MXZ9-PW35-0000 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> MXZ9-PW35-0000

MXZ9-PW35-0000: DescriptionStandard LEDs - SMD Warm White, 3500K; CategoryLED optoelectronic/LED; File Size2MB，25 Pages; ManufacturerLumileds; Websitehttps://www.lumileds.com/

Download Datasheet Parametric Compare View All

MXZ9-PW35-0000 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MXZ9-PW35-0000	-	-	View	Buy Now

MXZ9-PW35-0000 Overview

Standard LEDs - SMD Warm White, 3500K

MXZ9-PW35-0000 Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	Lumileds
Product Category	Standard LEDs - SMD
RoHS	Details
Package / Case	1606 (4014 metric)
Illumination Color	White (Warm White)
Wavelength/Color Temperature	3500 K
Luminous Intensity	-
Viewing Angle	-
Lens Color/Style	Tinted
If - Forward Current	30 mA
Vf - Forward Voltage	2.9 V
Power Rating	-
Length	4 mm
Height	0.7 mm
Width	1.4 mm
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Packaging	Cut Tape
Packaging	MouseReel
Packaging	Reel
Type	SMD LEDs
Lens Shape	Rectangular
Mounting Style	SMD/SMT
Peak Wavelength	-
Color Rendering Index - CRI	90
Lens Dimensions	3.34 mm x 1 mm
Luminous Flux/Radiant Flux	9 lm
NumOfPackaging	3
Operating Supply Voltage	-
Factory Pack Quantity	3000
Vr - Reverse Voltage	5 V

Preview

Download Datasheet

View All

ILLUMINATION

For NEW designs consider

this replacement product:

• LUXEON 3014

O O

R L

D O

ER N

A E

B R

LUXEON 4014

A compact footprint delivering high

efficacy and just the right amount of light

LUXEON 4014 is a 2.9V low-power product, the first of its kind from

Lumileds. It is a compact QFN 4.0mm x 1.4mm x 0.7mm package that

delivers the Quality of Light needed for indoor lighting applications.

LUXEON 4014 offers an ideal solution when uniformity and a smooth

lighting appearance are critical in luminaire designs.

FEATURES AND BENEFITS

PRIMARY APPLICATIONS

Indoor Area Lighting

Rectangular QFN package design increases uniformity

Superior heat dissipation enables cost effective design

Unique phosphor technology enables high efficacy

1/6

ANSI color binning for tight color control

Superior heat dissipation enables cost effective thermal design

COMPLIANT

RoHS

Table of Contents

General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Product Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Average Lumen Maintenance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Environmental Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

O O

R L

D O

ER N

A E

B R

Product Performance and Characterization Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

JEDEC Moisture Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Reflow Soldering Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Material Information & Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Characteristic Curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Typical Forward Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Light Output Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Typical Radiation Patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Emitter Pocket Tape Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Emitter Reel Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Product Binning and Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Color Bin Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

