ZXTN26070CV-7

Description
Bipolar Transistors - BJT 70V NPN Low SAT 2A Ic 5A Peak 130mOh
Categorysemiconductor    Discrete semiconductor
File Size135KB,7 Pages
ManufacturerDiodes
Websitehttp://www.diodes.com/
Download Datasheet Parametric View All

ZXTN26070CV-7 Online Shopping

Suppliers Part Number Price MOQ In stock
ZXTN26070CV-7 - - View Buy Now

ZXTN26070CV-7 Overview

Bipolar Transistors - BJT 70V NPN Low SAT 2A Ic 5A Peak 130mOh

ZXTN26070CV-7 Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerDiodes
Product CategoryBipolar Transistors - BJT
RoHSDetails
Transistor PolarityNPN
PackagingCut Tape
PackagingMouseReel
PackagingReel
NumOfPackaging3
Factory Pack Quantity3000
A Product Line of
Diodes Incorporated
ZXTN26070CV
70V NPN LOW SATURATION TRANSISTOR IN SOT-666
Features
BVceo = 70V, BVcbo = 150V
I
C
Cont. 2A
5A Peak Pulse Current
Extremely Low Equivalent On Resistance; R
CE(sat)
= 130mΩ at
1A
Lead, Halogen, and Antimony Free/RoHS Compliant (Note 1)
“Green” Devices (Note 2)
Mechanical Data
Case: SOT-666
Case material: Molded Plastic. “Green” Molding Compound.
UL Flammability Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Matte Tin Finish annealed over copper leadframe.
Solderable per MIL-STD-202, Method 208
Weight: 0.003 grams (Approximate)
Applications
DC-DC converter
1, 2, 5, 6
3
4
Top View
Device Schematic
6
5
4
1
2
3
Pin Out Configuration
Ordering Information
(Note 3)
Product
ZXTN26070CV-7
Notes:
Marking
1Q6
Reel size (inches)
7
Tape width (mm)
8mm
Quantity per reel
3000
1. No purposefully added lead. Halogen and Antimony free: <900ppm bromine, <900ppm chlorine (<1500ppm total) and <1000ppm antimony compounds.
2. Diodes Inc.‘s “Green” Policy can be found on our website at http://www.diodes.com
3. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
1Q6
1Q6 = Product Type Marking Code
ZXTN26070CV
Document number: DS32129 Rev. 3 - 2
1 of 7
www.diodes.com
April 2010
© Diodes Incorporated
