I
NTEGRATED
C
IRCUITS
D
IVISION
Driver Characteristics
Parameter
V
OFFSET
I
O +/-
(Source/Sink)
V
OUT
t
on
/t
off
Delay Matching (Max)
600V High and Low Side
Gate Driver
Description
Units
V
A
V
ns
ns
IX2113
Rating
600
2/2
10-20
113/100
20
The IX2113 is a high voltage integrated circuit that can
drive high speed MOSFETs and IGBTs that operate at
up to +600V. The IX2113 is configured with
independent high-side and low-side referenced output
channels, both of which can source and sink 2A. The
floating high-side channel can drive an N-channel
power MOSFET or IGBT 600V from the common
reference.
Manufactured on IXYS Integrated Circuits Division's
proprietary high-voltage BCDMOS on SOI (silicon on
insulator) process, the IX2113 is extremely robust, and
is virtually immune to negative transients. The UVLO
circuit prevents the turn-on of the MOSFET or IGBT
until there is sufficient V
BS
or V
CC
supply voltage.
Propagation delays are matched for use in high
frequency applications.
The IX2113 is available in a 14-pin DIP package and
in a 16-pin SOIC package.
Features
•
Floating Channel for Bootstrap Operation to +600V
with Absolute Maximum Rating of +700V
•
Outputs Capable of Sourcing and Sinking 2A
•
Gate Drive Supply Range From 10V to 20V
•
Enhanced Robustness due to SOI Process
•
Tolerant to Negative Voltage Transients:
dV/dt Immune
•
3.3V Logic Compatible
•
Undervoltage Lockout for Both High-side and
Low-Side Outputs
•
Matched Propagation Delays
Ordering Information
Part
IX2113G
IX2113B
IX2113BTR
Description
14-Pin DIP (25/Tube)
16-Pin SOIC (50/Tube)
16-Pin SOIC (1000/Reel)
IX2113 Functional Block Diagram
V
DD
Level
Shift
V
DD
/ V
CC
V
SS
/ COM
V
B
Pulse
Generator
High
Voltage
Level
Shift
UVLO
R
S
R
Q
Buffer
HO
HIN
Input Control Logic
&
Cycle-by-Cycle
Edge-Triggered
Shutdown
SD
LIN
Level
Shift
V
DD
/ V
CC
V
SS
/ COM
LS Delay
Control
UVLO
V
S
V
CC
Buffer
LO
V
SS
COM
DS-IX2113-R03
www.ixysic.com
1
I
NTEGRATED
C
IRCUITS
D
IVISION
IX2113
1. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Package Pinout: 16-Pin SOIC Package. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Pin Description: 16-Pin SOIC Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Package Pinout: 14-Pin DIP Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Pin Description: 14-Pin DIP Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.5 Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.6 Recommended Operating Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.7 Dynamic Electrical Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.8 Static Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.9 Test Waveforms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3
3
3
3
3
4
4
5
5
6
2. Typical Performance Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3. Manufacturing Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Moisture Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 ESD Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Reflow Profile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4 Board Wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.5 Mechanical Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11
11
11
11
11
12
2
www.ixysic.com
R03
I
NTEGRATED
C
IRCUITS
D
IVISION
1 Specifications
1.1 Package Pinout: 16-Pin SOIC Package
1.3 Package Pinout: 14-Pin DIP Package
IX2113
LO - 1
COM - 2
V
CC
- 3
4
5
V
S
- 6
V
B
- 7
HO - 8
16
15 - V
SS
14 - LIN
13 - SD
12 - HIN
11 - V
DD
10
9
LO - 1
COM - 2
V
CC
- 3
4
V
S
- 5
V
B
- 6
HO - 7
14
13 - V
SS
12 - LIN
11 - SD
10 - HIN
9 - V
DD
8
1.2 Pin Description: 16-Pin SOIC Package
Pin#
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Name
LO
COM
V
CC
-
-
V
S
V
B
HO
-
-
V
DD
HIN
SD
LIN
V
SS
-
Description
Low-Side Gate Drive Output
Low-Side Return
Low-Side Supply
No Connection
No Connection
High-Side Floating Supply Return
High-Side Floating Supply
High-Side Gate Drive Output
No Connection
No Connection
Logic Supply
1.4 Pin Description: 14-Pin DIP Package
Pin#
1
2
3
4
5
6
7
8
9
10
11
Name
LO
COM
V
CC
-
V
S
V
B
HO
-
V
DD
HIN
SD
LIN
V
SS
-
Description
Low-Side Gate Drive Output
Low-Side Return
Low-Side Supply
No Connection
High-Side Floating Supply Return
High-Side Floating Supply
High-Side Gate Drive Output
No Connection
Logic Supply
Logic Input for High-Side Gate Driver
Output (HO), In-Phase
Logic Input for Shutdown
Logic Input for Low-Side Gate Driver
Output (LO), In-Phase
Logic Ground
No Connection
Logic Input for High-Side Gate Driver
Output (HO), In-Phase
Logic Input for Shutdown
Logic Input for Low-Side Gate Driver
Output (LO), In-Phase
Logic Ground
No Connection
12
13
14
R03
www.ixysic.com
3
I
NTEGRATED
C
IRCUITS
D
IVISION
1.5 Absolute Maximum Ratings
IX2113
Absolute maximum ratings indicate sustained limits beyond which damage to the device may occur. All voltage
parameters are absolute voltages referenced to COM. The thermal resistance and power dissipation ratings are
measured under board-mounted and still-air conditions.
