Datasheet> All Categories > Passive components> inductor> 2000-5R6-V-RC

Preview

2000-5R6-V-RC: DescriptionFixed Inductors 5.6uH 20% Vertical; CategoryPassive components inductor; File Size85KB，1 Pages; ManufacturerBourns; Websitehttp://www.bourns.com; Environmental Compliance

Download Datasheet Parametric View All

2000-5R6-V-RC Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	2000-5R6-V-RC	-	-	View	Buy Now

2000-5R6-V-RC Overview

Fixed Inductors 5.6uH 20% Vertical

2000-5R6-V-RC Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	14 weeks
structure	Vertical Mount
DC Resistance	0.0084 Ω
Nominal inductance(L)	5.6 µH
Inductor Applications	HIGH CURRENT INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e3
Lead diameter	1.0668 mm
lead spacing	8.382 mm
Number of functions	1
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Package diameter	17.272 mm
Package length	10.414 mm
Package form	Radial
Maximum rated current	9.7 A
Shape/Size Description	CYLINDRICAL PACKAGE
shield	YES
surface mount	NO
Terminal surface	Tin (Sn)
Terminal location	RADIAL
Terminal shape	WIRE
Test frequency	0.001 MHz
Tolerance	20%
Base Number Matches	1

Preview

Download Datasheet

View All

CO

M

PL

IA

NT

High Current Toroid Inductors

L (µH)

±20 %

@ 1 KHz

1.2

3.3

3.9

4.7

5.6

6.8

8.2

10

12

15

18

22

27

33

39

47

†

Ro

HS

Special Features

• Low radiation

• Low core loss

• High operation frequency

• High current capacity

• Low core saturation

• Horizontal or vertical mount

• Operating temperature: -55 to +105 °C

Part

Number

2000-1R2-RC

2000-3R3-RC

2000-3R9-RC

2000-4R7-RC

2000-5R6-RC

2000-6R8-RC

2000-8R2-RC

2000-100-RC

2000-120-RC

2000-150-RC

2000-180-RC

2000-220-RC

2000-270-RC

2000-330-RC

2000-390-RC

2000-470-RC

2000 Series

L (µH)

Idc*

±20 %

(A)

@ I rated

20.2

11.1

10.5

10.1

9.7

7.2

7.0

6.6

6.4

4.7

4.5

4.3

4.1

3.5

3.3

3.2

0.86

2.5

3.0

3.5

4.0

5.7

6.4

7.9

8.7

12.4

14.5

16.7

20.4

25.4

29.9

34.6

DCR

Ω

Max.

0.0022

0.0067

0.0074

0.0077

0.0084

0.013

0.014

0.015

0.016

0.029

0.032

0.035

0.039

0.054

0.059

0.064

Dim.

A

Nom.

0.35

0.33

0.31

0.29

Dim.

B

Nom.

0.60

0.58

0.56

0.53

Dim.

C

Nom.

0.059

0.042

0.034

0.027

0.024

Typical Applications

• High current, low voltage converters

• High-speed computers

• Video game machines

• Output chokes

• EMI filters

LE

AD

FR

EE

Notes

* Rated current to cause 40 °C temperature rise.

** Insert “-H” or “-V” for mounting style before “-RC”.

Example: 2000-390-V-RC

† RoHS Directive 2002/95/EC Jan 27 2003

including Annex.

Tel. (877) 426-8767 • Fax (951) 781-5006

REV. 02/17

Ro VE LEA

HS RS D

CO ION FRE

M SA E

PL R

IA E

NT

*

www.bourns.com

23.1
