1705346 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 1705346

1705346: DescriptionFixed Terminal Blocks GMKDS 3/11 BD:NZ07865620; CategoryThe connector; File Size90KB，4 Pages; ManufacturerPHOENIX CONTACT; Websitehttps://www.phoenixcontact.com

Download Datasheet Parametric View All

1705346 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1705346	-	-	View	Buy Now

1705346 Overview

Fixed Terminal Blocks GMKDS 3/11 BD:NZ07865620

1705346 Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	PHOENIX CONTACT
Product Category	Fixed Terminal Blocks
Shipping Restrictions	Mouser does not presently sell this product in your region.
Number of Positions	11 Position
Pitch	7.5 mm
Product	Fixed Terminal Blocks
Factory Pack Quantity	1
Unit Weight	0.860649 oz

Preview

Download Datasheet

View All

https://www.phoenixcontact.com/hq/products/1705346

PCB terminal block - GMKDS 3/11 BD:NZ07865620 - 1705346

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

PCB terminal block, Nominal current: 24 A, Nom. voltage: 630 V, Pitch: 7.5 mm, Number of positions: 11,

Connection method: Screw connection with tension sleeve, Mounting: Wave soldering, Conductor/PCB

connection direction: 0 °, Color: green

Key Commercial Data

Packing unit

GTIN

Custom tariff number

Note

4017918315283

85369010

Made to Order (non-returnable)

50 STK

Technical data

Dimensions

Length

Pitch

Dimension a

Constructional height

Length of the solder pin

Pin dimensions

Hole diameter

11.2 mm

7.50 mm

75 mm

18 mm

5 mm

0,9 x 0,9 mm

1.3 mm

General

Range of articles

Rated surge voltage (III/3)

Rated surge voltage (III/2)

Rated surge voltage (II/2)

Rated voltage (III/3)

Rated voltage (III/2)

Rated voltage (II/2)

Connection in acc. with standard

Nominal current I

Nominal cross section

Solder pin surface

GMKDS 3

6 kV

500 V

630 V

1000 V

EN-VDE

24 A

2.5 mm²

11/14/2016 Page 1 / 4
