REVISIONS
DESCRIPTION
UPDATED FOOTPRINT AND DIMENSIONS; ADDED NEW
TITLE BLOCK
1
DATE
29-JUN-12
17-OCT-12
3-MAY-16
APPV
BPM
BPM
SAH
DESCRIPTION MATERIAL
BODY
SOCKET
INSULATION
D
FINISH
NICKEL
GOLD
N/A
BRASS
BeCu
PTFE
C ADDED SOCKET TO PCB DIMENSION
TO STANDOFF DIMENSION; UPDATED
D ADDED CONTACT VARIOUS DIMENSIONS
NOTE 3; UPDATED
D
0.598
15.20
0.102
2.60
4X S 0.057
1.45
0.180
4.56
0.113
2.88
C
0.425
10.80
0.291
7.40
0.210
5.34
0.050
1.28
S 0.276
7.00
0.081
2.05
0.057
1.44
0.096
2.44
0.153
3.88
0.306
7.76
C
0.051
1.30
0.047
1.20
1/4-36UNS-2A
THREADS
A
B
B
SIDE VIEW
BOTTOM VIEW
RECOMMENDED FOOTPRINT
NOTES: (UNLESS OTHERWISE SPECIFIED)
1. ALL DIMENSIONS ARE IN INCHES [mm].
2. DIMENSIONS APPLY AFTER FINISHING.
3. MANUFACTURE TO BE COMPLIANT WITH EU RoHS DIRECTIVE, USE
MATERIALS THAT DO NOT CONTAIN REACH SUBSTANCES OF VERY
HIGH CONCERN >1000ppm, AND USE DRC CONFLICT-FREE
SOURCED MATERIALS.
4. SAFETY BREAK ALL SHARP CORNERS AND EDGES .02 MAXIMUM.
A
0.004 CENTER CONTACT TO MOUNTING PLANE STAND-OFF
0.000
0.10
0.00
WARNING:
THIS DRAWING CONTAINS PROPRIETARY INFORMATION
THAT IS THE SOLE PROPERTY OF LINX TECHNOLOGIES, AND SHALL BE
TREATED AS SUCH. NO DISCLOSURE OR REPRODUCTION OF THIS
DOCUMENT IS PERMITTED, IN WHOLE OR IN PART, WITHOUT THE
EXPRESS WRITTEN PERMISSION OF LINX TECHNOLOGIES OR ITS
DESIGNATED AGENTS.
INTERPRET DIMENSIONS AND
TOLERANCES PER ASME Y14.5.
32
DETAIL A
SCALE 12 : 1
6
5
4
TITLE:
159 ORT LANE
MERLIN, OR 97532
A
MATERIAL:
PROJECTION:
FINISH:
SURFACE FINISH:
ANGLES: 1
TOLERANCES: .X .1 .XX .01 .XXX .005
SIZE DWG. NO.
SMA FEMALE RIGHT ANGLE
SURFACE MOUNT
DRAWN: B.MURPHY DT: 29-JUN-12
CONSMA002-SMD
ENGR: S.HOGAN
DT: 29-JUN-12 SCALE: 6:1
DO NOT SCALE DRAWING
2
1
B
REV
SHEET 1 OF 1
LDCFDFB_C
D
8
7
3
