IDS-5
Amphenol
®
Amphe-PPM Quick Disconnect Connectors
The Amphe-PPM is a rapid mate, push/pull connector which
provides positive mating in limited space and ease of use. The
design features of the Amphe-PPM allow consumers to save
cost in space savings and in installation.
Amphe-PPM, the high performance signal and power
interconnection solution, is ideally suited to many commercial
and industrial applications including, but not limited to:
• Medical Equipment
• Instrumentation/Test & Measurement
• Communication Equipment
The Amphe-PPM continues Amphenol’s commitment of
providing new products to meet customer and market
demands for new emerging technologies and advancing
applications.
Features:
• Push/pull rapid mate connector system - high performance of
500 + mating cycles
• Sealed or non-sealed connector versions -
NON-SEALED VERSION:
• Available in 12mm and 16mm shell sizes
• From 2 up to 12 contacts of 1.0mm to 2.5mm diameter (see
back side for insert arrangement charts)
• Jam nut receptacle and straight plug are available with a
rubber boot or standard cable clamp rear accessory
• Non-reflective nickel or black epoxy finish
• IP55 rated
SEALED VERSION:
• Available in 10mm, 12mm, 16mm and 18mm shell sizes
• From 2 up to 14 contacts of 0.8mm to 2.5mm diameter (see
back side for insert arrangement charts)
• Jam nut receptacle and straight plug come with jacketed
cable PG sealing gland
• Non-reflective nickel finish only
• IP67 rated
• Three shell styles available: box mount and jam nut receptacles
and a straight plug
• Designed to IEC 61984
• Inserts have a UL94V-0 flammability rating
• Operating temperature: –40° to 100°C
• Solder contacts standard, crimp by special request
• Non-magnetic product standard
www.amphenol-industrial.com
How to Order
Amphe-PPM Sealed Connectors
APS
designates Amphe-PPM
Sealed Series Connectors
Shell Size:
C.....designates 10mm shell size
D.....designates 12mm shell size
E......designates 16mm shell size
F......designates 18mm shell size
Contact Type:
P......designates pin contacts
S......designates socket contacts
Insert Arrangement Designator
See Insert Arrangement Tables 1, 2, 3, 4
Table 1
Shell Size “C” 10mm
Table 2
Shell Size “D” 12mm
APS
D
S
A
6
E1
Sealing Range:
Diameters in mm
Series
E1
E2
C
N/A
N/A
3 - 6.5
PG7
D
3 - 6.5 PG7
4-8
PG9
E
4-8
PG9
7 - 12 PG13.5
F
7 - 12 PG13.5 10 - 14 PG16
Shell Style:
2......designates square flange receptacle
6......designates straight plug
7......designates jam nut receptacle
Table 3
Shell Size “E” 16mm
Contact
Insert
Diameter No. of
Arrangement (mm)
Contacts
A
1
2
B
1
3
C
0.8
4
D
0.8
5
Contact
Insert
Diameter No. of
Arrangement (mm)
Contacts
A
1.6
2
B
1
3
C
1
4
D
1
5
E
1
6
F
1
7
HOW TO ORDER
Amphe-PPM Non-Sealed Connectors
Contact
Diameter No. of
Insert
Contacts
(mm)
Arrangement
2
1.5
A
2
2.5
B
3
1
C
3
1.5
D
4
1
E
4
1.5
F
5
1
G
7
1
H
9
1
I
12
1
J
Table 4
Shell Size “F” 18mm
Contact
Insert
Diameter
No. of
Arrangement
(mm)
Contacts
A
2.5
3
B
1.5
5
8
C
1.5
(3 contacts)
, 1
(5 contacts)
D
1
5
APN
APN
designates Amphe-PPM
Non-Sealed Series Connectors
Shell Size:
A......designates 12mm shell size
B......designates 16mm shell size
Contact Type:
P......designates pin contacts
S......designates socket contacts
Insert Arrangement Designator
See Insert Arrangement Tables 5 & 6
A
S
A
6
N
R
Rear Accessory:
R.....designates with rubber boot
C.....designates with cable clamp
Shell Finish:
N.....designate non-reflective nickel finish
B......designates black epoxy finish
Shell Style:
2......designates square flange receptacle
6......designates straight plug
7......designates jam nut receptacle
Table 6
Shell Size “B” 16mm
Table 5
Shell Size “A” 12mm
Contact
Insert
Diameter No. of
Arrangement (mm)
Contacts
A
1.6
2
B
1
3
C
1
4
D
1
5
E
1
6
F
1
7
For additional information on the Amphe-PPM connectors consult Amphenol Industrial Operations
.
Contact
Insert
Diameter No. of
Arrangement
(mm)
Contacts
A
1.5
2
B
2.5
2
C
1
3
D
1.5
3
E
1
4
F
1.5
4
G
1
5
H
1
7
I
1
9
J
1
12
Notice: Specifications are subject to change without notice. Contact your nearest Amphenol Corporation Sales Office for the latest specifications. All statements, information and data given herein are believed to be accurate and reliable but are presented
without guarantee, warranty, or responsibility of any kind, expressed or implied. Statements of suggestions concerning possible use of our products are made without representation or warranty that any such use is free of patent infringement and are not
recommendations to infringe any patent. The user should assume that all safety measures are indicated or that other measures may not be required. Specifications are typical and may not apply to all connectors.
