AC Line EMI Suppression and RC Networks
PHE820E Series Metallized Polyester Film, Class X2, 300 VAC
Overview
The PHE820E Series is constructed of series winding of
metallized polyester encapsulated in self-extinguishing material
meeting the requirements of UL 94 V–0.
Applications
Typical applications include worldwide use in electromagnetic
interference suppression in all X2 and across-the-line
applications.
Benefits
•
•
•
•
•
•
•
•
•
•
Approvals: ENEC, UL, cUL
Rated voltage: 300 VAC 50/60 Hz
Capacitance range: 0.01 – 2.2 µF
Lead spacing: 15.0 – 37.5 mm
Capacitance tolerance: ±20%, ±10%, ±5% on request
Climatic category: 40/100/56, IEC 60068–1
Tape and reel in accordance with IEC 60286–2
RoHS Compliant and lead-free terminations
Operating temperature range of -40˚C to +100˚C
100% screening factory test at 2,150 VDC
Click image above for interactive 3D content
Open PDF in Adobe Reader for full functionality
Legacy Part Number System
PHE820
Series
X2, Metallized Polyester
E
Rated Voltage (VAC)
E = 300
B
Lead Spacing (mm)
B = 15.0
D = 22.5
F = 27.5
R = 37.5
5100
Capacitance Code (pF)
The last three digits
represent significant
figures. The first digit
specifies the total
number of digits.
M
Capacitance
Tolerance
J = ±5%
K = ±10%
M = ±20%
R17
Packaging
See Ordering
Options Table
New KEMET Part Number System
F
Capacitor
Class
F = Film
720
Series
X2,
Metallized
Polyester
B
Lead Spacing (mm)
B = 15.0
D = 22.5
F = 27.5
R = 37.5
D
Size Code
See Dimension
Table
103
Capacitance Code (pF)
First two digits represent
significant figures. Third digit
specifies number of zeros.
M
Capacitance
Tolerance
J = ±5%
K = ±10%
M = ±20%
300
Rated Voltage
(VAC)
300 = 300
A
Packaging
See Ordering
Options Table
One world. One KEMET
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com
F3010_PHE820E_X2_300 • 5/14/2015
1
Film Capacitors
AC Line EMI Suppression and RC Networks – PHE820E Series Metallized Polyester Film, Class X2, 300 VAC
Ordering Options Table
Lead Spacing
Nominal (mm)
Type of Leads and Packaging
Standard Lead and Packaging Options
Bulk (Bag) – Short Leads
Bulk (Bag) – Long Leads
6 +0/-1
17 +0/-1
30 +5/-0
H
0
= 18.5 +/-0.5
H
0
= 18.5 +/-0.5
H
0
= 16.5 +/-0.5
H
0
= 16.5 +/-0.5
C
A
ALW0L
L
P
XLAF1
XLTF1
R06
R17
R30
R17T0
R17T1
R25XA
R25X2
Lead Length
(mm)
KEMET
Legacy
Lead and Lead and
Packaging Packaging
Code
Code
15
Other Lead and Packaging Options
Bulk (Bag) – Max Length Leads
Tape & Reel (Standard Reel)
Tape & Reel (Large Reel)
Native 15
formed to 7.5
Ammo Pack
Tape & Reel (Standard Reel)
Standard Lead and Packaging Options
Bulk (Tray) – Short Leads
6 +0/-1
H
0
= 18.5 +/-0.5
H
0
= 18.5 +/-0.5
6 +0/-1
C
L
P
Z
R06L2
(1)
R17T0
R17T1
R06L2
(1)
22.5
Other Lead and Packaging Options
Tape & Reel (Standard Reel)
Tape & Reel (Large Reel)
Pizza Pack
Standard Lead and Packaging Options
27.5
Bulk (Tray) – Short Leads
Other Lead and Packaging Options
Tape & Reel (Large Reel)
Pizza Pack
Standard Lead and Packaging Options
6 +0/-1
H
0
= 18.5 +/-0.5
6 +0/-1
C
P
Z
R06L2
(1)
R17T1
R06L2
(1)
37.5
Bulk (Tray) – Short Leads
Other Lead and Packaging Options
Pizza Pack
6 +0/-1
6 +0/-1
C
Z
R06L2
(1)
R06L2
(1)
(1) Please specify Bulk (Tray) or Pizza Packaging.
