C
IRCUIT
P
ROTECTORS
No. 385 / TIP
Telecom Interface Protector Specifications
Packaging
Lead Free
000: Tape/Ammopack (1400 pcs.)
T ime-Current
Standard
Transient Tolerant (T)
UL 248-14
CSA C22.2 No. 248.14
cULus Recognized
Characteristic
Materials
Base/Cap:
Brown Thermoplastic
Polyamide PA 6.6, UL 94V0
Round Pins: Copper, Sn plated
-40 ºC to +85 ºC (consider de-rating)
-40 ºC/+85 ºC/21 days
(EN 60068-1,-2-1,-2-2,-2-78)
+10 ºC to +60 ºC
relative humidity
≤
75 % yearly average,
without dew, maximum value for 30 days-95 %
24 cycles at 15 min. each (EN 60068-6)
10 - 60 Hz at 0.75 mm amplitude
60 - 2000 Hz at 10 g acceleration
10N (EN 60068-2-21)
260 ºC,
≤
3 s (Wave)
350 ºC,
≤
3 s (Soldering iron)
260 ºC, 10 s (IEC 60068-2-20)
, TIP, T, Current Rating
Approvals
Operating Temperature
Temperature
Climatic Category
Stock Conditions
Features
Dimensions (mm)
8,5
max. 8
max. 4
Surge proof for telecom applications
Reduced PCB space requirements
Highly defined cut-off times
Irreversible physical separation
Low internal resistance
Flame resistant encapsulated casing
CCCe for China import
Vibration Resistance
0,5 min
18,8
∅
0,6
1,5
W ebLinks
Further infos see:
www.wickmanngroup.com
Further application infos see
Fuseology:
Lead Pull Strength
Solderability
5,08
1 +0,1
www.wickmanngroup.com/download/
fuseology.pdf
Soldering Heat Resistance
Marking
Holes in PCB
Unit Weight
0.60 g (approx.)
Limits for Pre-arcing Time
Rated Current
350 mA ... 1.50 A
1.0 x I
N
>2h
3.0 x I
N
300 ms ... 5 s
Bellcore
cURus
350mA
500mA
800mA
1.00A
1.25A
1.50A
1 FCC 47 Part 68:
0350
0500
0800
1100
1125
1150
125V
125V
125V
125V
125V
125V
50 A / 125 V AC
50-60 Hz
cos
ϕ
= 1.0
540
320
160
105
75
60
250
220
170
140
125
120
90
110
130
130
140
170
0.6
1.2
2.7
4.5
6.7
9.0
32
48
80
100
128
155
19
26
42
52
65
78
36
61
67
67
67
67
•
•
•
•
•
•
ITU-T K.20:
Bellcore GR-1089:
Minimum pulse load quantity is 2 pulses at a test generator output of 800V and 10x560µs waveform.
Minimum pulse load quantity is 30 pulses at a test generator output of 1000V, 67A and 10x700µs waveform.
Minimum pulse load quantity is 50 pulses at a test generator output of 1000V and 10x1000µs.
Order
Information
050223
Qty.
Order-
Number
Series
385
Amp Code
Packaging
Specifications are subject
to change without notice
China
Tel: +86 21 6432 5146
E-mail: sales@wickmann.cn
WebSite
Europe
Tel: +49 2302 662-107
www.wickmanngroup.com E-mail: sales@wickmann.com
Americas
Tel: +1 404 699-7820
E-mail: service@wickmannusa.com
Asia
Tel: +852 26 14-1108
E-mail: sales@wickmann.com.hk
CCCe
FCC
ITU
Permissible continuous operating current is
≤
70% at ambient temperature of 23ºC (73.4ºF).
Rated
Amp Voltage Breaking Cold Resistance Voltage Drop Power Dissipation Melting Integral
1.0 x I
N
1.0 x I
N
10 x I
N
Current Code Rating Capacity
0.1 x I
N
max. (mΩ)
max. (mV)
max. (mW)
min. (A
2
s)
Surge Amplitude (A)
1
Approvals
•
•
•
•
•
•
