SMD PLCC
EAHE2835WD63
Features
PLCC-2 package
Top view white LED
High luminous intensity output
W ide viewing angle
Pb-free
RoHS compliant
ANSI Binning
1
˙
˙
˙
˙
˙
‧
‧
‧
‧
‧
‧
‧
Description
The Everlight EAHE2835WD63 package has high efficacy, high CRI, low power consumption, wide viewing angle
and a compact form factor. These features make this package an ideal LED for all lighting applications.
Applications
General lighting
Decorative and Entertainment Lighting
Indicators
Illumination
Switch lights
Copyright © 2015, Everlight Americas Inc.
. Release Date: 15.Dec. 2015. Issue No:
Issue No:
www.everlightamericas.com
DATASHEET
SMD PLCC
EAHE2835WD63
Mass Production List
Product
EAHE2835WD63
CRI
Min.
(1)
80
CCT(K)
6500K
Φ(lm)
Min.
(2)
29
Φ(lm)
Max.
(2)
39
Notes:
1. Tolerance of Color Rendering Index: ±2
2. Tolerance of Luminous flux: ±11%.
2
Copyright © 2015, Everlight Americas Inc.
. Release Date: 15.Dec. 2015. Issue No:
Issue No:
www.everlightamericas.com
DATASHEET
SMD PLCC
EAHE2835WD63
Device Selection Guide
Chip
Materials
InGaN
Emitted Color
Cool White
Neutral White
Warm White
Water Clear
Resin Color
Absolute Maximum Ratings (T
Soldering
=25℃)
℃
Parameter
Forward Current
Peak Forward Current (Duty 1/10 @10ms)
Power Dissipation
Operating Temperature
Storage Temperature
Thermal Resistance (Junction / Soldering point)
Junction Temperature
Soldering Temperature
Symbol
I
F
I
FP
P
d
T
opr
T
stg
R
th J-S
T
j
T
sol
Rating
180
300
580
-40 ~ +85
-40 ~ +100
30
115
Unit
mA
mA
mW
Hand Soldering : 350
Note:
The products are sensitive to static electricity and must be carefully taken when handling products
Electro-Optical Characteristics (T
Soldering
=25℃)
℃
Parameter
Luminous Flux
(1)
Forward Voltage
(2)
Color Rendering Index
(3)
Efficacy
(1) (4)
Viewing Angle
Reverse Current
Symbol
Min.
27
2.5
80
-----
-----
-----
Typ.
-----
-----
-----
180
120
-----
Max.
40
3.2
-----
-----
-----
50
lm/W
deg
µΑ
Unit
lm
V
Condition
I
F
=65mA
I
F
=65mA
I
F
=65mA
I
F
=65mA
I
F
=65mA
V
R
=5V
Φ
V
F
Ra
-----
2θ
1/2
I
R
Notes:
1. Tolerance of Luminous flux: ±11%.
2. Tolerance of Forward Voltage: ±0.1V.
3. Tolerance of Color Rendering Index: ±2
4. Efficacy characteristics under the condition of 65mA and 5000K .
3
Copyright © 2015, Everlight Americas Inc.
. Release Date: 15.Dec. 2015. Issue No:
Issue No:
www.everlightamericas.com
℃
℃
Reflow Soldering : 260
for 10 sec.
for 3 sec.
℃
℃
℃
℃
/W
DATASHEET
SMD PLCC
EAHE2835WD63
Bin Range of Luminous Flux
2700K----
Bin Code
T1
T2
T3
T4
T5
Min.
27
29
31
33
35
Max.
29
31
33
35
37
lm
I
F
=65mA
Unit
Condition
3000K----
Bin Code
T1
T2
T3
T4
T5
Min.
28
30
32
34
36
Max.
30
32
34
36
38
lm
I
F
=65mA
Unit
Condition
4000K----
Bin Code
T1
T2
T3
T4
T5
Min.
29
31
33
35
37
Max.
31
33
35
37
39
lm
I
F
=65mA
Unit
Condition
4
Copyright © 2015, Everlight Americas Inc.
. Release Date: 15.Dec. 2015. Issue No:
Issue No:
www.everlightamericas.com
DATASHEET
SMD PLCC
EAHE2835WD63
5000K---
Bin Code
T1
T2
T3
T4
T5
Min.
30
32
34
36
38
Max.
32
34
36
38
40
lm
I
F
=65mA
Unit
Condition
5700K---
Bin Code
T1
T2
T3
T4
T5
Min.
30
32
34
36
38
Max.
32
34
36
38
40
lm
I
F
=65mA
Unit
Condition
6500K---
Bin Code
T1
T2
T3
T4
T5
Min.
29
31
33
35
37
Max.
31
33
35
37
39
lm
I
F
=65mA
Unit
Condition
Notes:
Tolerance of Luminous flux: ±11%
5
