• Axial leads, cylindrical aluminum case, insulated with a
blue sleeve
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
041-043
ASH
standard
042/043 AHH-ELB
550 V/24 h
85 °C
042/043 AMH-ELB
550 V/24 h
Fig. 1
APPLICATIONS
QUICK REFERENCE DATA
DESCRIPTION
Nominal case sizes (Ø D x L in mm)
Rated capacitance range, C
R
Tolerance on C
R
Rated voltage, U
R
Category temperature range
Endurance test at 105 °C
Useful life at 105 °C
Useful life at 85 °C I
R
applied
Shelf life at 0 V, 105 °C
Based on sectional specification
Climatic category IEC 60068
VALUE
12.5 x 30 to 18 x 38
6.8 μF to 33 μF
-10 % to +50 %
450 V
-25 °C to +105 °C
5000 h
10 000 h
100 000 h
500 h
IEC 60384-4 / EN 130300
25 / 105 / 56
• Electronic lighting ballast, power supply
• Smoothing, filtering, buffering at high voltages
• Boards with restricted mounting height, vibration, and
shock resistant
MARKING
The capacitors are marked (where possible) with the
following information:
• Rated capacitance (in μF)
• Tolerance on rated capacitance, code letter in accordance
with IEC 60062 (T for -10 % to +50 %)
• Rated voltage (in V)
• Upper category temperature (105 °C)
• Date code, in accordance with IEC 60062
• Code for factory of origin
• Name of manufacturer
• Negative terminal identification
• Series number (042 or 043)
DIMENSIONS
in millimeters
AND AVAILABLE FORMS
73 ± 1.6
ØD
L
Ød
Ød
ØD
I
L
33 ± 1
F
F
Form BR:
Taped on reel
Case Ø D x L = 6.5 mm x 18 mm to 15 mm x 30 mm
Form AA:
Axial in box
Case Ø D x L = 10 mm x 30 mm to 21 mm x 38 mm
Fig. 2 -
Form BR
Fig. 3 -
Form AA
Revision: 09-Jan-17
Document Number: 28331
1
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
042 AHH-ELB, 043 AHH-ELB
www.vishay.com
Table 1
Vishay BCcomponents
AXIAL; DIMENSIONS
in millimeters,
MASS AND PACKAGING QUANTITIES
NOMINAL
CASE SIZE
ØDxL
12.5 x 30
15 x 30
18 x 30
18 x 38
CASE
CODE
01
02
03
04
AXIAL: FORM AA AND BR
ØD
0.8
0.8
0.8
0.8
L
55 ± 1
55 ± 1
55 ± 1
34 ± 1
Ø D
max.
13.0
15.5
18.5
18.5
L
max.
30.5
30.5
30.5
39.5
F
min.
35
35
35
44
MASS
(g)
6.1
8.3
11.6
16.0
PACKAGING QUANTITIES
FORM
FORM
AA
BR
260
400
200
250
120
-
125
-
Note
• For detailed tape dimensions please refer to packaging information:
www.vishay.com/doc?28361
ELECTRICAL DATA
SYMBOL
C
R
I
R
I
L5
ESR
Z
DESCRIPTION
Rated capacitance at 100 Hz,
tolerance -10 % to+50 %
Rated RMS ripple current at 10 kHz, 105 °C
Max. leakage current after 5 min at U
R
Typ. / max. equivalent series resistance at 100 Hz
Typ. / max. impedance at 10 kHz
ORDERING EXAMPLE
Electrolytic capacitor 042 series
10 μF / 450 V; -10 % / +50 %
Nominal case size: Ø 12.5 mm x 30 mm; Form BR
Ordering code: MAL204272109E3
Former 12NC: 2222 042 72109
Note
• Unless otherwise specified, all electrical values in Table 2 apply
at T
amb
= 20 °C, P = 86 kPa to 106 kPa, RH = 45 % to 75 %.
Table 2
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
C
R
100 Hz
(μF)
6.8
10
15
22
33
NOMINAL
CASE SIZE
ØDxL
(mm)
12.5 x 30
12.5 x 30
15 x 30
18 x 30
18 x 38
I
R
10 kHz
105 °C
(mA)
390
470
600
750
1020
I
L5
5 min
(μA)
106
110
115
120
130
ESR
TYP.
100 Hz
()
4.2
2.9
1.9
1.2
0.9
ESR
MAX.
100 Hz
()
8.7
5.9
3.9
2.5
1.8
Z
TYP.
10 kHz
()
3.1
2.0
1.3
1.0
0.7
Z
MAX.
10 kHz
()
5.1
3.3
2.3
1.5
1.1
ORDERING CODE MAL2..........
