CLD-DS46 Rev 4G
Product family data sheet
Cree
®
XLamp
®
ML-C LEDs
ProDuCt DEsCriPtion
The Cree XLamp
®
ML-C LeD brings
lighting-class reliability and performance
to 1/3-watt LeDs. The XLamp ML-C LeD
expands Cree’s lighting-class leadership
to LeD bulbs and linear and distributed
lighting
applications.
With
XLamp
FEAturEs
•
Available in white (2600 K to 8300 K
CCT), 80-, 85- and 90-CRI minimum
and royal blue
•
•
•
White LeDs available in both parallel
and series
ANSI-compatible sub-bins
Maximum drive current: 350 mA for
parallel, 175 mA for series, 250 mA
for royal blue
•
•
•
•
120° viewing angle, uniform
chromaticity profile
electrically neutral thermal path
RoHS and ReACh compliant
UL
®
recognized component
(E349212)
tAbLE oF ContEnts
Characteristics ............................................2
Flux Characteristics ....................................3
Relative Spectral Power Distribution .........6
Relative Luminous Flux vs. Junction
Temperature ................................................7
Relative Radiant Flux vs. Junction
Temperature ................................................7
electrical Characteristics ............................8
Relative Luminous Flux vs. Current............9
Relative Radiant Flux vs. Current ............ 10
Typical Spatial Distribution...................... 11
Thermal Design ........................................ 12
Reflow Soldering Characteristics
............ 14
Notes ........................................................ 15
Mechanical Dimensions .......................... 17
Tape and Reel ...........................................
18
Packaging .................................................
19
LeD lighting-class reliability, a wide
viewing angle, uniform light output, and
industry-leading chromaticity binning in
a 3.5-mm X 3.5-mm package, the XLamp
ML-C LeD continues Cree’s history of
segment-focused product innovation in
LeDs for lighting applications.
The XLamp ML-C LeD brings high
performance and a smooth look to a
wide range of lighting applications,
including linear lighting, fluorescent
retrofits and retail-display lighting.
www.CRee.Com/XLAmp
Copyright © 2011-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are
registered trademarks and the Cree logo is a trademark of Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
Cree, Inc.
4600 Silicon Drive
Durham, NC 27703
USA Tel: +1.919.313.5300
1
XLamp
®
mL-C LED
ChArACtEristiCs (t
J
= 25 °C)
Characteristics
Thermal resistance, junction to solder point
viewing angle (FWHM) - white
viewing angle (FWHM) - royal blue
Temperature coefficient of voltage - parallel
Temperature coefficient of voltage - series
Temperature coefficient of voltage - royal blue
ESD classification (HBM per Mil-Std-883D) - parallel
ESD withstand voltage (HBM per Mil-Std-883D) - series
DC forward current - parallel
DC forward current - series
DC forward current - royal blue
Reverse voltage
Forward voltage (@ 100 mA) - parallel
Forward voltage (@ 50 mA) - series
Forward voltage (@ 100 mA) - royal blue
LeD junction temperature
v
mA
mA
mA
v
v
v
v
°C
3.2
6.4
3.2
unit
°C/W
degrees
degrees
mv/°C
mv/°C
mv/°C
Minimum
typical
13
120
125
-3.4
-6.8
-3.4
Class 2
8000
350
175
250
-5
3.4
7.0
3.4
150
Maximum
Copyright © 2011-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
2
XLamp
®
mL-C LED
FLuX ChArACtEristiCs - ML-C PArALLEL WhitE (t
J
= 25 °C)
The following table provides several base order codes for XLamp ML-C LEDs. It is important to note that the base order codes listed
here are a subset of the total available order codes for the product family. For more order codes, as well as a complete description of the
order-code nomenclature, please consult the XLamp ML Family LED Binning and Labeling document.
Minimum Luminous Flux
(lm) @ 100 mA
Group
K2
J3
K2
J3
K2
J3
K2
J3
K2
J3
J3
J2
J3
J2
H0
J2
Flux (lm)
30.6
26.8
30.6
26.8
30.6
26.8
30.6
26.8
30.6
26.8
26.8
23.5
26.8
23.5
18.1
23.5
Color
CCt range
Minimum
Maximum
8300 K
Calculated Min.
Luminous Flux (lm) @
300 mA *
63.1
55.2
63.1
55.2
63.1
55.2
63.1
55.2
63.1
55.2
55.2
48.4
55.2
48.4
37.3
48.4
order Code
Cool White
5000 K
MLCAWT-A1-0000-000051
MLCAWT-A1-0000-000X51
MLCAWT-H1-0000-0000e1
MLCAWT-H1-0000-000Xe1
MLCAWT-H1-0000-0000e3
MLCAWT-H1-0000-000Xe3
MLCAWT-A1-0000-0000e5
MLCAWT-A1-0000-000Xe5
MLCAWT-A1-0000-0000e7
MLCAWT-A1-0000-000Xe7
MLCAWT-H1-0000-000Xe5
MLCAWT-H1-0000-000We7
MLCAWT-P1-0000-000Xe5
MLCAWT-P1-0000-000We7
MLCAWT-U1-0000-000ve5
MLCAWT-U1-0000-000We7
6000 K
80-CRI
Cool White
4750 K
7000 K
5250 K
3700 K
Warm White
2800 K
3700 K
2800 K
3700 K
2800 K
3700 K
2800 K
4300 K
3200 K
4300 K
3200 K
4300 K
3200 K
4300 K
3200 K
80-CRI
Warm White
85-CRI
Warm White
90-CRI
Warm White
Notes:
• Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and ±2 on CRI
measurements. See the Measurements section (page 15).