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com
F3010_PHE820E_X2_300 • 5/14/2015
2
Film Capacitors
AC Line EMI Suppression and RC Networks – PHE820E Series Metallized Polyester Film, Class X2, 300 VAC
Dimensions – Millimeters
FRONT VIEW
L
SIDE VIEW
B
H
d
LL
p
0.5
KEMET Size
Code
BD
BE
BL
BJ
BQ
DD
DH
DM
DT
FE
FG
FM
FR
RK
RM
Legacy Size
Code
B04
B05
B06
B10
B11
D13
D14
D15
D16
F11
F12
F13
F14
R02
R03
p
Nominal
15
15
15
15
15
22.5
22.5
22.5
22.5
27.5
27.5
27.5
27.5
37.5
37.5
Tolerance
+/-0.4
+/-0.4
+/-0.4
+/-0.4
+/-0.4
+/-0.4
+/-0.4
+/-0.4
+/-0.4
+/-0.4
+/-0.4
+/-0.4
+/-0.4
+/-0.4
+/-0.4
Nominal
5.5
5.5
7.5
6.5
8.5
6.5
8.0
9.0
11.0
10.5
11.5
14.5
17.5
16.5
19.0
B
Tolerance
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Nominal
10.5
12.5
14.5
12.5
16.0
14.5
16.0
18.5
21.5
20.5
22.5
24.5
28.0
32.0
36.0
H
Tolerance
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Nominal
18.0
18.0
18.0
18.0
18.0
26.0
26.0
26.0
26.0
31.5
31.5
31.5
31.5
41.0
41.0
L
Tolerance
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Maximum
Nominal
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
1
1
d
Tolerance
+/-0.05
+/-0.05
+/-0.05
+/-0.05
+/-0.05
+/-0.05
+/-0.05
+/-0.05
+/-0.05
+/-0.05
+/-0.05
+/-0.05
+/-0.05
+/-0.05
+/-0.05
Note: See Ordering Options Table for lead length (LL) options.
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com
F3010_PHE820E_X2_300 • 5/14/2015
3
Film Capacitors
AC Line EMI Suppression and RC Networks – PHE820E Series Metallized Polyester Film, Class X2, 300 VAC
Performance Characteristics
Rated Voltage
Capacitance Range
Capacitance Tolerance
Temperature Range
Climatic Category
Approvals
Dissipation Factor
300 VAC 50/60 Hz
0.01 – 2.2 µF
±20%, ±10%, ±5% on request
-40ºC to +100°C
40/100/56
ENEC, UL, cUL
Maximum Values at +23°C
1 kHz
1.0%
The 100% screening factory test is carried out at 2,150 VDC. The
voltage level is selected to meet the requirements in applicable
equipment standards. All electrical characteristics are checked
after the test. It is not permitted to repeat this test as there is a risk
to damage the capacitor. KEMET is not liable in such case for any
failures.
Minimum Values Between Terminals
Insulation Resistance
C ≤ 0.33 µF
C > 0.33 µF
In DC Applications
Recommended voltage ≤ 760 VDC
≥ 30,000 MΩ
≥ 10,000 MΩ • µF
Test Voltage Between Terminals
Environmental Test Data
Test
Endurance
Vibration
Bump
Change of Temperature
Active Flammability
Passive Flammability
Damp Heat Steady State
IEC Publication
EN/IEC 60384–14
IEC 60068–2–6 Test Fc
IEC 60068–2–29 Test Eb
IEC 60068–2–14 Test Na
IEC 60384–14
IEC 60384–14
IEC 60068–2–78 Test Cab
Procedure
1.25 x V
R
VAC 50 Hz, once every hour increase to 1,000 VAC for 0.1
second, 1,000 hours at upper rated temperature
3 directions at 2 hours each 10 – 55 Hz at 0.75 mm or 98 m/s
2
1,000 bumps at 390 m/s
2
Upper and lower rated temperature 5 cycles
V
R
+ 20 surge pulses at 2.5 kV (pulse every 5 seconds)
IEC 60384–1, IEC 60695–11–5 Needle-flame test
+40°C and 93% RH, 56 days
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com
F3010_PHE820E_X2_300 • 5/14/2015
4
Film Capacitors
AC Line EMI Suppression and RC Networks – PHE820E Series Metallized Polyester Film, Class X2, 300 VAC
Approvals
Mark
Specification
EN/IEC 60384–14
File Number
SE/0140–12E
UL 1414 (up to 1 μF, 85°C, 250 VAC)
CSA – C22.2 No. 1
(up to 1 μF, 85°C, 250 VAC)
UL 1283 (310 VAC)
CSA – C22.2 No. 8 (310 VAC)
E73869
E73869
E100117
E100117
Environmental Compliance
All KEMET EMI capacitors are RoHS Compliant.
