SERIES 200A SWITCHES
TACT
SWITCHES
TOGGLE SWITCHES - SUB-MINIATURE
SPECIFICATIONS
NAVIGATION
SWITCHES
Contact Rating:
Life Expectancy:
Contact Resistance:
Insulation Resistance:
Dependent on contact material
50,000 make-and-break cycles at full load
Below 20 m typ. initial @ 2-4 VDC,
100 mA, for both silver and gold plated contacts
1,000 M
1
min.
1,000 V RMS min. @ sea level
IP67
PUSHBUTTON
SWITCHES
Dielectric Strength:
Seal Rated:
Operating Temperature: -30° C to 85° C
TOGGLE
SWITCHES
MATERIALS
Case & Bushing:
Actuator:
Switch Support:
Contacts / Terminals:
Terminal Seal:
Glass filled nylon, flame retardant, heat stabilized
(UL 94-V0)
Brass, chrome plated, internal O-ring seal
standard for all actuators
Brass, tin plated
Silver or gold plated copper alloy
Epoxy
FEATURES & BENEFITS
ROCKER
SWITCHES
Variety of switching functions
Sub-miniature
Multiple actuator & bushing options
Sealed to IP67
APPLICATIONS/MARKETS
Telecommunications
Instrumentation
Networking
Medical equipment
SLIDE
SWITCHES
▲
▲
▲
HOW TO ORDER
SERIES
MODEL NO.
ACTUATOR
BUSHING
TERMINATION
CONTACT
MATERIAL
SEAL
SNAP-ACTION
SWITCHES
200A
WMSP1
WMSP2
WMSP3
WMSP4
WMSP5
WMSP6*
WMDP1
WMDP2
WMDP3
T1
T2
A1
M2
M6
M61
M7
VS2
Q = Silver
R = Gold
E
E = Epoxy
Sealed at
Base of
Terminal
DIP
SWITCHES
▲
▲
▲
KEYLOCK
SWITCHES
Example Ordering Number
200A_ WMSP2_ T1_ A1_ VS2_ Q_ E
*Only available with M2 or VS2
termination
Specifications subject to change without notice.
ROTARY
SWITCHES
SPDT
Epoxy Seal
POS 1
Model No.
WMSP-1
WMSP-2
WMSP-3
WMSP-4
WMSP-5
Term. Comm.
WMSP-6
Term. Comm.
ON
ON
ON
(ON)
ON
2-3
OFF
OPEN
POS 2
NONE
NONE
OFF
OFF
OFF
OPEN
NONE
NONE
POS 3
ON
(ON)
ON
(ON)
(ON)
2-1
ON
3-1
DETECTOR
SWITCHES
POS 3
POS 2
POS 1
CAP
OPTIONS
( ) = Momentary
SCHEMATIC
132
Phone: 800-867-2717
Fax: 763-531-8235
M7
DPDT
P.C. MOUNTING
VS2
SPDT
VS2
DPDT
P.C. MOUNTING
CONTACT MATERIAL OPTIONS
Q
Fixed Terminal:
Moving Contact:
Rating:
Silver plated copper alloy
Silver plated copper alloy
3 Amps @ 120VAC or 28VDC; 1 Amp @ 250VAC
R
Fixed Terminal:
Moving Contact:
Rating:
Copper alloy with gold plate over nickel plate
Copper alloy with gold plate over nickel plate
0.4 Volt-Amps (VA) max. @ 20V max. (AC or DC)
www.e-switch.com
info
@
e-switch.com
CAP
OPTIONS
DETECTOR
SWITCHES
ROTARY
SWITCHES
KEYLOCK
SWITCHES
DIP
SWITCHES
SNAP-ACTION
SWITCHES
SLIDE
SWITCHES
P.C. MOUNTING
ROCKER
SWITCHES
TOGGLE
SWITCHES
PUSHBUTTON
SWITCHES
NAVIGATION
SWITCHES
TACT
SWITCHES
135