Parameter
High-Side Floating Supply
Voltage
High-Side Floating Supply Offset
Voltage
High-Side Floating Output
Voltage
Low-Side Fixed Supply
Voltage
Low-Side Output
Voltage
Logic Supply
Voltage
Logic Supply Offset
Voltage
Logic Input
Voltage
(HIN, LIN, SD)
Allowable Offset Supply
Voltage
Transient
Package Power Dissipation @ T
A
25°C
Thermal Resistance, Junction to Ambient
Junction Temperature
Storage Temperature
Lead Temperature (Soldering, 10 Seconds)
16-Pin SOIC
14-Pin DIP
16-Pin SOIC
14-Pin DIP
Symbol
V
B
V
S
V
HO
V
CC
V
LO
V
DD
V
SS
V
IN
dV
S
/dt
PD
R
JA
T
J
T
S
T
L
Min
-0.3
V
B
-20
V
S
-0.3
-0.3
-0.3
-0.3
V
CC
-20
V
SS
-0.3
-
-
-
-
-55
-
Max
700
V
B
+0.3
V
B
+0.3
20
V
CC
+0.3
V
SS
+20
V
CC
+0.3
V
DD
+0.3
50
1.25
1.6
100
75
150
150
300
Units
V
V
V
V
V
V
V
V
V/ns
W
°C/W
°C
°C
°C
1.6 Recommended Operating Conditions
For proper operation, the device should be used within the recommended conditions. The V
S
and V
SS
offset ratings
are tested with all supplies biased at a 15V differential.
Parameter
High-Side Floating Supply Absolute
Voltage
High-Side Floating Supply Offset
Voltage
High-Side Floating Output
Voltage
Low-Side Fixed Supply
Voltage
Low-Side Output
Voltage
Logic Supply
Voltage
Logic Supply Offset
Voltage
Logic Input
Voltage
(HIN, LIN, SD)
Ambient Temperature
Symbol
V
B
V
S
V
HO
V
CC
V
LO
V
DD
V
SS
V
IN
T
A
Min
V
S
+10
-
V
S
10
0
V
SS
+3
-5
V
SS
-40
Max
V
S
+20
600
V
B
20
V
CC
V
SS
+20
5
V
DD
+125
Units
V
°C
4
www.ixysic.com
R03
I
NTEGRATED
C
IRCUITS
D
IVISION
1.7 Dynamic Electrical Characteristics
V
BIAS
(V
CC
, V
BS
, V
DD
)=15V, CL=1000 pF, T
A
=25°C, and V
SS
=COM unless otherwise specified.
Parameter
Turn-On propagation Delay
Turn-Off propagation Delay
Shutdown propagation Delay
Turn-On Rise Time
Turn-Off Fall Time
Delay Matching, HS & LS Turn-On/Off
Conditions
V
S
=0V
V
S
=600V
-
-
-
Symbol
t
on
t
off
t
SD
t
r
t
f
MT
IX2113
Min
-
-
-
-
-
-
Typ
113
100
94
9.4
9.7
-
Max
160
150
160
35
25
20
Units
ns
1.8 Static Electrical Characteristics
V
BIAS
(V
CC
, V
BS
, V
DD
)=15V, T
A
=25°C and V
SS
=COM unless otherwise specified. The V
IN
, V
TH
, and I
IN
parameters
are referenced to V
SS
and are applicable to all three logic input leads: HIN, LIN, and SD. The V
O
and I
O
parameters
are referenced to COM and are applicable to the respective output leads: HO or LO.
Parameter
Logic “1” Input
Voltage
Logic “0” Input
Voltage
Logic “1” Input
Voltage
Logic “0” Input
Voltage
High-Level Output
Voltage, V
BIAS
-V
O
Low-Level Output
Voltage, V
O
Offset Supply Leakage Current
Quiescent
V
BS
Supply Current
Quiescent
V
CC
Supply Current
Quiescent
V
DD
Supply Current
Logic “1” Input Bias Current
Logic “0” Input Bias Current
V
BB
Supply Undervoltage Positive Going Threshold
V
BB
Supply Undervoltage
Negative
Going Threshold
V
CC
Supply Undervoltage Positive Going Threshold
V
CC
Supply Undervoltage
Negative
Going Threshold
Output High Short Circuit Pulsed Current
Output Low Short Circuit Pulsed Current
Conditions
V
DD
=15V
V
DD
=3V
I
O
=0A
I
O
=20mA
V
B
=V
S
=600V
V
IN
=0V or
V
DD
V
IN
=0V or
V
DD
V
IN
=0V or
V
DD
V
IN
=V
DD
V
IN
=0V
-
-
-
-
V
O
=0V,
V
IN
=V
DD
, PW10s
V
O
=15V,
V
IN
=0V, PW10s
Symbol
V
IH
V
IL
V
IH
V
IL
V
OH
V
OL
I
LK
I
QBS
I
QCC
I
QDD
I
IN+
I
IN-
V
BSUV+
V
BSUV-
V
CCUV+
V
CCUV-
I
O+
I
O-
Min
9.5
-
2.5
-
-
-
-
-
-
-
-
-
7.5
7
7.4
7
2
2
Typ
-
-
-
-
1.6
-
-
187
300
-
22
-
8.4
7.8
8.4
7.8
2.5
2.5
Max
-
6
-
0.8
2.5
0.15
60
310
420
1
40
5
9.7
9.4
9.6
9.4
-
-
Units
V
V
V
A
A
V
A
R03
www.ixysic.com
5