Table 1 – Ratings & Part Number Reference
Capacitance
Size Code
Value (µF) (New/Legacy)
0.010
0.015
0.022
0.033
0.047
0.068
0.10
0.10
0.15
0.22
0.33
0.33
0.47
0.68
1.0
1.5
2.2
BD/B04
BD/B04
BD/B04
BE/B05
BJ/B10
BL/B06
BQ/B11
DD/D13
DH/D14
DM/D15
DT/D16
FE/F11
FG/F12
FM/F13
FR/F14
RK/R02
RM/R03
Max Dimensions in mm
B
5.5
5.5
5.5
5.5
6.5
7.5
8.5
6.5
8.0
9.0
11.0
10.5
11.5
14.5
17.5
16.5
19.0
H
10.5
10.5
10.5
12.5
12.5
14.5
16.0
14.5
16.0
18.5
21.5
20.5
22.5
24.5
28.0
32.0
36.0
L
18.0
18.0
18.0
18.0
18.0
18.0
18.0
26.0
26.0
26.0
26.0
31.5
31.5
31.5
31.5
41.0
41.0
Lead
f
o
dV/dt
Spacing (p) (MHz) (V/µs)
15
15
15
15
15
15
15
22.5
22.5
22.5
22.5
27.5
27.5
27.5
27.5
37.5
37.5
13
11
9.0
7.5
6.5
5.5
4.5
4.5
3.9
2.7
2.5
2.4
1.9
1.6
1.3
0.75
0.65
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
New KEMET
Part Number
F720BD103(1)300(2)
F720BD153(1)300(2)
F720BD223(1)300(2)
F720BE333(1)300(2)
F720BJ473(1)300(2)
F720BL683(1)300(2)
F720BQ104(1)300(2)
F720DD104(1)300(2)
F720DH154(1)300(2)
F720DM224(1)300(2)
F720DT334(1)300(2)
F720FE334(1)300(2)
F720FG474(1)300(2)
F720FM684(1)300(2)
F720FR105(1)300(2)
F720RK155(1)300(2)
F720RM225(1)300(2)
Legacy Part
Number
PHE820EB5100(1)(2)
PHE820EB5150(1)(2)
PHE820EB5220(1)(2)
PHE820EB5330(1)(2)
PHE820EB5470(1)(2)
PHE820EB5680(1)(2)
PHE820EB6100(1)(2)
PHE820ED6100(1)(2)
PHE820ED6150(1)(2)
PHE820ED6220(1)(2)
PHE820ED6330(1)(2)
PHE820EF6330(1)(2)
PHE820EF6470(1)(2)
PHE820EF6680(1)(2)
PHE820EF7100(1)(2)
PHE820ER7150(1)(2)
PHE820ER7220(1)(2)
Capacitance
Value (µF)
Size Code (New/
Legacy)
B (mm)
H (mm)
L (mm)
Lead Spacing
(p)
f
o
(MHz)
dV/dt
(V/µs)
New KEMET
Part Number
Legacy Part Number
(1) M = ±20%, K = ±10%, J = ±5% on request.
(2) Insert ordering code for lead type and packaging. See Ordering Options Table for available options.
© KEMET Electronics Corporation • P.O. Box 5928 • Greenville, SC 29606 (864) 963-6300 • www.kemet.com
F3010_PHE820E_X2_300 • 5/14/2015
5
