158 PUL-SI
www.vishay.com
Vishay BCcomponents
Aluminum Electrolytic Capacitors
Power Ultra Long Life Snap-In
FEATURES
• Useful life: 5000 h at +105 °C
• High ripple current capability
• Keyed polarity version available
• Polarized aluminum electrolytic capacitors, non-solid
electrolyte
• Large types, very small dimensions, cylindrical aluminum
case, insulated with a blue sleeve
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
058/059
PLL-SI
longer life
158
PUL-SI
miniaturized
85 °C
156
PUM-SI
APPLICATIONS
• General purpose, industrial telecommunication and audio /
video systems
• Smoothing and filtering
• Standard and switched mode power supplies
• Energy storage in pulse systems
090
PUL-SI
Fig. 1
QUICK REFERENCE DATA
DESCRIPTION
Nominal case sizes
(Ø D x L in mm)
Rated capacitance range
(E6 / E12 series), C
R
Tolerance on C
R
Rated voltage range, U
R
Category temperature range
Endurance test at 105 °C
Useful life at 105 °C
Useful life at 40 °C,
1.9 x I
R
applied
Shelf life at 0 V, 105 °C
Based on sectional
specification
Climatic category IEC 60068
VALUE
22 x 25 to 35 x 50
560 μF to 47 000 μF
± 20 %
16 V to 100 V
-40 °C to +105 °C
2000 h
5000 h
125 000 h
500 h
IEC 60384-4 / EN 130300
40 / 105 / 56
MARKING
The capacitors are marked (where possible) with the
following information:
• Rated capacitance (in μF)
• Tolerance on rated capacitance, code letter in accordance
with IEC 60062 (M for ± 20 %)
• Rated voltage (in V)
• Date code (YYMM)
• Name of manufacturer
• Code for factory of origin
• “-” sign to identify the negative terminal, visible from the
top and side of the capacitor
• Code number
• Climatic category in accordance with IEC 60068
SELECTION CHART FOR C
R
, U
R
, AND RELEVANT NOMINAL CASE SIZES
(Ø D x L in mm)
C
R
(μF)
560
820
1000
1200
1500
1800
U
R
(V)
16
-
-
-
-
-
-
-
-
-
25
-
-
-
-
-
-
-
-
-
40
-
-
-
-
-
-
-
-
-
50
-
-
-
-
-
22 x 25
-
-
-
63
-
-
-
-
22 x 25
22 x 30
-
-
-
80
-
22 x 25
-
-
22 x 30
22 x 35
25 x 30
25 x 35
-
100
22 x 25
22 x 30
22 x 35
25 x 30
25 x 35
-
25 x 40
-
30 x 30
Revision: 13-Oct-16
Document Number: 28375
1
For technical questions, contact:
aluminumcaps2@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
158 PUL-SI
www.vishay.com
Vishay BCcomponents
U
R
(V)
SELECTION CHART FOR C
R
, U
R
, AND RELEVANT NOMINAL CASE SIZES
(Ø D x L in mm)
C
R
(μF)
2200
2700
3300
3900
4700
5600
6800
8200
10 000
12 000
15 000
18 000
22 000
27 000
33 000
39 000
47 000
16
-
-
-
-
-
-
-
-
-
-
22 x 25
-
-
-
22 x 30
-
22 x 35
25 x 30
22 x 40
25 x 35
25 x 40
-
30 x 35
30 x 40
-
35 x 35
30 x 50
35 x 40
35 x 45
35 x 50
25
-
-
-
-
22 x 25
-
-
-
22 x 30
-
-
-
22 x 35
25 x 30
22 x 40
25 x 35
25 x 40
30 x 30
-
30 x 35
30 x 40
-
35 x 35
30 x 50
35 x 45
-
35 x 50
-
-
-
40
22 x 25
-
-
-
22 x 30
-
22 x 35
25 x 30
22 x 40
-
-
25 x 35
-
30 x 30
25 x 50
30 x 35
30 x 40
35 x 30
-
35 x 35
35 x 45
35 x 50
-
-
-
-
-
-
-
-
50
22 x 30
-
22 x 35
25 x 30
-
25 x 35
22 x 45
25 x 40
-
30 x 30
25 x 50
30 x 35
30 x 40
-
-
35 x 35
35 x 40
-
35 x 45
-
-
-
-
-
-
-
-
-
-
-
63
22 x 35
25 x 30
-
25 x 35
25 x 40
30 x 30
-
30 x 35
30 x 40
-
-
35 x 35
30 x 50
35 x 40
35 x 45
-
35 x 50
-
-
-
-
-
-
-
-
-
-
-
-
-
80
25 x 40
30 x 30
-
30 x 35
25 x 50
-
30 x 40
-
35 x 35
-
35 x 40
-
35 x 50
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
100
30 x 35
-
30 x 40
-
30 x 50
35 x 35
35 x 40
-
35 x 50
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
DIMENSIONS
in millimeters
AND AVAILABLE FORMS
TWO TERMINAL SNAP-IN
ØD
+ Terminal
- Terminal
L
L + 2 max.
