INIATURE
M
INIATURE
F
USEHOLDERS
Holder / No. 820
Panel Mount, Shocksafe
5x20mm Fuses
4,45
0,5
Fuse carrier inserted
max. 0,2
M12,7x1,5
Specifications
Standard
IEC 60127-6
UL 512
CSA C22.2. No.39
VDE: License No. 132225
SEMKO: Certificate No. 9942054
UL Recognized: File No. E 70164
CSA Certified: File No. 47574
Approvals (only 820/835)
7,62
Bayonet-joint
3,2 2,5
11,7 -0,15
12 -0,1
SW14
∅15
∅16
Mounting
4,8
12,7 -0,1
12,7 -0,1
5,5 1...6 5
32
8
12.7mm diameter D-hole or double D-hole
Admissible torque on plastic hex nut is 1.2Nm
Solderable or 4.8mm quick connect-fits 0.5mm tab
IP 40 (IEC 60529)
PC2 (IEC 60127-6)
Holder/Cap:
Metal Parts:
Terminals:
Panel alternatives
Te r m i n a l s
Protection Class & Category
Cap / No. 835
Bayonet-connector-nose
max. 20,6
1,5
Materials
Black Thermoplastic
Polyamide PA 6.6, UL 94 V-O
Copper alloy,
corrosion protected
Solderable, tinned
∅
9,2
Electrical Data (23ºC)
7
Type
Flush Mount Type
1,2
Slot for screwdriver
Rated Voltage: 250V
Rated Current: 6.3A (VDE/SEMKO)
16A (UL/CSA)
Rated Power: 4W (SEMKO)
-25ºC to +70ºC (consider de-rating)
-25ºC/+70ºC/21 days (IEC 60068-2-1...3)
+10ºC to +60ºC
relative humidity
≤
75% yearly average,
without dew, maximum value for 30 days - 95%
24 cycles at 15 min. each (IEC 60068-2-6)
10 - 60Hz at 0.75mm amplitude
60 - 2000Hz at 10g acceleration
≤
5mΩ
Temperature
Operating Temperature
Test
Climatic Test
Stock Conditions
Cap / No. 837
Bayonet-connector-nose
1,5
max. 29,6
∅
9,2
Vibration Resistance
Contact Resistance
1,2
7
Type
Finger Grip Type
Slot for screwdriver
Dielectric Strength
> 1.5 kV
Impulse Voltage
4 kV, 50 Hz, 1 min., dry
> 10
3
MΩ (500 VDC, 1 min.)
235ºC, 3 sec. (Wave)
350ºC, 1 sec. (Soldering Iron)
260ºC, 5 sec. (IEC 60068-2-20)
Conductor - 2.5mm
2
820, 250V, Approvals
4.0g (Holder) / 1.6g (835) / 2.2g (837)
Order Information
Packaging
Bulk (100 pcs.)
Holder
No. 820 0000 000
Cap, Flush Mount No. 835 0000 000
Cap, Finger Grip No. 837 0000 000
Specifications are subject
to change without notice
Note: 1.00 means the number one with two decimal places. 1,000 means the number one thousand.
Insulation Resistance
Solderability
Order Numbers
Soldering Heat Resistance
Minimum Cross Section
Marking
Unit Weight
050909
