T1/E1 Line Interface Modules
DIL Package
Conflict
FREE
Product Features:
Standard series of 6 pin DIL Line Interface Modules
to meet the isolation and impedance matching
requirements for T1, E1, CEPT and PRI ISDN
applications.
Isolation modules are available for all popular
LIU’s.
1,500 Vrms hi-pot
Operating Temperature Range is 0 to 70°C
Part Number
TD02-1205ALF
TD04-1205ALF
TD08-1205ALF
TD10-1205ALF
TD15-1205ALF
TD37-1205ALF
TD38-1505ALF
TD70-1205ALF
TD71-1205ALF
TD72-1205ALF
Schem
D
A
A
B
D
C
D
C
C
A
Turns Ratio
PRI/SEC
1CT:1
1CT:1CT
1CT:2CT
1:1:1
1:2CT
1:1.14CT
1:1.15CT
1:1.36CT
1:2.3CT
1CT:3CT
OCL
(mH min)
1.2
1.2
1.2
1.2
1.2
1.2
1.5
1.2
1.2
1.2
Pri/Sec
Cw/w
(pF max)
35
35
35
35
35
35
35
35
35
45
Pri/Sec
LL
(µH max)
0.50
0.50
0.50
0.50
0.50
0.50
0.80
0.50
0.50
0.50
DCR
Pri
(Ω max)
0.70
0.70
0.70
0.70
0.70
0.70
0.70
0.70
0.70
0.70
Primary
Pins
1-5
1-5
1-5
1-2
2-6
1-5
2-6
1-5
1-5
1-5
Schematic A
Schematic B
Schematic C
Schematic D
For additional information contact your
local representative,
or HALO’s support staff at (650) 903-3800 or
info@haloelectronics.com
T1/E1 Line Interface Modules
Package A
Dimensions: inches [mm]
Note: All unused pins are removed.
2880 Lakeside Drive #116
Santa Clara, CA 95054
(650) 903-3800
www.haloelectronics.com
HALO
®
Electronics is a leading supplier of high quality communication magnetics
including signal transformers, filters, CMR chokes, PoE power transformers,
DC/DC converters, and integrated Ethernet connectors. HALO’s leading edge
technology solutions are manufactured in ISO9001 and ISO14001 factories
offering high quality products at a competitive price.
© Copyright 2014 HALO Electronics, Inc. All rights reserved.
Revised 02/2014 Download the latest version at
www.haloelectronics.com/pdf/discrete-dil-t1.pdf