AXIAL
IN BOX
TAPED ON REEL
FORM AA
FORM BR
04271688E3
04272688E3
04271109E3
04272109E3
04271159E3
04272159E3
04271229E3
-
04371339E3
-
450
ADDITIONAL ELECTRICAL DATA
PARAMETER
Voltage
Surge voltage
Overvoltage test
Reverse voltage
Current
Leakage current
Inductance
Case Ø D x L in mm:
12.5 x 30
15 x 30
18 x 30
18 x 38
Typ. 46 nH
Typ. 48 nH
Typ. 50 nH
Typ. 54 nH
U
R
= 450 V
24 h at 85 °C
U
s
550 V
550 V
(1)
U
rev
1 V
I
L1
0.009 x C
R
x U
R
+ 200 μA
I
L5
0.002 x C
R
x U
R
+ 100 μA
CONDITIONS
VALUE
After 1 min
After 5 min
Equivalent series inductance
Note
(1)
Test conditions on request.
Revision: 09-Jan-17
Document Number: 28331
2
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
042 AHH-ELB, 043 AHH-ELB
www.vishay.com
CAPACITANCE (C)
1.1
C
C
0
1.0
Vishay BCcomponents
0.9
0.8
0.7
- 40
- 20
0
20
40
60
80
100
120
C
0
= Capacitance at 20 °C, 100 Hz
T
amb
(°C)
Fig. 4 - Typical multiplier of capacitance as a function
of ambient temperature
EQUIVALENT SERIES RESISTANCE (ESR)
10
2
ESR
ESR
0
10
2
Curve 1: 100 Hz
Curve 2: 1 kHz
Curve 3: 10 kHz
ESR
ESR
0
10
Curve 1: T
amb
= 20 °C
Curve 2: T
amb
= 40 °C
Curve 3: T
amb
= 60 °C
Curve 4: T
amb
= 85 °C
Curve 5: T
amb
= 105 °C
1
2
3
4
5
10
1
1
1
2
10
-1
3
- 20
0
20
40
60
80
100
120
10
-1
- 40
10
10
2
10
3
10
4
f (Hz)
10
5
ESR
0
= Typical at 20 °C, 100 Hz
T
amb
(°C)
ESR
0
= Typical at 20 °C, 100 Hz
Fig. 5 - Typical multiplier of ESR as a function of
ambient temperature at different frequencies
10
2
10
3
Z
(
Ω
)
10
2
10
10
Fig. 6 - Typical multiplier of ESR as a function of frequency
at different ambient temperatures
1
2
3
4
Curve 1: 10 µF,
Case Ø D x L = 12.5 mm x 30 mm
Curve 2: 15 µF,
Case Ø D x L = 15 mm x 30 mm
Curve 3: 22 µF,
Case Ø D x L = 18 mm x 30 mm
Curve 4: 33 µF,
Case Ø D x L = 18 mm x 38 mm
1
1
10
-1
10
−1
- 20
0
20
40
60
80
100
120
10
10
2
10
3
10
4
10
5
6
f (Hz) 10
- 40
Z
0
= Impedance at 20 °C, 100 Hz
T
amb
(°C)
T
amb
= 20 °C
Fig. 7 - Typical multiplier of impedance as a function
of ambient temperature
Revision: 09-Jan-17
Fig. 8 - Typical impedance as a function of frequency
Document Number: 28331
3
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
042 AHH-ELB, 043 AHH-ELB
www.vishay.com
RIPPLE CURRENT AND USEFUL LIFE
Table 3
Vishay BCcomponents
ENDURANCE TEST DURATION AND USEFUL LIFE
ENDURANCE AT 105 °C (h)
5000
Note
• Multiplier of useful life code: CCC122
6
I
A
I
R
5
CCC122
USEFUL LIFE AT 105 °C (h)
10 000
4
3
Lifetime multiplier
2
1
1.0
2.0
5.0
10
(1)
0
40
50
60
70
80
90
100
110
120
I
A
= Actual ripple current at 10 kHz
I
R
= Rated ripple current at 10 kHz, 105 °C
(1)
T
amb
= 20 °C
Useful life at 105 °C and I
R
applied: 10 000 h
Fig. 9 - Multiplier of useful life as a function of ambient temperature
and ripple current load
Table 4
MULTIPLIER OF RIPPLE CURRENT (I
R
) AS A FUNCTION OF FREQUENCY
FREQUENCY (Hz)
50
100
300
I
R
MULTIPLIER
0.20
0.27
0.45
0.68
0.82
1.00
1000
3000
10 000
Note
• Formula (1) should be used to calculate the actual ripple current at 10 kHz (see Fig. 9) when multiple frequencies are present. For an example
of the values 100 Hz and 50 kHz:
I
100 Hz
2
I
50 kHz
2
(1)
I
A
=
--------------------------
+
--------------------------
-
-
0.27
1.0
Revision: 09-Jan-17
Document Number: 28331
4
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
042 AHH-ELB, 043 AHH-ELB
www.vishay.com
Table 5
Vishay BCcomponents
TEST PROCEDURES AND REQUIREMENTS
TEST
NAME OF TEST
REFERENCE
IEC 60384-4 /
EN130300
subclause 4.13
PROCEDURE
(quick reference)
REQUIREMENTS
C/C:
± 10 %
tan
1.3 x spec. limit
Z
2 x spec. limit
I
L5
spec. limit
C/C:
± 30 %
tan
3 x spec. limit
Z
3 x spec. limit
I
L5
spec. limit
No short or open circuit
Total failure percentage:
3 %
C/C,
tan
,
Z:
For requirements
see “Endurance test” above
I
L5
2 x spec. limit
Endurance
T
amb
= 105 °C; U
R
applied;
5000 h
Useful life
CECC 30301
subclause 1.8.1
T
amb
= 105 °C; U
R
and I
R
applied;
10 000 h
Shelf life
(storage at high
temperature)
IEC 60384-4 /
EN130300
subclause 4.17
T
amb
= 105 °C; no voltage applied;
500 h
After test: U
R
to be applied for 30 min,
24 h to 48 h before measurement
Statements about product lifetime are based on calculations and internal testing. They should only be interpreted as estimations. Also due to external factors, the
lifetime in the field application may deviate from the calculated lifetime. In general, nothing stated herein shall be construed as a guarantee of durability.