10
± 0.1
Bottom view
0
5.8
+ 1
mm
-
The minus terminal can be marked with a black dot or
with an imprinted “-”
sign.
Ø 2 ± 0.1 (2 x)
Fig. 2 - Two terminal snap-in
Fig. 3 - Mounting hole diagram
Revision: 13-Oct-16
Document Number: 28375
2
For technical questions, contact:
aluminumcaps2@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
158 PUL-SI
www.vishay.com
THREE TERMINAL SNAP-IN
Ø 2 ± 0.1 (2 x)
Ø 2.5 ± 0.1
ØD
Vishay BCcomponents
+ Terminal
- Terminal
Minus pole
marking
Bottom view
10 ± 0.1
L
L + 2 max.
3.3 ± 0.1
4 ± 0.5
4.75 ± 0.1
The 10 mm
spacing
of the 2 pin
snap-in
is used as the base
layout and a third hole is added.
The third hole is closer to the negative primary hole
so
that
polarization is always maintained, together with added
mechanical
stability.
The negative terminal has
TWO
pins which are
BOTH
electrically connected.
Fig. 4 - Three terminal snap-in
Fig. 5 - Mounting hole diagram
Table 1
DIMENSIONS
in millimeters,
MASS AND PACKAGING QUANTITIES
NOMINAL
CASE SIZE
ØDxL
22 x 25
22 x 30
22 x 35
22 x 40
25 x 30
25 x 35
25 x 40
25 x 50
30 x 30
30 x 35
30 x 40
30 x 50
35 x 35
35 x 40
35 x 45
35 x 50
Ø D
max.
23
23
23
23
26
26
26
26
31
31
31
31
36
36
36
36
L
max.
27
32
37
42
32
37
42
52
32
37
42
52
37
42
47
52
MASS
(g)
12
16
20
23
22
24
27
38
30
35
40
50
48
55
63
72
PACKAGING QUANTITIES
(units per box)
100
100
100
100
100
100
100
100
100
100
100
100
50
50
50
50
CARDBOARD BOX DIMENSIONS
LxWxH
260 x 250 x 39
260 x 250 x 44
260 x 250 x 49
260 x 250 x 54
290 x 280 x 44
290 x 280 x 49
290 x 280 x 54
290 x 280 x 64
340 x 330 x 44
340 x 330 x 49
340 x 330 x 54
340 x 330 x 64
390 x 198 x 49
390 x 198 x 54
390 x 198 x 59
390 x 198 x 64
Revision: 13-Oct-16
Document Number: 28375
3
For technical questions, contact:
aluminumcaps2@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
158 PUL-SI
www.vishay.com
Vishay BCcomponents
ORDERING EXAMPLE
Electrolytic capacitor 158 series
3900 μF / 80 V; ± 20 %
Nominal case size: Ø 30 mm x 40 mm
2-terminal snap-in:
Ordering code: MAL2 158 32392 E3
Former 12NC: 2222 158 32392
3-terminal snap-in:
