BYVF32 Series
PRV : 50 - 200 Volts
Io : 18 Ampere
FEATURES :
* High current capability
* High surge current capability
* Low leakage, high voltage
* Glass passivated chip junction
* Pb / RoHS Free
Dual Ultrafast Plastic Rectifiers
ITO-220AB
0.134(3.4)DIA.
0.113(3.0)DIA.
0.112(2.85)
0.100(2.55)
0.406(10.3)MAX.
0.185(4.70)Max.
0.124(3.16)Max.
0.272(6.9)
0.248(6.3)
0.603(15.5)
0.573(14.8)
1
2 3
0.161(4.1)Max.
0.543(13.8)
0.512(13.2)
0.055(1.4)Max.
0.110(2.8)
0.098(2.5)
MECHANICAL DATA :
* Case : Epoxy, Molded
* Lead Temperature for Soldering Purposes:
260°C Max. for 10 Seconds
* Polarity: As marked
* Mounting Position: Any
* Weight : 2.24 grams (Approximately)
0.035(0.9)Max.
0.030(0.76)Max.
0.100(2.55)
PIN 1
PIN 2
PIN 3
Dimensions in inches and ( millimeters )
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(Ta =25°C unless otherwise specified.)
RATING
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Current, Tc = 100°C
Maximum Peak Forward Surge Current
8.3ms single half sine-wave superimposed on
rated load (JEDEC Method) at Tc = 100°C
Maximum Instantaneous Forward Voltage per Leg
at I
F
= 20A
I
F
= 5.0A, Tj = 100°C
Maximum Reverse Current per Leg
at Rated DC Blocking Voltage
Maximum Reverse Recovery Time per Leg
(I
F
= 1A, V
R
= 30V , di/dt = 100A/µs, Irr = 10%I
RM
)
Typical junction capacitance at 4V, 1MHz
Maximum Thermal Resistance, Junction to Case
Operating storage and temperature range
I
R
I
R(H)
Trr
Cj
RθJC
T
J
, T
STG
V
F
1.15
0.85
10 (Tc = 25°C)
600 (Tc = 100°C)
35
85
3.0
- 55 to + 150
µA
µA
ns
pF
°C/W
°C
V
I
FSM
150
A
SYMBOL BYVF32-50
V
RRM
V
RMS
V
DC
I
F(AV)
50
35
50
BYVF32-
100
100
70
100
BYVF32-150
150
105
150
18
BYVF32-
200
200
140
200
UNIT
V
V
V
A
Page 1 of 2
Rev. 02 : March 25, 2005
RATING AND CHARACTERISTIC CURVES ( BYVF32 Series )
FIG.1 - FORWARD CURRENT
DERATING CURRENT
24
150
Resistive or Inductive Load
FIG.2 - MAXIMUM NON-REPETITIVE
PEAK FORWARD SURGE CURRENT PER LEG
Tj =150 °C
AVERAGE FORWARD RECTIFIED
CURRENT, AMPERES
PEAK FORWARD SURGE
CURRENT, AMPERES
20
125
10ms SINGLE HALF SINE-WAVE
(JEDEC) Method
16
10
12
75
8
50
4
25
0
0
25
50
75
100
125
150
175
0
1
2
4
6
10
20
40
60
100
CASE TEMPERATURE, (
°
C)
NUMBER OF CYCLES AT 60Hz
FIG.3 - TYPICAL INSTANTANEOUS
FORWARD CHARACTERISTICS PER LEG
100
FIG. 4 - TYPICAL REVERSE
CHARACTERISTICS PER LEG
100
INSTANTANEOUS FORWARD
CURRENT, AMPERES
INSTANTANEOUS REVERSE
CURRENT, MICROAMPERES
T
J
= 100
°C
10
10
1
T
J
= 25
°C
Pulse Width = 300
µs
2% Duty Cycle
1
T
J
= 25
°C
0.1
0
0.1
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
2.0
0
20
40
60
80
100
120
140
INSTANTANEOUS FORWARD
VOLTAGE, VOLTS
PERCENT OF RATED PEAK REVERSE
VOLTAGE, (%)
FIG. 5 – TYPICAL JUNCTION CAPACITANCE PER LEG
JUNCTION CAPACITANCE, pF
80
70
60
50
40
30
20
10
0
1
10
100
1000
T
J
= 25°C
f = 1.0 MHz
Vsig = 50 mVp-p
REVERSE VOLTAGE, VOLTS
Page 2 of 2
Rev. 02 : March 25, 2005
