THESE DRAWINGS ARE THE PROPERTY OF QUALTEK
ELECTRONICS AND NOT TO BE REPRODUCED FOR
OR COMMUNICATED TO A THIRD PARTY WITHOUT
THE EXPRESS WRITTEN PERMISSION OF AN OFFICER
OF QUALTEK ELECTRONICS.
WHITE
WIRE
GROUND
WIRE
BLACK
WIRE
REVISION
REV.
B
C
SOLID
CONDUCTOR
“18”(AWG)
USE COPPER WIRE ONLY
PANEL LOCK
TAB TERMINAL
(USING SOLID OR
STRANDED WIRE)
DESCRIPTION
RoHS Compliancy
Specifications Update
DATE
06-01-06
09-14-07
APPROVED
DP
DP
LOCKING
LATCH
LATCH
SLOT
HOUSING
FLANGE
TAB TERMINAL
SLOT
4.8 TAB FASTON
TERMINAL APPLICATION
27 ±
1
0
R1
5
24.5 ±
0.2
0
15.1
24.5 ±
0.2
0
27 ±
8.5
5
30
1
0
0.4
24
2.7
3.5
24
5
4
3
2
1
PANEL CUTOUT
Cover back of the body, NYLON Black Color
Contact PIN Bronze Strip t=0.4mm Cu-Plated
Contact PIN Bronze Strip t=0.4mm Ni-Plated
Contact PIN Bronze Strip t=0.4mm Cu-Plated
Body Insulator NYLON Black Color
Dim
range
(mm)
0-1
1-6
6-18
18-50
50-120
120-250
250-500
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
Drawn / Date
B.ZHANG
01-22-02
CONTROLLED
1
1
1
1
1
Qualtek Electronics Corp.
Part Number:
Description:
NOTES:
USE COPPER WIRE ONLY
RATING: 10A 125V AC
APPROVALS: UL,cUL, CSA
PANEL THICKNESS: 0.8~1.8mm
RoHS COMPLIANT
PPC DIVISION
739W-X2/04
AC RECEPTACLE
UNIT: mm
Checked / Date
01-22-02
REV. C
Approved / Date
JJH / 01-22-02