Ordering code: MAL2 158 72392 E3
Former 12NC: 2222 158 72392
ELECTRICAL DATA
SYMBOL
C
R
I
R
I
L5
ESR
Z
DESCRIPTION
Rated capacitance at 100 Hz
Rated RMS ripple current at 100 Hz, 105 °C
Max. leakage current after 5 min at U
R
Typ. / max. equivalent series resistance at 100 Hz
(1)
Typ. / max. impedance at 10 kHz
Notes
(1)
ESR at 120 Hz is approximately 0.95 x ESR 100 Hz
• Unless otherwise specified, all electrical values in Table 2 apply
at T
amb
= 20 °C, P = 86 kPa to 106 kPa, RH = 45 % to 75 %
Table 2
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
C
R
100 Hz
(μF)
5600
8200
10 000
10 000
12 000
12 000
15 000
16
15 000
18 000
22 000
27 000
33 000
33 000
39 000
47 000
3300
4700
6800
6800
8200
8200
10 000
25
10 000
12 000
15 000
18 000
22 000
22 000
27 000
33 000
NOMINAL
CASE SIZE
ØDxL
(mm)
22 x 25
22 x 30
22 x 35
25 x 30
22 x 40
25 x 35
25 x 40
30 x 30
30 x 35
30 x 40
35 x 35
30 x 50
35 x 40
35 x 45
35 x 50
22 x 25
22 x 30
22 x 35
25 x 30
22 x 40
25 x 35
25 x 40
30 x 30
30 x 35
30 x 40
35 x 35
30 x 50
35 x 40
35 x 45
35 x 50
I
R
100 Hz
105 °C
(A)
2.50
3.10
3.56
3.42
4.00
3.91
4.39
3.80
4.36
4.85
4.49
5.70
4.97
5.42
5.80
2.27
2.82
3.37
3.25
3.79
3.72
4.18
3.65
4.19
4.66
4.36
5.52
4.83
5.24
5.32
I
R
10 kHz
105 °C
(A)
2.95
3.66
4.20
4.04
4.72
4.61
5.18
4.48
5.14
5.72
5.30
6.73
5.86
6.40
6.84
2.68
3.33
3.98
3.84
4.47
4.39
4.93
4.31
4.94
5.50
5.14
6.51
5.70
6.18
6.27
I
L5
5 min
(mA)
0.18
0.27
0.32
0.32
0.39
0.39
0.48
0.48
0.58
0.71
0.87
1.06
1.06
1.25
1.51
0.17
0.24
0.34
0.34
0.41
0.41
0.50
0.50
0.60
0.75
0.90
1.10
1.10
1.35
1.65
MAX. ESR
100 Hz
(1)
(m)
111
79
65
70
56
59
49
61
50
43
49
33
42
37
33
130
93
69
74
58
62
52
64
53
45
51
35
44
39
36
MAX. Z
10 kHz
(m)
98
70
58
63
50
53
45
55
46
39
43
31
37
33
30
105
76
57
62
49
52
44
55
46
39
43
31
37
33
31
ORDERING CODE
MAL2158.......
2-TERM.
15562E3
15822E3
15103E3
25103E3
15123E3
25123E3
25153E3
35153E3
35183E3
35223E3
45273E3
35333E3
45333E3
45393E3
45473E3
16332E3
16472E3
16682E3
26682E3
16822E3
26822E3
26103E3
36103E3
36123E3
36153E3
46183E3
36223E3
46223E3
46273E3
46333E3
3-TERM.
