Ultra-Portable LCD Projectors
L720
PT-
L520
PT-
XGA
2200 ANSI
S VG A
2000 ANSI
P T- L 7 2 0
P T- L 7 2 0
P T- L 5 2 0
P T- L 5 2 0
•
•
2200 ANSI lumens (PT-L720), 2000 ANSI
lumens (PT-L520)
Advanced auto setup with digital key-
stone correction
•
•
•
Extra short-throw lens
–
80-inch diagonal
images from 2.5-m distance
3000-hour lamp life (in low lamp power
mode)
Ceiling mountable
Panasonic’s new PT-L720 XGA projector and PT-L520
SVGA projector are the perfect solution for a wide vari-
ety of presentation environments. Both models feature
extraordinary brightness and high native resolution for
high-quality video and data images.
The PT-L720 and PT-L520 pack best-in-class perfor-
mance and advanced user-friendly features into a sleek
and compact unit.
Their stunning performance is backed by a host of
Panasonic’s digital technologies, such as an advanced
10-bit digital gamma correction circuit, sRGB color
management for accurate color rendition, and one-
touch auto-setup with digitalized keystone correction.
For greater connection flexibility, both models feature
two computer inputs, one of which doubles as a monitor
loop-through output, as well as three video inputs (com-
ponent, composite and S-Video). And for even more
convenience in loop-through monitoring, the images
can still be monitored on the computer display while the
projector is switched to standby mode.
Each model is equipped with a large-diameter, extra
short-throw lens, which allows 80-inch diagonal images
from a 2.5-meter distance.
The PT-L720 and PT-L520 perform even better than
other heavier and bulkier conference room projectors.
N E W
Projection Distances
Diagonal image size
P R O D U C T
I N F O R M A T I O N
1.0 m / 3.3´
1.5 m / 5.0´
2.0 m / 6.7´
(40˝)
(60˝)
(80˝)
Distance to screen
With supplied lens
With optional wide conversion lens
min.
max.
min.
max.
1.2 m / 4.0´
1.5 m / 5.0´
1.1 m / 3.5´
1.3 m / 4.4´
1.9 m / 6.3´
2.5 m / 8.1´
3.1 m / 10.2´
3.7 m / 12.2´
5.0 m / 16.3´
6.2 m / 20.5´
7.8 m / 25.6´
9.4 m / 31.0´
2.3 m / 7.7´
3.1 m / 10.3´
3.9 m / 12.9´
4.7 m / 15.5´
6.2 m / 20.5´
7.8 m / 25.7´
9.8 m / 32.3´
11.8 m / 38.9´
1.6 m / 5.3´
2.2 m / 7.1´
2.8 m / 9.2´
3.3 m / 10.7´
4.4 m / 14.4´
5.5 m / 18.0´
6.9 m / 22.8´
8.3 m / 27.3´
2.0 m / 6.7´
2.7 m / 9.1´
3.4 m / 11.4´
4.1 m / 13.7´
5.5 m / 18.0´
6.9 m / 22.7´
8.6 m / 28.5´
10.4 m / 34.3´
2.5 m / 8.3´ (100˝)
3.0 m / 10.0´ (120˝)
4.1 m / 13.3´ (160˝)
5.1 m / 16.7´ (200˝)
6.4 m / 20.8´ (250˝)
7.6 m / 25.0´ (300˝)
Image sizes and distances are approximate.
Specifications
Native Resolution:
PT-L720:
PT-L520:
Brightness:
PT-L720:
PT-L520:
Dimensions
(W x H x D):
Weight:
Contrast Ratio:
Display Technology:
PT-L720:
PT-L520:
Lamp:
Lamp Life:
Brightness Uniformity:
Keystone Correction:
Lens Shift:
Installation:
Audio:
Input Sources:
Output Sources:
XGA (1024 x 768 pixels)
SVGA (800 x 600 pixels)
2200 ANSI lumens
2000 ANSI lumens
245 x 118 x 341 mm
(9-5/8˝ x 4-5/8˝ x 13-4/16˝)
3.9 kg/8.6 lbs
XXX:1
LCD (0.9˝ polysilicon panels)
786,432 (1024 x 768) x 3
480,000 (800 x 600) x 3
AC 220-W UHM™ lamp
3000 hours (in low lamp power mode)
2000 hours (in high lamp power mode)
90%
Digital, vertically adjustable (optically
fixed)
9:1 (fixed)
Ceiling/desk, front/rear (menu selection)
2 W (mono)
Computer (D-sub HD 15-pin x 2)
Component video (D-sub HD 15-pin x 1)
Composite video (RCA x 1)
S-Video (Mini DIN 4-pin x 1)
Audio line in for computer (mini x 1)
Audio line in for video (RCA, L/R)
VGA monitor out (D-sub HD 15-pin)
Audio monitor out (mini x 1)
Computer Compatibility:
VGA, SVGA, XGA, SXGA, UXGA*, Mac
*
PT-L720 only
Video Compatibility:
PAL, PAL-M, PAL-N, PAL60, SECAM,
NTSC, M-NTSC, YP
B
P
R
(525i/480i,
625i/576i, 525p/480p, 750p/720p,
1125i/1080i)
Number of Colors:
Full color (16.7 million)
Aspect Ratio:
4:3 (16:9 compatible)
H-Sync/V-Sync Range:
PT-L720:
31– 91 kHz, 50– 85 Hz
PT-L520:
15
–
70 kHz, 50– 85 Hz
Lens:
Manual zoom/focus lens (1:1–1:1.3),
F 1.75, f 28.7–36.0 mm
Image Size (Diagonal):
40˝–300˝ (1.0
–7.6
m)
Control:
RS-232C (D-sub 9-pin)
Power Supply:
100
–240
V AC (auto-voltage), 50/60 Hz
Power Consumption:
300 W
Operating Temperature:
0°– 40°C (32°–104°F)
Operating Humidity:
20%
–80%
Safety Regulations:
UL1950, C-UL, FCC class B, EN60950/
IEC60950, EN55024, N55022 (B),
EN61000-3-2, EN61000-3-3, VDE,
GOST, MIC, CB, C-tick
Supplied Accessories
•
•
•
•
•
•
Full-function remote control
Batteries (AAA x 3) for remote control unit
Power cord
RGB cable
AV cable
Carrying bag
Optional Accessories
ET-LA730
ET-PK730
ET-ADBNC
ET-LEC701
ET-RMRC1
User-replacement lamp unit
Ceiling mount bracket
D-sub 15-pin/BNC adaptor
Wide conversion lens
Wireless Mouse Receiver
Design and specifications are subject to change without notice.
PT-L720/L520NPI2-02MAYxxK Printed in Japan.
