Table 3a . Electrical and thermal characteristics for LUXEON UV FC1 at 500mA, T
j
=25°C .
Part numBer
LxF3-U41010000xxxx1
LxF3-U40010000xxxx1
LxF3-U39010000xxxx1
LxF3-U38010000xxxx1
ForWard Voltage
[1]
(V
f
)
mInImum
2.8
2.8
2.8
2.8
tyPIcal
3.1
3.1
3.1
3.2
maXImum
3.4
3.4
3.4
3.4
-2 to -3
2.0
tyPIcal temPerature
coeFFIcIent oF ForWard
Voltage
[2]
(mV/°c)
tyPIcal thermal
resIstance—JunctIon
to solder Pad (°c/W)
Notes for Table 3a:
1. Lumileds maintains a tolerance of ±0.05V on forward voltage measurements.
2. Measured between 25°C and 85°C.
Table 3b . Electrical and thermal characteristic for LUXEON UV FC2 at 1000mA, T
j
=25°C .
Part numBer
L0F3-U4102000xxxx1
L0F3-U4002000xxxx1
L0F3-U3902000xxxx1
L0F3-U3802000xxxx1
ForWard Voltage
[1]
(V
f
)
mInImum
2.8
2.8
2.8
2.8
tyPIcal
3.1
3.1
3.1
3.2
maXImum
3.4
3.4
3.4
3.6
-1 to -2
1.0
tyPIcal temPerature
coeFFIcIent oF ForWard
Voltage
[2]
(mV/°c)
tyPIcal thermal
resIstance—JunctIon
to solder Pad (°c/W)
Notes for Table 3b:
1. Lumileds maintains a tolerance of ±0.05V on forward voltage measurements.
2. Measured between 25°C and 85°C.
Absolute Maximum Ratings
Table 4 . Absolute maximum ratings for LUXEON UV FC Line .
Parameter
DC Forward Current
[1,2]
Peak Pulsed Forward Current
[1,3]
LED Junction Temperature
[1]
(DC & Pulse)
ESD Sensitivity (ANSI/ESDA/JEDEC JS-001-2012)
Operating Case Temperature
[1]
LED Storage Temperature
Soldering Temperature
Allowable Reflow Cycles
Reverse Voltage (V
reverse
)
maXImum PerFormance
1000mA for LUXEON UV FC1
2000mA for LUXEON UV FC2
1300mA for LUXEON UV FC1
2600mA for LUXEON UV FC2
120°C
Class 0B
-40°C to 120°C
-40°C to 135°C
300 ±3°C
[4]
3
LUXEON UV FC Line LEDs are not designed to be driven in reverse bias
Notes for Table 4:
1. Proper current derating must be observed to maintain the junction temperature below the maximum allowable junction temperature.
2. Residual periodic variations due to power conversion from alternating current (AC) to direct current (DC), also called “ripple,” are acceptable if the following conditions are met:
– The frequency of the ripple current is 100Hz or higher
– The average current for each cycle does not exceed the maximum allowable DC forward current
– The maximum amplitude of the ripple does not exceed 15% of the maximum allowable DC forward current
3. At 10% duty cycle with pulse width of 10ms.
4. 300°C for AuSn (gold-tin) solder system, see
AB116
for more details; 260°C for non-AuSn lead-free solder system per JEDEC J-STD-020E classification.
