ALUMINUM ELECTROLYTIC CAPACITORS
TVX
Standard, For General Purposes - Axial Lead Type
(02 type)
(Through 100V only)
Axial lead type of standard series for general purposes.
Compliant to the RoHS directive (2011/65/EU).
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Performance Characteristics
–40 to +85°C (6.3 to 250V), –25 to +85°C (315 to 450V)
6.3 to 450V
0.47 to 10000µF
± 20% at 120Hz, 20°C
Rated voltage (V)
6.3 to 100
160 to 450
In case of CV 1000
After 1 minute's application of rated voltage at 20°C,
not more than 0.1CV+40 (
µ
A) .
In case of CV > 1000
After 1 minute's application of rated voltage at 20°C,
not more than 0.04CV+100 (
µ
A) .
Measurement frequency : 120Hz at 20°C
Leakage Current
Leakage current
After 1 minute's application of rated voltage at 20°C,
not more than 0.03CV or 4 (
µ
A) , whichever is greater.
After 2 minutes' application of rated voltage at 20°C,
not more than 0.01CV or 3 (
µ
A) , whichever is greater.
Tangent of loss angle (tan
δ)
Rated voltage (V)
tan
δ
(MAX.)
6.3
0.24
10
0.20
16
0.16
25
0.14
35
0.12
50
0.10
63 to 100 160 to 315 350 to 450
0.08
0.20
0.25
For capacitance of more than 1000µF, add 0.02 for every increase of 1000µF.
Measurement frequency :
120Hz
Stability at Low Temperature
Rated voltage (V)
Z–25°C / Z+20°C
Impedance rat io
ZT / Z20 (MAX.)
Z–40°C / Z+20°C
6.3
4
10
10
3
8
16
2
6
25
2
4
35 to 100 160 to 250 315 · 350 400 · 450
2
4
6
15
3
12
—
—
Within ±20% of the initial capacitance value
200% or less than the initial specified value
Less than or equal to the initial specified value
Within ±20% of the initial capacitance value
200% or less than the initial specified value
Less than or equal to the initial specified value
Endurance
The specifications listed at right shall be met when
the capacitors are restored to 20°C after the rated
voltage is applied for 2000 hours at 85°C.
Capacitance change
tan
δ
Leakage current
Capacitance change
tan
δ
Leakage current
Shelf Life
Marking
After storing the capacitors under no load at 85°C for
1000 hours and then performing voltage treatment
based on JIS C 5101-4 clause 4.1 at 20°C, they shall
meet the characteristic requirements at right.
Printed with white color letter on purple blue sleeve.
Axial Lead Type
Sleeve (P.E.T.)
Sealing rubber packing
Sleeve (P.E.T.)
Sealing rubber packing
Pressure relief vent
(φ10up)
Pressure relief vent
φ
d
(φ10up)
Type numbering system (Example : 10V 330
µ
F)
1
2
3
4
5
6
7
8
9 10 11
1 2 3 4 5 6 7 8 9 10 11
T V X 1 A 3 3 1 MAD
T V X 1 A 3 3 1 MAD
φ
d
+
0.5MAX
φD
φD
+
0.5MAX
Configuration
Configuration
Capacitance tolerance (±20%)
Capacitance tolerance
(330µF)
Rated capacitance
(±20%)
Rated capacitance (330µF)
Rated voltage (10V)
Rated voltage
name
Series
(10V)
35MIN
35MIN
L+
L+
MAX
MAX
35 MIN
35MIN
Series name
Type
(mm)
(φD < 10) 1
α
φD
φ
d
5 to 13
0.6
16 to 18
0.8
Configuration
Configuration
Pb-free leadwire
φ
D
Pb-free PET sleeve
Pb-free leadwire
Pb-free PET sleeve
5
φ
D
to 8
AD
5 to 8
10 to 18
10 to 18
AD
CD
CD
Type
(φD
10) 2
Please refer to page 22 about the taped product spec.
Please refer to page 4 for the minimum order quantity.
Dimension table in next page.
