BZT52C5V6S-TP

Description
Zener Diodes 200mW 5.6V
Categorysemiconductor    Discrete semiconductor
File Size321KB,4 Pages
ManufacturerMCC
Websitehttp://www.mccsemi.com
Download Datasheet Parametric View All

BZT52C5V6S-TP Online Shopping

Suppliers Part Number Price MOQ In stock
BZT52C5V6S-TP - - View Buy Now

BZT52C5V6S-TP Overview

Zener Diodes 200mW 5.6V

BZT52C5V6S-TP Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerMCC
Product CategoryZener Diodes
RoHSDetails
Vz - Zener Voltage5.6 V
Mounting StyleSMD/SMT
Package / CaseSOD-323-2
Pd - Power Dissipation200 mW
Voltage Tolerance-
Voltage Temperature Coefficient- 2 mV/C
Zener Current1 uA
Zz - Zener Impedance40 Ohms
Minimum Operating Temperature- 65 C
Maximum Operating Temperature+ 150 C
ConfigurationSingle
Test Current5 mA
PackagingCut Tape
PackagingMouseReel
PackagingReel
Height1 mm
Length1.8 mm
ProductZener Diode
Width1.35 mm
Ir - Reverse Current1 uA
Factory Pack Quantity3000
Vf - Forward Voltage0.9 V
Unit Weight0.001164 oz
MCC
Micro Commercial Components
TM
  omponents
20736 Marilla
Street Chatsworth

  !"#
$ %    !"#
BZT52C2V4S
THRU
BZT52C39S
200 mW
Zener Diode
2.4 to 39 Volts
Features
Planar Die Construction
200mW Power Dissipation on Ceramic PCB
General Purpose Medium Current
Ideally Suited for Automated Assembly Processes
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Lead Free Finish/RoHS Compliant("P" Suffix
designates RoHS Compliant. See ordering information)
Halogen
free available upon request by adding suffix "-HF"
SOD-323
A
B
Unit
mW
Absolute Maximum Ratings
Symbol
P
D
T
J
T
STG
Parameter
Power dissipation
Junction Temperature
Storage Temperature Range
Rating
200
-65 to +150
-65 to +150
C
E
H
D
Absolute Maximum Ratings
Symbol
R
thJA
Parameter
Thermal Resistance Junction to
Ambient*
Rating
625
Unit
G
J
DIM
/W
* Device mounted on ceramic PCB: 7.6mm x 9.4mm x 0.87mm with
pad areas 25
mm
2
Electrical Characteristics
Symbol
Parameter
Rating
Unit
A
B
C
D
E
G
H
J
DIMENSIONS
INCHES
MM
MIN
MAX
MIN
MAX
.090
.107
2.30
2.70
.063
.071
1.60
1.80
.045
.053
1.15
1.35
.031
.045
0.80
1.15
.010
.016
0.25
0.40
.004
.018
0.10
0.45
.004
.010
0.10
0.25
-----
.006
-----
0.15
SUGGESTED SOLDER
PAD LAYOUT
NOTE
V
F
Maximum Forward Voltage
(I
F
=10mAdc)
0.9
V
0.074"
0.027”
0.022”
Revision:
B
www.mccsemi.com
1 of
3
2014/01/01