Revision: 09-Jan-17
Document Number: 28331
5
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
[font=微软雅黑][size=3]The world's first flexible smart screen mobile phone: [url=https://training.eeworld.com.cn/course/3554See more EE University's wonderful maker videos[/url][/b][/color][/size][/font]...
[i=s] This post was last edited by bqgup on 2021-8-23 19:43 [/i] #I'm addicted to C language! Please help me read "Number Processing and Judgment" ##Problem description##My code ``` cpp #include
#incl...
What should I do if I want to post a picture in a post on eeworld? If I delete the picture from my computer, I will not be able to see it on the eeworld website....
[color=#000000] The acquisition device I made recently uses low-power MSP430. The main control chip needs to complete three functions: constant current chip drive (four pin outputs), 8-channel ADC con...
Hello, Teacher Xia! :)I am working on Manchester decoding recently. When I reached the step of extracting the synchronous signal, I extracted the edge signal of the Manchester code into a pulse signal...
1. Several nouns
ABI:
The specifications that an executable file must follow in order to run in a specific execution environment;
Separately generated relocatabl...[Details]
On August 24th, Tesla CEO Elon
Musk
revealed information about the upcoming FSD V14, claiming it will outperform human drivers. Tesla FSD lead Ashok stated last year that FSD version 12.5, ...[Details]
Most of the houses we live in now are elevator buildings, mainly because it is more convenient to go up and down the stairs! It can also make life more comfortable. It even helps to increase the ad...[Details]
Whether it is an electric car or an ordinary fuel car, for the vast majority of car buyers, the final cost of use is what they care about most. For fuel cars, how to save fuel is what drivers care ...[Details]
On August 22, according to the Ministry of Industry and Information Technology's official website, my country's first mandatory national standard for the control of hazardous substances in electric...[Details]
As AI accelerates across industries, the demand for data center infrastructure is also growing rapidly.
Keysight Technologies, in collaboration with Heavy Reading, released the "Beyo...[Details]
Tires are a very important component for cars. They are related to the driving experience of the vehicle. We are almost inseparable from cars in our daily lives. For tires, according to the role of...[Details]
Permanent magnets are essential components in a wide range of household and industrial devices. They are particularly crucial in the renewable energy sector, including electric vehicle motors. Curr...[Details]
1. Ease of Use: The HMI module should be designed to be simple and clear, allowing users to easily operate and configure the energy storage device.
2. Ease of Maintenance: The HMI module should...[Details]
On August 22, according to CNBC's report today, the National Highway Traffic Safety Administration (NHTSA) is launching an investigation into Tesla, and the latter is questioned whether it has fail...[Details]
1. Fault phenomenon and cause analysis
1. During the operation of the equipment, the expansion sleeve is subjected to a large torque, and the mating surfaces of the shaft and the sleeve move...[Details]
Magna's integrated in-cabin perception system fuses vision and millimeter-wave radar data to detect the presence of passengers, identify stranded children, monitor driver fatigue and vital signs, a...[Details]
To improve the lateral active safety of intelligent connected vehicles, the identification and definition of unexpected functional safety scenarios for the EPS (Electronic Steering System) ...[Details]
In the field of communications power supplies, AC/DC rectifier power supplies are called primary power supplies or basic power supplies, while DC/DC converters are called secondary power supplies. ...[Details]
Renesas Electronics' new ultra-low-power RA4C1 MCU features advanced security and a dedicated peripheral set, making it ideal for metering and other applications.
The new product mee...[Details]
Integrated technical exchanges
京公网安备 11010802033920号
EEWORLD