• Typical CRI for Cool White (4300 K – 8300 K CCT) is 75.
• Typical CRI for Warm White (2600 K – 4300 K CCT) is 80.
• Minimum CRI for 80-CRI White is 80.
• Minimum CRI for 85-CRI White is 85.
• Minimum CRI for 90-CRI White is 90
*
Calculated flux values are for reference only.
Copyright © 2011-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
3
XLamp
®
mL-C LED
FLuX ChArACtEristiCs - ML-C sEriEs WhitE (t
J
= 25 °C)
The following table provides several base order codes for XLamp ML-C LEDs. It is important to note that the base order codes listed
here are a subset of the total available order codes for the product family. For more order codes, as well as a complete description of the
order-code nomenclature, please consult the XLamp ML Family LED Binning and Labeling document.
Minimum Luminous Flux
(lm) @ 50 mA
Group
K2
J3
K2
J3
K2
J3
K2
J3
K2
J3
J3
J2
J3
J2
H0
J2
Flux (lm)
30.6
26.8
30.6
26.8
30.6
26.8
30.6
26.8
30.6
26.8
26.8
23.5
26.8
23.5
18.1
23.5
Color
CCt range
Minimum
Maximum
8300 K
Calculated Min.
Luminous Flux (lm) @
150 mA *
63.1
55.2
63.1
55.2
63.1
55.2
63.1
55.2
63.1
55.2
55.2
48.4
55.2
48.4
37.3
48.4
order Code
Cool White
5000 K
MLCSWT-A1-0000-000051
MLCSWT-A1-0000-000X51
MLCSWT-H1-0000-0000e1
MLCSWT-H1-0000-000Xe1
MLCSWT-H1-0000-0000e3
MLCSWT-H1-0000-000Xe3
MLCSWT-A1-0000-0000e5
MLCSWT-A1-0000-000Xe5
MLCSWT-A1-0000-0000e7
MLCSWT-A1-0000-000Xe7
MLCSWT-H1-0000-000Xe5
MLCSWT-H1-0000-000We7
MLCSWT-P1-0000-000Xe5
MLCSWT-P1-0000-000We7
MLCSWT-U1-0000-000ve5
MLCSWT-U1-0000-000We7
6000 K
80-CRI
Cool White
4750 K
7000 K
5250 K
3700 K
Warm White
2800 K
3700 K
2800 K
3700 K
2800 K
3700 K
2800 K
4300 K
3200 K
4300 K
3200 K
4300 K
3200 K
4300 K
3200 K
80-CRI
Warm White
85-CRI
Warm White
90-CRI
Warm White
Notes:
• Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and ±2 on CRI
measurements. See the Measurements section (page 15).
• Typical CRI for Cool White (4300 K – 8300 K CCT) is 75.
• Typical CRI for Warm White (2600 K – 4300 K CCT) is 80.
• Minimum CRI for 80-CRI White is 80.
• Minimum CRI for 85-CRI White is 85.
• Minimum CRI for 90-CRI White is 90
*
Calculated flux values are for reference only.
Copyright © 2011-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
4
XLamp
®
mL-C LED
FLuX ChArACtEristiCs - ML-C royAL bLuE (t
J
= 25 °C)
The following table provides a base order code for XLamp ML-C Royal Blue LEDs. It is important to note that the base order codes listed
here are a subset of the total available order codes for the product family. For more order codes, as well as a complete description of the
order-code nomenclature, please consult the XLamp ML Family LED Binning and Labeling document.
Dominant Wavelength range
Color
Minimum
Group
Royal Blue
D3
DWL
(nm)
450
Maximum
Group
D5
DWL
(nm)
465
Minimum radiant
Flux (mW) @ 100 mA
Group
07
Flux (mW)
100
MLCROY-A1-0000-000201
order Code
Note:
• Cree maintains a tolerance of ±7% on flux and power measurements, ±0.005 on chromaticity (CCx, CCy) measurements and ±2 on CRI
measurements
and ±1 nm on dominant wavelength measurements.
See the Measurements section (page 15).
Copyright © 2011-2017 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree
®
and XLamp
®
are registered trademarks and the Cree logo is a trademark of
Cree, Inc. UL
®
and the UR logo are registered trademarks of UL LLC.
5
