This document was generated on 01/15/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0536471274
Active
SlimStack™ 0.635mm Pitch Board-to-Board Connectors
0.635mm Pitch SlimStack Header, Surface Mount, Dual Row, Vertical Stacking,
8.00 and 14.00mm Stacking Heights, 120 Circuits, with Embossed Tape with Cover
Packaging
Documents:
3D Model
Drawing (PDF)
Product Specification 527600000-000 (PDF)
General
Product Family
Series
Application
Comments
Overview
Product Name
UPC
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Mated Height
Material - Metal
Material - Plating Mating
Material - Plating Termination
Net Weight
Number of Rows
Orientation
PCB Locator
PCB Retention
Packaging Type
Pitch - Mating Interface
Polarized to PCB
Robotic Placement
Stackable
Temperature Range - Operating
Termination Interface: Style
Electrical
Current - Maximum per Contact
Voltage - Maximum
Material Info
Reference - Drawing Numbers
Packaging Specification
Product Specification
Product Specification PS-52760-015-001 (PDF)
Packaging Specification SPK-53647-001-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
Halogen-Free
Status
Not Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
PCB Headers
53647
Board-to-Board, Signal
Stacking-Type
SlimStack™ 0.635mm Pitch Board-to-Board Connectors
SlimStack
822348204922
No
120
120
Brown
50
No
No
No
None
Yes
14.00mm, 8.00mm
Brass, Phosphor Bronze, Stainless Steel
Gold
Tin
1479.783/mg
2
Vertical
Yes
Yes
Embossed Tape on Reel
0.64mm
Yes
Metal Cap
No
-55°C to +105°C
Surface Mount
0.5A
100V
Search Parts in this Series
53647 Series
Mates With
SlimStack Receptacle 52760 , 52837 ,
52885 , 52901
SPK-53647-001-001
527600000-000, PS-52760-015-001
