CONDUCTIVE POLYMER ALUMINUM SOLID ELECTROLYTIC CAPACITORS
LV
Radial Lead Type, Long Life Assurance
series
High voltage (to 100V), Low ESR, High ripple current.
Long life of 3000 hours at 105°C.
Radial lead type:
Lead free flow soldering condition correspondence.
Compliant to the RoHS directive (2011/65/EU).
LX
High Temperature
LV
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Tangent of loss angle (tan
δ)
ESR (
1)
2)
Leakage Current (
Performance Characteristics
– 55 to +105°C
16 to 100V
6.8 to 470µF
± 20%
at 120Hz, 20°C
Less than or equal to the specified value at 120Hz, 20°C
Less than or equal to the specified value at 100kHz, 20°C
Less than or equal to the specified value.
Z+105°C / Z+20°C
Z– 55°C / Z+20°C
1.25
1.25
(100kHz)
After 2 minutes' application of rated voltage at 20°C
Temperature Characteristics
(Max.Impedance Ratio)
Endurance
The specifications listed at right shall be met when the
capacitors are restored to 20°C after the rated voltage is
applied for 3000 hours at 105°C.
Capacitance change
tan
δ
ESR (
1)
Leakage current ( 2)
Capacitance change
tan
δ
Within ± 20% of the initial capacitance value ( 3)
150% or less than the initial specified value
150% or less than the initial specified value
Less than or equal to the initial specified value
Within ± 20% of the initial capacitance value ( 3)
150% or less than the initial specified value
150% or less than the initial specified value
Less than or equal to the initial specified value
Damp Heat
(Steady State)
The specifications listed at right shall be met when the
capacitors are restored to 20°C after the rated voltage is
applied for 1000 hours at 60°C, 90% RH.
ESR (
1)
Leakage current ( 2)
Resistance to
Soldering Heat
After soldering the capacitor under the soldering conditions
prescribed here as preheat at 150 to 200°C for 60 to 180 seconds
and peak temperature at 265°C for 10 seconds or less, the
capacitor shall meet the specifications listed at right, provided that
its temperature profile is measured at both of terminal ends facing
the soldering side.
Navy blue print on the case top
Capacitance change
tan
δ
ESR (
1)
Leakage current ( 2)
Within ± 10% of the initial capacitance value ( 3)
130% or less than the initial specified value
130% or less than the initial specified value
Less than or equal to the initial specified value
Marking
1 ESR should be measured at both of the terminal ends closest to the capacitor body.
2 Conditioning : If any doubt arises, measure the leakage current after the voltage treatment of applying DC rated voltage continuously to the capacitor for 120
minutes at 105°C.
3 Initial value : The value before test of examination of resistance to soldering.
Dimensions
Capacitance
Type numbering system (Example : 35V 82
µ
F)
Resin coated Case
Voltage(V:35V)
φD±0.5
1
2
3
4
5
6
7
8
9
10 11
12
P L V 1 V 8 2 0 M D L 1
Size code
P±
0.5
LV
82
V
012
Configuration
Capacitance tolerance (±20%)
φ
d
Series
Lot. No.
L+0.5MAX.
15MIN
4MIN
Rated capacitance (82µF)
Rated voltage (35V)
Series name
Type
Size
φD
L
P
φd
φ8
×
9L
8.0
8.5
3.5
0.6
(mm)
φ8
×
12L
φ10
×
13L
8.0
10.0
11.5
12.5
3.5
5.0
0.6
0.6
Voltage
V
Code
16
C
20
D
25
E
35
V
50
H
63
J
80
K
100
2A
Please refer to page 20 about the end seal configuration.
Dimension table in next page.
CAT.8100D