MXZ9-PW35-0000 Related Products

	MXZ9-PW35-0000	MXZ7-PW40-0000	MXZ8-PW57-0000	MXZ7-PW65-0000	MXZ9-PW27-0000	MXZ7-PW50-0000	MXZ8-PW50-0000	MXZ8-PW22-0000	MXZ8-PW30-0000
Description	Standard LEDs - SMD Warm White, 3500K	Standard LEDs - SMD Neutral White, 4000K	Standard LEDs - SMD Cool White, 5700K	Standard LEDs - SMD Cool White, 6500K	Standard LEDs - SMD Warm White, 2700K	Standard LEDs - SMD Cool White, 5000K	Standard LEDs - SMD Cool White, 5000K	Standard LEDs - SMD Warm White, 2200K	Standard LEDs - SMD Warm White, 3000K
Product Attribute	Attribute Value	Attribute Value	Attribute Value	Attribute Value	Attribute Value	Attribute Value	Attribute Value	Attribute Value	Attribute Value
Manufacturer	Lumileds	Lumileds	Lumileds	Lumileds	Lumileds	Lumileds	Lumileds	Lumileds	Lumileds
Product Category	Standard LEDs - SMD	Standard LEDs - SMD	Standard LEDs - SMD	Standard LEDs - SMD	Standard LEDs - SMD	Standard LEDs - SMD	Standard LEDs - SMD	Standard LEDs - SMD	Standard LEDs - SMD
RoHS	Details	Details	Details	Details	Details	Details	Details	Details	Details
Package / Case	1606 (4014 metric)	1606 (4014 metric)	1606 (4014 metric)	1606 (4014 metric)	1606 (4014 metric)	1606 (4014 metric)	1606 (4014 metric)	1606 (4014 metric)	1606 (4014 metric)
Illumination Color	White (Warm White)	White (Neutral White)	White (Cool White)	White (Cool White)	White (Warm White)	White (Cool White)	White (Cool White)	White (Warm White)	White (Warm White)
Wavelength/Color Temperature	3500 K	4000 K	5700 K	6500 K	2700 K	5000 K	5000 K	2200 K	3000 K
Lens Color/Style	Tinted	Tinted	Tinted	Tinted	Tinted	Tinted	Tinted	Tinted	Tinted
If - Forward Current	30 mA	30 mA	30 mA	30 mA	30 mA	30 mA	30 mA	30 mA	30 mA
Vf - Forward Voltage	2.9 V	2.9 V	2.9 V	2.9 V	2.9 V	2.9 V	2.9 V	2.9 V	2.9 V
Length	4 mm	4 mm	4 mm	4 mm	4 mm	4 mm	4 mm	4 mm	4 mm
Height	0.7 mm	0.7 mm	0.7 mm	0.7 mm	0.7 mm	0.7 mm	0.7 mm	0.7 mm	0.7 mm
Width	1.4 mm	1.4 mm	1.4 mm	1.4 mm	1.4 mm	1.4 mm	1.4 mm	1.4 mm	1.4 mm
Minimum Operating Temperature	- 40 C	- 40 C	- 40 C	- 40 C	- 40 C	- 40 C	- 40 C	- 40 C	- 40 C
Maximum Operating Temperature	+ 85 C	+ 85 C	+ 85 C	+ 85 C	+ 85 C	+ 85 C	+ 85 C	+ 85 C	+ 85 C
Type	SMD LEDs	SMD LEDs	SMD LEDs	SMD LEDs	SMD LEDs	SMD LEDs	SMD LEDs	SMD LEDs	SMD LEDs
Lens Shape	Rectangular	Rectangular	Rectangular	Rectangular	Rectangular	Rectangular	Rectangular	Rectangular	Rectangular
Mounting Style	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT
Color Rendering Index - CRI	90	70	80	70	90	70	80	80	80
Lens Dimensions	3.34 mm x 1 mm	3.34 mm x 1 mm	3.34 mm x 1 mm	3.34 mm x 1 mm	3.34 mm x 1 mm	3.34 mm x 1 mm	3.34 mm x 1 mm	3.34 mm x 1 mm	3.34 mm x 1 mm
Luminous Flux/Radiant Flux	9 lm	10 lm	9.5 lm	10 lm	8.5 lm	10 lm	10 lm	8.5 lm	8.5 lm
Factory Pack Quantity	3000	3000	3000	3000	3000	3000	3000	3000	3000
Vr - Reverse Voltage	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V
Packaging	Reel	Reel	Reel	Reel	Reel	Reel	Reel	Reel	Reel
NumOfPackaging	3	-	3	3	3	3	3	-	-
Color Temperature	-	4000 K	5700 K	6500 K	2700 K	5000 K	5000 K	-	-
Moisture Sensitive	-	-	Yes	Yes	Yes	Yes	Yes	Yes	Yes
