Ka Band Connectorised Amplifier: 30 – 35 GHz
Features
•
•
•
•
•
High Reliability
Weight and space saving design
Built-in power supply protection
Field Replaceable K Connectors
Space Qualified version available
MAAMML0017
V4
Description
The MAAMML0017 is a high reliability Ka band
connectorised amplifier. This weight and space
saving design has been realised by utilising the
latest advances in housing materials. Additionally,
built-in circuitry ensures that power supply
sequencing can be in any order, for both power-up
and power down.
Alternative frequency ranges, gain, output powers
and supply rail configurations are available. The
MAAMML0017 is also available as a space qualified
version. Please contact the factory for details.
Mechanical
This device is supplied with field replaceable ‘K’
connectors. It is hermetically sealed, with a
gold-plated finish to MIL-G-45204.
1
M/A-COM Inc. and its affiliates reserve the right to make changes to the
product(s) or information contained herein without notice. M/A-COM makes
no warranty, representation or guarantee regarding the suitability of its
products for any particular purpose, nor does M/A-COM assume any liability
whatsoever arising out of the use or application of any product(s) or
information.
•
North America
Tel: 800.366.2266 / Fax: 978.366.2266
•
Europe
Tel: 44.1908.574.200 / Fax: 44.1908.574.300
•
Asia/Pacific
Tel: 81.44.844.8296 / Fax: 81.44.844.8298
Visit www.macom.com for additional data sheets and product information.
Ka Band Connectorised Amplifier: 30 – 35 GHz
MAAMML0017
V4
Specification at +25 °C
(Applies over the frequency range @ +25 °C, output and input load impedance of 50 ohms.
Unless otherwise stated limits & conditions are indicated values.)
Parameter
Frequency
Operating Temperature T
OP
Small signal gain @ +25
O
C
Pk-pk Gain variation over T
OP
Passband flatness
P1dB (Output)
Noise Figure
Input VSWR
Output VSWR
Value
30-35
+0
∼
+50
31
7
4
+25
11
2:1
2:1
DC Supply Positive Rail
Supply Voltage
Current consumption @ P1dB
Current consumption @ P3dB
+7
750
1000
DC Supply Negative Rail
Supply Voltage
Current consumption
-6.5
20
V
mA
V
mA
mA
Units
GHz
°C
dB
dB
dB pk-pk
dBm
dB
Ratio
Ratio
2
