SILICON ZENER DIODES
Hermetically Sealed Glass Silicon Zener Diodes
SOD-80C Zener Diodes
CLL750 to CLL759, 500mW Hermetically Sealed, Glass Silicon Zener Diodes
Electrical Characteristics :
T
A
= 25°C, V
F
= 1.5 V Max @ 200 mA for all types
Type
No.
(Note 1)
CLL750
CLL751
CLL752
CLL753
CLL754
CLL755
CLL756
CLL757
CLL758
CLL759
Nominal
Zener Voltage
V
Z
@ I
ZT
(Note 2)
Volts
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10.0
12.0
Test
Current Max Zener Impedance
I
ZT
Z
ZT
@ I
ZT
(Note 2)
Ohms
mA
20
20
20
20
20
20
20
20
20
20
19
17
11
7
5
6
8
10
17
30
Max Reverse Leakage Current
Maximum
DC Zener Current
I
ZM
mA
75
70
65
60
55
50
45
40
35
30
95
85
80
70
65
60
55
50
45
35
T
A
= 25ºC
I
R
@ V
R
= 1 V
µA
2.0
1.0
1.0
0.1
0.1
0.1
0.1
0.1
0.1
0.1
T
A
= 150ºC
I
R
@ V
R
= 1 V
µA
30
20
20
20
20
20
20
20
20
20
Polarity :
Cathode indicated by colour band.
Note 1 :
CLL750 Series : ± 10% tolerance; Suffix A ± 5% tolerance.
CLL750_759Rev210902E
Note 2 :
Pulse test : 20ms
≤
tp
≤
50ms.
Continental Device India Limited
Data Sheet
Page 1 of 3
SOD - 80C
Mini MELF (LL-34)
SOD 80C (LL-34) Mini MELF Hermetically Sealed Glass Package
± 0.05
0.35
± 0.20
3.50
± 0.05
0.35
±0.5
1.5
4.5
3.5
Identification Label
Part Number
Date Code
Quantity
10.4
8.4
±0.025
ø 1.40
± 0.04
ø 1.50
12.9
12.5
180
120°
Cathode band
All Dimensions are in mm
2.0
1.4
Reel ø
No. of Device
180 mm (7")
2,500
TAPE & REEL
2.5
MAX
±0.2
4.0
De-reeling direction
±0.2
2.0
1.85 ±0.05
3.50
1.65
5.50
5.25
±0.3
8.00
All Dimensions are in mm
Notes:
1. Maximum of 0.5% of the total number of components per
reel may be missing-exclusively at the beginning and at
the end of the reel.
2. A maximum of three consecutive components may be
missing, provided this gap is followed by six consecutive
components.
0.3
MAX
ø1.6
ø1.4
De-reeling direction
300mm (75 empty
compartments)
Tape leader/carrier leader
All Dimensions are in mm
160mm (40 empty
compartments)
Carrier trailer
Drawings are not to scale
Packing Detail
STANDARD PACK
INNER CARTON BOX
Details
Net Weight/Qty
Size
Qty
SOD-80C T&R 2.5K/reel
225 gm/2.5K pcs 9" x 9" x 9"
40K
CLL750_759Rev210902E
PACKAGE
OUTER CARTON BOX
Size
Qty
Gr Wt
18" x 12" x 10"
80K
7.2 kgs
19" x 19" x 20"
320K
28.8 kgs
Page 2 of 3
Continental Device India Limited
Data Sheet
53.5
50.5
SOD - 80C
Mini MELF (LL-34)
Component Disposal Instructions
1. CDIL Semiconductor Devices are RoHS compliant, customers are requested to please dispose
as per prevailing Environmental Legislation of their Country.
2. In Europe, please dispose as per EU Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE).
Customer Notes
Disclaimer
The product information and the selection guides facilitate selection of the CDIL's Semiconductor Device(s) best suited for application in
your product(s) as per your requirement. It is recommended that you completely review our Data Sheet(s) so as to confirm that the
Device(s) meet functionality parameters for your application. The information furnished in the Data Sheet and on the CDIL Web Site/CD
are believed to be accurate and reliable. CDIL however, does not assume responsibility for inaccuracies or incomplete information.
Furthermore, CDIL does not assume liability whatsoever, arising out of the application or use of any CDIL product; neither does it convey
any license under its patent rights nor rights of others. These products are not designed for use in life saving/support appliances or
systems. CDIL customers selling these products (either as individual Discrete Semiconductor Devices or incorporated in their end
products), in any life saving/support appliances or systems or applications do so at their own risk and CDIL will not be responsible for any
damages resulting from such sale(s).
CDIL strives for continuous improvement and reserves the right to change the specifications of its products without prior notice.
CDIL is a registered Trademark of
Continental Device India Limited
C-120 Naraina Industrial Area, New Delhi 110 028, India.
Telephone + 91-11-2579 6150,
4141
1112 Fax + 91-11-2579 5290,
4141
1119
email@cdil.com
www.cdilsemi.com
CLL750_759Rev210902E
Continental Device India Limited
Data Sheet
Page
3
of
3
