IR0618LC2Q: DescriptionDemodulator, I/Q, 6000MHz Min, 18000MHz Max, 13dB Conversion Loss-Max; CategoryWireless rf/communication Radio frequency and microwave; File Size62KB，2 Pages; ManufacturerMITEQ Inc

Download Datasheet Parametric Compare View All

IR0618LC2Q Overview

Demodulator, I/Q, 6000MHz Min, 18000MHz Max, 13dB Conversion Loss-Max

IR0618LC2Q Parametric

Parameter Name	Attribute value
Maker	MITEQ Inc
Reach Compliance Code	unknown
Other features	SMA-F, LOW NOISE
Characteristic impedance	50 Ω
structure	COAXIAL
Maximum frequency conversion loss	13 dB
modulation technology	I/Q
Maximum operating frequency	18000 MHz
Minimum operating frequency	6000 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-54 °C
RF/Microwave Device Types	DEMODULATOR
Maximum voltage standing wave ratio	1.5
Base Number Matches	1

Preview

Download Datasheet

View All

6 TO 18 GHz IMAGE REJECTION OR I/Q MIXERS

MODELS: IR0618LC2A, IR0618LC2B, IR0618LC2C AND IR0618LC2Q

FEATURES

• RF/LO Coverage ............ 6 to 18 GHz

• IF Operation .................. DC to 0.5 GHz

• LO Power Range ............ +10 to +13 dBm

• Conversion Loss ............. 9 dB Typical

• Image Rejection ............. 20 dB Typical

MITEQ’s IR series of image rejection mixers is useful for wideband test equipment or in ultra-broadband

receivers requiring rejection of an unwanted sideband of signal or noise following a low-noise front-end ampli-

fier. These mixers are also useful as linear single-sideband upconverters by operating in the reverse mode.

Higher RF input power versions are available with proportional increases in LO power. Greater image rejec-

tion is also available in selected bandwidths, including the IRE series for the 2 to 8 and 6 to 18 GHz bands.

ELECTRICAL SPECIFICATIONS

INPUT PARAMETERS

RF frequency range

RF VSWR (RF = -10 dBm, LO = +10 dBm)

LO frequency range

LO power range

LO VSWR (RF = -10 dBm, LO = +10 dBm)

TRANSFER CHARACTERISTICS

Conversion loss (Notes 1 and 2)

Single-sideband noise figure

Image rejection (Note 1)

LO-to-RF isolation

LO-to-IF isolation

Input power at 1 dB compression

Input two-tone third-order intercept point

OUTPUT PARAMETERS

IF frequency (image rejection mode)

LO = +13 dBm

CONDITION

IRO618LC2A

IRO618LC2B

IRO618LC2C

IRO618LC2Q

RF < LO

CONDITION

RF > LO

CONDITION

UNITS

GHz

Ratio

GHz

dBm

Ratio

UNITS

dB

dBm

UNITS

MHz

Ratio

MIN.

20

40

100

DC

1.5:1

18

MIN.

6

+10

+12

2.5:1

TYP.

9

10.5

20

+6

+16

TYP.

MAX.

40

80

200

500

MAX.

10

MIN.

6

2:1

18

+13

TYP.

MAX.

18

IF frequency (QIFM, I/Q demodulator mode)

IF VSWR (RF = -10 dBm, LO = +10 dBm)

27

IR0618LC2Q Related Products

	IR0618LC2Q	IR0618LC2B	IR0618LC2C	IR0618LC2A
Description	Demodulator, I/Q, 6000MHz Min, 18000MHz Max, 13dB Conversion Loss-Max	6000 MHz - 18000 MHz RF/MICROWAVE IMAGE REJECTION MIXER, 10 dB CONVERSION LOSS-MAX	6000 MHz - 18000 MHz RF/MICROWAVE IMAGE REJECTION MIXER, 10 dB CONVERSION LOSS-MAX	Image Rejection Mixer, 6000MHz Min, 18000MHz Max, 10dB Conversion Loss-Max
Maker	MITEQ Inc	MITEQ Inc	MITEQ Inc	MITEQ Inc
Reach Compliance Code	unknown	unknown	unknown	unknown
Other features	SMA-F, LOW NOISE	SMA-F, LOW NOISE	SMA-F, LOW NOISE	SMA-F, LOW NOISE
Characteristic impedance	50 Ω	50 Ω	50 Ω	50 Ω
structure	COAXIAL	COAXIAL	COAXIAL	COAXIAL
Maximum frequency conversion loss	13 dB	10 dB	10 dB	10 dB
Maximum operating frequency	18000 MHz	18000 MHz	18000 MHz	18000 MHz
Minimum operating frequency	6000 MHz	6000 MHz	6000 MHz	6000 MHz
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-54 °C	-54 °C	-54 °C	-54 °C
RF/Microwave Device Types	DEMODULATOR	IMAGE REJECTION	IMAGE REJECTION	IMAGE REJECTION
Maximum voltage standing wave ratio	1.5	1.5	1.5	1.5
Base Number Matches	1	1	1	1
