In order to reduce the amount of packaging materials used to help protect the global environment, it is recommended that each packaging box contains 1,500 units
with the “J” product number suffix.
As for the part No. P is suffixed, only 1,000 pcs. reel is available.
2. Regarding ordering units: During production: Please make orders in 1-reel units.
Samples for mounting confirmation: Available in units of 50 pieces. Please consult us. (See “Regarding sample orders to confirm proper mounting” on page 19.)
Samples: Small lot orders are possible. Change the suffix “J” to the suffix “P.”
3. Connectors with suction tape are also available except for 16 contacts type. For this type of connector, insert the letter “C” between the 6th and 7th column of the
ordering number.
Example: For a 20-contact socket with 3mm mated height (embossed tape package): AXN320C038P
4. The standard type comes with positioning bosses. Connectors without positioning bosses are available for on-demand production (3,000 pcs/lot or more).
5. Regarding of 100-contact connectors are please consult us. In an embosses tape package as the required embossed tape width exceeds the JIS standard.
6. The standard type of 13mm embossed tape package does not come with positioning bosses.
panasonic-electric-works.net/ac
AXN(1/3/4)
1. Characteristics
Item
Rated current
Rated voltage
Electrical
characteristics
Breakdown voltage
Insulation resistance
Contact resistance
Composite insertion force
Mechanical
characteristics
Composite removal force
Max. 60mΩ
Specifications
3mm, 3.5mm, 4mm, 4.5mm,
5.0mm, 5.5mm, 6.0mm, 7.0mm,
8.0mm, 13.0mm, 14.0mm type
0.5A
60V AC/DC
250V AC for 1 minute
Min. 1,000MΩ
Max. 50mΩ
Detection current: 1mA
Using 500V DC megger
Based on the contact resistance
measurement method specified by
JIS C 5402.
Conditions
11.5mm type
Contact holding force
Ambient temperature
Soldering heat resistance
Max. 43.1N {4.40kgf}
Max. 0.785N {80gf}
×
(30 contacts)
no. of contacts (initial)
Min. 6.37N {0.65kgf}
Min. 0.127N {13gf}
×
(30 contacts)
no. of contacts
40 contacts or less:
Min. 1.96N {200 gf}
Min. 1.96N {200 gf}
50 contacts or more:
Min. 0.981N {100 gf}
–55°C to +85°C
Max. peak temperature of 245°C (on the surface of the PC board
