Generated Part Number
KF85X-ED-9P-30
Part Number Builder
LR78160
D-SUBMINIATURE CONNECTORS:
KF85X
Series
KF85X Series
Dimensions
Dimensions in mm
KF85X
Series
E
Shell
Type
D
Pin
Type
9
Contact
Option
P
Contact
Type
Mounting
Option
30
Plating
Option
Vertical PCB Mount Low Profile with Ferrite
Series
KF85X
-
D-Subminiature Connector Vertical PCB
Termination, High Profile with Ferrite
Contact Shell Size
E
- 9 Contacts
A
- 15 Contacts
B
- 25 Contacts
C
- 37 Contacts
C
B
A, A1
8.36 Plug Interior
7.90 Socket Exterior
Contact Construction, Pin Type
D
- Precision Formed
Contact Type
P
- Pin Contact (Plug)
S
- Socket Contact (Receptacle)
Mounting Option
Blank
- Through Hole
BR
- With #4-40 Tin Plated 11.00mm Long Boardlocks
BRJ
- With #4-40 Tin Plated 11.00mm Long Boardlocks and
#4-40 Jackscrews
K
- With #4-40 Bushings
KJ
- With #4-40 Bushings and #4-40 Jackscrews
Plating Option
Blank
- Gold Flash
30
- 30µ” Gold
6.1 Plug
5.8 Socket
D
Ferrite Specifications
Test Frequency
30 Mhz
50 Mhz
100 Mhz
Number
of Contacts
(Shell Size)
Edge Hole
10-14 Ohms
12-18 Ohms
15-20 Ohms
Dimensions (Inch/mm)
Inner Hole
13-17 Ohms
15-19 Ohms
19-24 Ohms
9 (E)
15 (A)
25 (B)
37 (C)
A
.643
16.33
.971
24.66
1.511
38.38
2.159
54.84
A1
.666
16.92
.994
25.25
1.534
38.96
2.182
55.42
B
.984
24.99
1.312
33.32
1.852
47.04
2.500
63.50
C
1.213
30.81
1.541
39.14
2.088
53.04
2.729
69.32
D
.755
19.18
1.083
27.51
1.614
41.00
2.272
57.30
Contact Kycon for Other Options
A = Exterior of Female Shell (S)
A1 = Interior of Male Shell (P)
Phone: +1.408.494.0330
l
Fax: +1.408.494.0325
l
WWW.KYCON.COM
l
2013
