24.4
.96
D
D
C
56.7
2.23
13.4
.53
C
SELF TAPPING (2)
6.4
.25
B
48.6
1.92
3.43
.135
THRU (2) PLACES
13.9
.55
NOTES:
1. SCREWS: STEEL, ZINC PLATED
2. KIT INCLUDES HANDLE AND TWO SELF TAPPING SCREWS
3. CONNECTOR SOLD SEPARATELY
B
19.1
.75
DIMENSIONS
ARE IN:
INCH [MM]
UNLESS OTHERWISE STATED
DRAWN
APPROVALS
1/25/2002
2/1/2002
2/5/2002
2/5/2002
2/1/2002
TITLE
DECIMALS (INCH) DECIMALS (MM) ANGLES
CHECKED
TOLERANCES:
.X
.5
CMS
ANDERSON POWER
PRODUCTS
.XX
.02
2
A
2
1
REV.
ECRN-15046 REVISE AND REDRAW
ECRN-14075 ADD .25 DIM
DESCRIPTION
REVISIONS
TWE
JA
APPRV
1/18/12
10/24/06
DATE
PC
MACHINED
MOLDED
MATERIAL:
FINISH:
SURFACE FINISH:
MFG APPRV
QC APPRV
DJD
128μin [3.2μ]
64μin [1.6μ]
UFN
CATALOG NUMBER: SB120-
HDL-RED SB120 PLASTIC
HANDLE
DWG NO.
A
ENG APPRV
CHB
RPO
3
SIZE
SCALE
A
3rd ANGLE
PROJECTION
-CAD GENERATED DRAWING-
DO NOT MANUALLY UPDATE
DO NOT SCALE
CADFILE
113923S2
01575
1
REV.
SHEET
2
NONE
2
1 OF 1
8
7
6
5
4
