Agilent HDSP-301x/303x Series
HDSP-561x/563x Series
10 mm and 13 mm Slim Font
Seven Segment Displays
Data Sheet
Features
• Excellent appearance
• Slim font design
• Mitered corners, evenly
illuminated segments
Description
These slim font seven segment
displays incorporate a new slim
font character design. This slim
font features narrow width,
specially mitered segments to
give a fuller appearance to the
illuminated character. Faces of
these displays are painted a
neutral gray for enhanced on/off
contrast.
All devices are available in either
common anode or common
cathode configuration with right
hand decimal point.
• Gray face for optimum on/off
contrast
• Choice of colors: HER, green,
yellow, and AlGaAs
• Choice of character size: 10 mm
and 13 mm
• Characterized for luminous
intensity
Devices
HER
HDSP-
301E
303E
561E
563E
Green
HDSP-
301G
303G
561G
563G
Yellow
HDSP-
301Y
303Y
561Y
563Y
AlGaAs
HDSP-
301A
303A
561A
563A
Description
Common Anode, 10 mm Display
Common Cathode, 10 mm Display
Common Anode, 13 mm Display
Common Cathode, 13 mm Display
Part Numbering System
5082 - x xx x - x x x xx
HDSP - x xx x - x x x xx
Mechanical Options
[1]
00: No Mechanical Option
Color Bin Options
[1,2]
0: No Color Bin Limitation
Maximum Intensity Bin
[1,2]
0: No Maximum Intensity Bin Limitation
Minimum Intensity Bin
[1,2]
0: No Minimum Intensity Bin Limitation
Device Configuration/Color
[1]
A: AlGaAs Red
E: High Efficiency Red
G: Green
Y: Yellow
Device Specific Configuration
[1]
Refer to Respective Data Sheet
Package
[1]
Refer to Respective Data Sheet
Notes:
1. For codes not listed in the figure above, please refer to the respective data sheet or contact your nearest Agilent representative
for details.
2. Bin options refer to shippable bins for a part-number. Color and Intensity Binbs are typically restricted to 1 bin per tube
(exceptions may apply). Please refer to respective data sheet for specific bin limit information.
2
HDSP-301x/303x Series
FRONT VIEW
6.00
(0.236)
0.90
(0.035)
RIGHT SIDE
COUNTRY
OF ORIGIN
LUMINOUS
INTENSITY
CATEGORY
COLOR BIN
10.00°
2.54
±
0.38
(0.100)
10.00
(0.394)
1.85
(0.073)
YWW XZ COO
HDSP-XXXX
12.80
±
0.25
(0.504)
4 x 2.54
(0.400)
Ø 1.20
(0.047)
6.40
±
0.25
(0.252)
7.00
±
0.25
(0.276)
0.53
±
0.05
(0.021)
TOP SIDE
9.70
±
0.25
(0.382)
10.40 MIN.
(0.409)
DATE CODE
1
+
2
+
F
A
+
10
+
9
B
G
3
+
4
+
0.30
±
0.05
(0.012)
7.62
±
0.38
(0.300)
E
D
+
8
C
+
7
DP
5
+
+
6
PIN 6
NOTE: QDSP-399G DOES NOT HAVE PIN 6.
Pin
1
2
3
4
5
6
7
8
9
10
Function
G
F
Common A/C
E
D
DP
C
Common A/C
B
A
3
HDSP-561x/563x Series
45°
7.40
(0.292)
10°
1.25
(0.049)
13.00
(0.512)
17.50 ± 0.3/–0.25
(0.689)
15.24 ± 0.3
(0.600)
0.29 ± 0.08 TYP.
(0.011)
1.25
Ø (0.049)
6.40 ± 0.25
(0.252)
3.60 ± 0.3
(0.142)
7.00 ± 0.25
(0.276)
12.25 ± 0.25
(0.482)
10
9
8
a
7
6
f
g
b
0.58 ± 0.08
(0.023)
3.59 ± 0.3 TYP.
(0.141)
2.54 ± 0.3 TYP.
(0.100)
e
c
d
1
2
3
DP
4
5
NOTES:
1. ALL DIMENSIONS ARE IN MILLIMETERS (INCHES).
2. UNLESS OTHERWISE STATED, TOLERANCES ARE ±0.25 mm.
Pin
1
2
3
4
5
6
7
8
9
10
Function
E
D
Common A/C
C
DP
B
A
Common A/C
F
G
4
Absolute Maximum Ratings
Description
Average Power per Segment or DP
Peak Forward Current per Segment or DP
DC Forward Current per Segment or DP
Operating Temperature Range
Storage Temperature Range
Reverse Voltage per Segment or DP
Wavesoldering Temperature for 3 Seconds
1.59 mm below body
Notes:
1. Derate above 33˚C at 0.34 mA/˚C for HER.
2. Derate above 27˚C at 0.32 mA/˚C for Green.
3. Derate above 30˚C at 0.33 mA/˚C for Yellow.
4. Derate above 60˚C at 0.25 mA/˚C for AlGaAs.
HER
105
90
30
–40 to +80
–40 to +80
5
250
Green
105
90
30
–40 to +80
–40 to +80
5
250
Yellow
105
90
30
–40 to +80
–40 to +80
5
250
AlGaAs
37
45
15
–20 to +80
–40 to +80
5
250
Units
mW
mA
mA
˚C
˚C
V
˚C
Electrical/Optical Characteristics at T
A
= 25˚C
HER
Device
Series
HDSP-
Parameter
301/303E Luminous Intensity/Segment
(Digit Average)
Forward Voltage/Segment
or DP
Peak Wavelength
Dominant Wavelength
Reverse Current
Thermal Resistance LED
Junction-to-Pin
HER
Device
Series
HDSP-
Parameter
561/563E Luminous Intensity/Segment
(Digit Average)
Forward Voltage/Segment
or DP
Peak Wavelength
Dominant Wavelength
Reverse Current
Thermal Resistance LED
Junction-to-Pin
Symbol
I
V
V
F
λ
PEAK
λ
d
I
R
Rθ
J–PIN
Min.
1.251
Typ.
2.000
1.90
635
625
Max.
Units
mcd
V
Test Conditions
I
F
= 10 mA
I
F
= 20 mA
2.50
100
351.5
nm
I
F
= 20 mA
nm
I
F
= 20 mA
µA
V
R
= 5 V
˚C/W/Seg.
Symbol
I
V
V
F
λ
PEAK
λ
d
I
R
Rθ
J–PIN
Min.
2.001
Typ.
3.526
1.90
635
625
Max.
Units
mcd
V
Test Conditions
I
F
= 10 mA
I
F
= 20 mA
2.50
100
351.5
nm
I
F
= 20 mA
nm
I
F
= 20 mA
µA
V
R
= 5 V
˚C/W/Seg.
5
