LCD-128Y064L
Vishay
128 x 64 Graphic LCD
FEATURES
• Type: Graphic
• Display format: 128 x 64 dots
• Built-in controller:
Epson SED15605 (or equivalent)
• Duty cycle: 1/64
• + 3 V power supply
• N.V. built-in
• Compliant to RoHS directive 2002/95/EC
MECHANICAL DATA
ITEM
Module Dimension
Viewing Area
Dot Size
Dot Pitch
Mounting Hole
Character Size
STANDARD VALUE
90.5 x 50.0
67.0 x 40.0
0.42 x 0.50
mm
0.46 x 0.55
N/a
N/a
UNIT
ABSOLUTE MAXIMUM RATINGS
STANDARD VALUE
ITEM
SYMBOL
MIN.
Power Supply V
DD
to V
SS
Input Voltage
V
I
2.7
0
TYP.
3.0
-
MAX.
3.3
V
V
DD
UNIT
Note
• V
SS
= 0 V, V
DD
= 5.0 V
ELECTRICAL CHARACTERISTICS
STANDARD VALUE
ITEM
Input Voltage
Supply Current
SYMBOL
V
DD
I
DD
CONDITION
MIN.
V
DD
= + 5 V
V
DD
= + 5 V
- 20 °C
0 °C
Recommended LC Driving
Voltage for Normal Temperature
Version Module
V
DD
to V
0
25 °C
50 °C
70 °C
LED Forward Voltage
LED Forward Current
EL Power Supply Current
V
F
I
F
I
EL
25 °C
25 °C
V
EL
= 110 V
AC
, 400 Hz
2.7
-
8.7
8.5
8.4
8.1
7.9
-
-
-
TYP.
3.0
0.6
8.8
8.6
8.5
8.2
8.0
3.5
20
-
MAX.
3.3
0.8
8.9
8.7
8.6
8.4
8.2
3.8
-
5.0
V
mA
mA
V
V
mA
UNIT
OPTIONS
PROCESS COLOR
TN
STN
Gray
x
STN
Yellow
x
STN
Blue
FSTN
B&W
x
STN
Color
None
x
BACKLIGHT
LED
EL
x
CCFL
For detailed information, please see the “Product Numbering System” document.
Document Number: 37345
Revision: 16-Mar-09
For technical questions, contact:
displays@vishay.com
www.vishay.com
1
