18.0
16.4
15.0
13.4
12.0
10.9
10.0
9.3
8.5
7.7
7.1
6.5
5.9
5.1
4.8
4.4
4.0
3.6
3.3
3.0
2.8
2.4
2.3
2.0
1.8
MAXIMUM
TEMP.
COEF. OF
V
(
BR)
α
V(BR)
o
%/ C
.06
.06
.06
.07
.07
.07
.08
.08
.08
.085
.085
.085
.09
.09
.09
.095
.095
.095
.095
.095
.095
.095
.100
.100
.100
.100
.100
.100
.100
.100
.105
.105
.105
.110
.110
INDUSTRY TYPE
NUMBER
(Note 1)
†1N6103AUS
†1N6104AUS
†1N6105AUS
†1N6106AUS
†1N6107AUS
†1N6108AUS
†1N6109AUS
†1N6110AUS
†1N6111AUS
†1N6112AUS
†1N6113AUS
†1N6114AUS
†1N6115AUS
†1N6116AUS
†1N6117AUS
†1N6118AUS
1N6119AUS
1N6120AUS
1N6121AUS
1N6122AUS
1N6123AUS
1N6124AUS
1N6125AUS
1N6126AUS
1N6127AUS
1N6128AUS
1N6129AUS
1N6130AUS
1N6131AUS
1N6132AUS
1N6133AUS
1N6134AUS
1N6135AUS
1N6136AUS
1N6137AUS
† Also available in JANS qualification per MIL-PRF-19500/516.
Notes:
1. Part number without the A suffix has 5% higher V
C
, 5% lower minimum V
(BR)
, and 5% lower I
PP
.
T4-LDS-0277-1, Rev. 1 (121354)
©2013 Microsemi Corporation
Page 3 of 6