55562E3
55822E3
55103E3
65103E3
55123E3
65123E3
65153E3
75153E3
75183E3
75223E3
85273E3
75333E3
85333E3
85393E3
85473E3
56332E3
56472E3
56682E3
66682E3
56822E3
66822E3
66103E3
76103E3
76123E3
76153E3
86183E3
76223E3
86223E3
86273E3
86333E3
Revision: 13-Oct-16
Document Number: 28375
4
For technical questions, contact:
aluminumcaps2@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
158 PUL-SI
www.vishay.com
Vishay BCcomponents
I
R
100 Hz
105 °C
(A)
2.17
2.73
3.12
3.02
3.52
3.53
3.39
4.72
3.90
4.36
4.00
4.99
5.36
1.99
2.50
2.88
2.81
3.27
3.23
3.62
3.24
4.43
3.73
4.17
3.88
4.33
4.72
2.07
2.49
3.00
2.90
3.34
3.76
3.28
3.77
4.22
3.97
5.04
4.42
4.82
5.17
I
R
10 kHz
105 °C
(A)
2.65
3.33
3.81
3.68
4.29
4.31
4.14
5.76
4.76
5.32
4.88
6.09
6.54
2.43
3.05
3.51
3.43
3.99
3.94
4.42
3.95
5.40
4.55
5.09
4.73
5.28
5.76
2.53
3.04
3.66
3.54
4.07
4.59
4.00
4.60
5.15
4.84
6.15
5.39
5.88
6.31
ORDERING CODE
MAL2158.......
2-TERM.
17222E3
17332E3
17392E3
27392E3
17472E3
27562E3
37682E3
27822E3
37822E3
37103E3
47123E3
47153E3
47183E3
11152E3
11222E3
11272E3
21272E3
11332E3
21332E3
21392E3
31472E3
21562E3
31562E3
31682E3
41822E3
41103E3
41123E3
18122E3
18152E3
18222E3
28222E3
28272E3
28332E3
38332E3
38392E3
38472E3
48562E3
38682E3
48682E3
48822E3
48103E3
3-TERM.
57222E3
57332E3
57392E3
67392E3
57472E3
67562E3
77682E3
67822E3
77822E3
77103E3
87123E3
87153E3
87183E3
51152E3
51222E3
51272E3
61272E3
51332E3
61332E3
61392E3
71472E3
61562E3
71562E3
71682E3
81822E3
81103E3
81123E3
58122E3
58152E3
58222E3
68222E3
68272E3
68332E3
78332E3
78392E3
78472E3
88562E3
78682E3
88682E3
88822E3
88103E3
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
C
R
100 Hz
(μF)
2200
3300
3900
3900
4700
5600
40
6800
8200
8200
10 000
12 000
15 000
18 000
1500
2200
2700
2700
3300
3300
50
3900
4700
5600
5600
6800
8200
10 000
12 000
1200
1500
2200
2200
2700
3300
63
3300
3900
4700
5600
6800
6800
8200
10 000
NOMINAL
CASE SIZE
ØDxL
(mm)
22 x 25
22 x 30
22 x 35
25 x 30
22 x 40
25 x 35
30 x 30
25 x 50
30 x 35
30 x 40
35 x 35
35 x 45
35 x 50
22 x 25
22 x 30
22 x 35
25 x 30
22 x 40
25 x 35
25 x 40
30 x 30
25 x 50
30 x 35
30 x 40
35 x 35
35 x 40
35 x 45
22 x 25
22 x 30
22 x 35
25 x 30
25 x 35
25 x 40
30 x 30
30 x 35
30 x 40
35 x 35
30 x 50
35 x 40
35 x 45
35 x 50
I
L5
5 min
(mA)
0.18
0.27
0.32
0.32
0.38
0.45
0.55
0.66
0.66
0.80
0.96
1.20
1.44
0.15
0.22
0.27
0.27
0.33
0.33
0.39
0.47
0.56
0.56
0.68
0.82
1.00
1.20
0.16
0.19
0.26
0.28
0.34
0.42
0.42
0.50
0.60
0.71
0.86
0.86
1.04
1.26
MAX. ESR
100 Hz
(1)
(m)
131
91
77
83
65
63
69
44
57
48
56
42
38
148
104
85
91
71
75
64
74
48
61
52
61
52
46
137
107
79
85
70
59
74
61
52
59
40
51
45
40
MAX. Z
10 kHz
(m)
100
70
59
65
51
51
56
36
47
40
45
35
31
102
73
60
66
51
55
47
57
36
47
41
46
40
35
100
78
58
64
53
45
58
48
41
47
33
40
35
32
Revision: 13-Oct-16
Document Number: 28375
5
For technical questions, contact:
aluminumcaps2@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
京公网安备 11010802033920号
EEWORLD
